Installation should only be performed by a Quali ed Installation Professional
Contents of the box VESA 100 x 100 to VESA 600 x 800
1
2
M6 x
Not included
or M8 x
or
M10 x
M6 x12mm (8x)
Assemble
5 mm)
Assemble
3
Hang the monitor on the horizontal brackets
TP-1952-V04 ©2016 Promethean Ltd. All Rights Reserved. Products are subject to availability by country.
Product specifications are subject to change without notice.
M6 x
12mm (10x)
M6 x 12mm (10x)
or M8 x
12mm (10x)
or
M10 x
12mm (10x)
12mm (10x)
12mm (10x)
12mm (10x)
5 mm)
4
Center the monitor
ActivPanel Adjustable Stand 650
APTVMBB650 - Vesa Mount for use with APT2-84, AP4-84-4k,
AP5-86-4K & AP6-86-4K
Installation Guide
5
M6 x 12mm (2x)
Lock monitor with safety lock screws from the bottom
