- Page 1 PRODUCT ADEBUS & GAPID EXPLORER Product code ADEBUS & GAPID EXPLORER ADEBUS & GAPID EXPLORER MONITORING CONTROL UNIT INSTALLATION AND WIRING MANUAL VERSION 1.8...
-
Page 2: Table Of Contents
8.Relay output connections.…………………………………..…………………………………………………………………………13 9.Gapid SR sensor …………………………….…………………………………………………………………………..………..14 10.Installation method ………………………………………………..……………………………………………………………….….15 11.Connection of sensors to the control unit ..............……………………... 17 12.First access to the Adebus G board via IP address 192.168.1.222 ………………………………………..……..18 13.Gapid Explorer installation …………………………………………………….………………………………………………..19 14.First start-up ………………………………………………………………………………………………….……………………...21 14.1 Main screen 14.2 Working path... -
Page 3: Introduction
2. Product description The Adebus & Gapid Explorer is a monitoring control unit for the management of up to 128 sensors divided arbitrarily into 2 branches (expandable) using both the serial ports Com0 and Com1.Adebus Gapid manages, supervises and configures every single Gapid SR (or groups) -
Page 4: General Warnings
• Manufacturer's liability:Politec assumes no liability for failures resulting from incorrect installation; lack of maintenance, incorrect assembly or use. • Politec is also not liable for incorrect or incomplete operation of the product or failure to detect intrusion. •... -
Page 5: List Of Main Components
ADEBUS G Adebus motherboard ADEBUS ESP Expansion of 16 relay outputs INTERFACE BOARD TRASF LAR22S 18/24 Vac transformer ALPO1B Power supply board BATTERY (not included) 17 Ah Battery compartment TAMPER ADEBUS & GAPID EXPLORER POLITEC | INSTALLATION MANUAL - VER.1.8... -
Page 6: Gapid Sr
The box contains the following components and accessories. When opening the package, check that everything has been included. COMPONENT Screw 3x7 Gapid SR cover Serial CS board Screw 3x20 Gapid SR container Fixing plate Cable glands ADEBUS & GAPID EXPLORER POLITEC | INSTALLATION MANUAL - VER.1.8... -
Page 7: Description Of The Boards
5.1 ALPO1B - Power supply board. COMPONENT 18 Vac input 24 Vac input 24 Vac output 0-13.8 Vdc outputs Battery output 10 A fuse (24 Vac) 3 A fuse (12 Vac) 3 A fuse (battery) ADEBUS & GAPID EXPLORER POLITEC | INSTALLATION MANUAL - VER.1.8... -
Page 8: Adebus G - Adebus Motherboard
5.2 ADEBUS G - Adebus motherboard. COMPONENT Serial input line COM1 Serial input line COM2 0-12 Vdc input LAN port Relay outputs block Inputs Relay expansion connection ADEBUS & GAPID EXPLORER POLITEC | INSTALLATION MANUAL - VER.1.8... -
Page 9: Adebus Esp - Expansion Of 16 Relay Outputs For Adebus
5.3 ADEBUS ESP - Expansion of 16 relay outputs for Adebus. COMPONENT 0-12 Vdc input Relay outputs block 1-8 Output connector to next expansion board Relay outputs block 9-16 Input connector from CA 230 motherboard Input connector from previous expansion board 5.4 ADEBUS INTERFACE... -
Page 10: Preparation For Installation
• Check that the surface chosen for the installation of the product is solid so as to ensure stable fixing and that it is adequately protected from possible impacts or atmospheric agents. ADEBUS & GAPID EXPLORER POLITEC | INSTALLATION MANUAL - VER.1.8... -
Page 11: Sensor Mounting
The Gapid SR can be connected to the net and to the Adebus control unit only with the cable supplied which is RS485. The cable must be inserted in the two slots below: one for input and one for output. - Page 12 The ADEBUS system manages up to 256 Gapid SR divided into 2 branches (maximum length 750m each) using both the serial ports Com1 and Com2 (for Com1 the ADEBUS S2 accessory is required), On the other hand, using a single serial port it is mandatory to create a single branch of the RS485 bus, without making further branches.In this case, however, 128 sensors can be used on the same branch.
-
Page 13: Relay Output Connections
C1-4 = common first 4 relays C5-8 = common second 4 relays C9-12 = common third 4 relays C13-16 = common fourth 4 relays ADEBUS & GAPID EXPLORER POLITEC | INSTALLATION MANUAL - VER.1.8... -
Page 14: Gapid Sr Sensor
Signalling buzzer (activated via software) Input Connector: Output Connector:Connection Connection to the previous to the next Gapid Gapid or the Adebus control unit Sensitivity adjustment trimmer:It is generally used to check sensitivity in the field.This sensitivity will be overwritten via software. -
Page 15: Installation Method
Panel 1 Panel 2 N.B.:For correct operation, all sensors placed on the same side of a continuous fence must be connected to the same branch as in the drawing below. ADEBUS & GAPID EXPLORER POLITEC | INSTALLATION MANUAL - VER.1.8... - Page 16 Anti-breach wall: depending on the structure of the wall, typically mount a sensor every 5m. Windows or internal applications: mount a sensor every 5m depending on the structure. ADEBUS & GAPID EXPLORER POLITEC | INSTALLATION MANUAL - VER.1.8...
-
Page 17: Connection Of Sensors To The Control Unit
11.Connection of sensors to the control unit The connection of the Gapid SR sensors to the Adebus control unit must be made exclusively with the serial cable («input and output» mode) following the diagram below: If required, make the same... -
Page 18: First Access To The Adebus G Board Via Ip Address 192.168.1.222
12.First access to the Adebus G board via IP address 192.168.1.222 Connect the PC to the LAN connector of the ADEBUS G board with Ethernet cable. The system is accessible via Gapid Explorer software or via the WEB. N.B.: for the first access: username: admin, password: admin. -
Page 19: Gapid Explorer Installation
Gapid Explorer is a supervision and configuration program for Gapid SR sensors. The software can be used in three different languages (English, Italian, French). 13.2 First access: direct PC connection - Adebus G • Make direct connection with Static IP address. - Page 20 Internet Protocol and click Properties. Choose, if not already selected, an IP address different from that of the ADEBUS G board (default is 192.168.1.222) for example the address 192.168.1.223 and click on Subnet mask so that the following appears:255.255.255.0Save with OK.
-
Page 21: Main Screen
Settings menu, Work folders. By copying the database file and the plant image file it is possible to manage the systems from different PCs. ADEBUS & GAPID EXPLORER POLITEC | INSTALLATION MANUAL - VER.1.8... -
Page 22: Site Creation
Select the site created via the drop-down menu and activate the Configuration mode function. Select Board Configuration and enter the name of the Adebus G board with its IP address and port 8000. For large systems it is possible to insert an indefinite number of Adebus G boards within the same system and manage them through the only interface. - Page 23 Each segment is asked for the number of Gapid SR present in the line. Using the right button it is possible to connect the various segments modify them. ADEBUS & GAPID EXPLORER POLITEC | INSTALLATION MANUAL - VER.1.8...
- Page 24 Each Group must contain at least 4 sensors. If some sensors are not associated with Groups, these sensors will be considered completely independent (e.g. a single sensor applied to an iron gate between two welded nets). ADEBUS & GAPID EXPLORER POLITEC | INSTALLATION MANUAL - VER.1.8...
-
Page 25: Site Configuration
MODE:It is the type of programming of the sensors within the group according to the application. ADEBUS & GAPID EXPLORER POLITEC | INSTALLATION MANUAL - VER.1.8... - Page 26 Gin:By sending a number different from 0 the group will be inhibited for the equivalent in minutes. By clicking on Outputs, you can access the menu of the outputs relating to the Group. The relay outputs of the Adebus are managed as follows: Output numbers Description 1 …...
-
Page 27: Single Sensor Configuration
TEST:If the sensor sends a pre-alarm signal, it sounds.This function can be used during the testing phase to properly select the alarm thresholds. DISABLED:The sensor can be disabled.It will no longer give any tamper, alarm, offline signal. ADEBUS & GAPID EXPLORER POLITEC | INSTALLATION MANUAL - VER.1.8... - Page 28 Click on Copy and Send to apply the standard configuration of the algorithms. Activate the "Input 1 enable recording" flag so that the system records the events in the archive only if input 1 of the Adebus G board is balanced to ground of 1kΩ. ADEBUS & GAPID EXPLORER...
-
Page 29: Operating Condition
By double clicking on the Group or on the single sensor if it is not associated, it is possible to check the operating status. Group status Serial port Number Gapid SR Individual sensor pre-alarm ADEBUS & GAPID EXPLORER POLITEC | INSTALLATION MANUAL - VER.1.8... -
Page 30: Configuration And Management Via Web
This function is normally disabled to keep the system safety level high. Through the WEB management it is possible to view the status of the individual groups, sensors and change the configurations similarly to the software. E.g.Group status: ADEBUS & GAPID EXPLORER POLITEC | INSTALLATION MANUAL - VER.1.8... -
Page 31: Archive
Event storage can be enabled or disabled through system configuration. The Adebus G board maintains a maximum of 32000 events by overwriting the oldest in case of running out of available space.To view a greater number of events, it is necessary to open .db database files in the Gapid Explorer work folder using an appropriate program. -
Page 32: Settings
The system allows to use PopUps in case of important system events.During the group configuration phase it is possible to choose which ones to select and enable.These PopUpsare linked to the events archive downloaded on PC. ADEBUS & GAPID EXPLORER POLITEC | INSTALLATION MANUAL - VER.1.8... -
Page 33: Reset Adebus G Board
17.2 Reset Adebus G board It is possible to reset the Adebus G board to the factory settings by performing this procedure: • Disconnect the Adebus G board • Remove the COM1 serial port module. • Make a jumper on contact 3-5. -
Page 34: Advanced Configurations - Group
Structure must be sent using the appropriate button. Using the OUTPUTS button it is possible to configure the output relays referring to the INDIVIDUAL sensor signals. ADEBUS & GAPID EXPLORER POLITEC | INSTALLATION MANUAL - VER.1.8... - Page 35 Enable net cut time: Through this function it is possible to keep the vibration in memory for a timing expressed in days.N.B.:This function significantly increases the sensitivity of the system. ADEBUS & GAPID EXPLORER POLITEC | INSTALLATION MANUAL - VER.1.8...
- Page 36 SR 1 and Gapid SR 6 have a different configuration than the group, for example less sensitive because the fence is damaged.By rewriting the group programming, you can choose whether to keep the different programming or overwrite it. ADEBUS & GAPID EXPLORER POLITEC | INSTALLATION MANUAL - VER.1.8...
-
Page 37: Advanced Configurations - Gapid Sr
In the presence of Resonance, the alarm on a single sensor will be excluded.The "Recorded Resonance" flag indicates that the sensor has recorded this type of vibration and will be ready to filter it in the future. ADEBUS & GAPID EXPLORER POLITEC | INSTALLATION MANUAL - VER.1.8... - Page 38 To register it, it is necessary a single hit to the fence and verify its registration by viewing the status of the single sensor. The "Self-acq.For registered alarm ” flag indicates that the sensor has registered this type of vibration and will send an alarm signal in the future. ADEBUS & GAPID EXPLORER POLITEC | INSTALLATION MANUAL - VER.1.8...
- Page 39 Reset to group configuration: Retrieve the group configuration and overwrite it with the current configuration Format: The factory configuration of the sensor is recovered.In this case it is necessary to readdress the sensor. ADEBUS & GAPID EXPLORER POLITEC | INSTALLATION MANUAL - VER.1.8...
-
Page 40: Advanced Configurations - System Configuration
20%.Adjacent sensors must register at least 2 vibrations. Max BadCom \ Day:Maximum number of badcoms per day to record an alert Inputs 2-8: not enabled in the future. ADEBUS & GAPID EXPLORER POLITEC | INSTALLATION MANUAL - VER.1.8... -
Page 41: Advanced Configurations - Send Group Structure
Through software it is possible to access only with one user at a time.It is therefore necessary to log out before exiting the program so that another user can immediately access the site. ADEBUS & GAPID EXPLORER POLITEC | INSTALLATION MANUAL - VER.1.8... -
Page 42: Gapid Sr Technical Specifications
Adebus with RS485 serial connection 6 Standard Application Functions FUNCTIONS 3 self-learning functions (1 for alarm and 2 for non- alarm) POWER SUPPLY From 7 - 24 Vdc directly from Adebus ADDRESSING Automatic TECHNICAL SIGNALS Deactivation / Off line OUTPUT... -
Page 43: Adebus Gapid Technical Specifications
COMMUNICATION OUTPUT LIVE VIEWING Status of each sensor or group INTERFACE OUTPUTS 3 Relays on Adebus SC 16 Relays on Adebus ESP (accessory) up to 4 Adebus ESP POWER SUPPLY 220V with dedicated 13.8V power supply BATTERY HOUSING 12V up to 17Ah... -
Page 44: Product Disposal
Warning!- Local regulations can impose heavy penalties for incorrect disposal of these products. For technical support, contact your security systems distributor POLITEC | INSTALLATION MANUAL - VER.1.8...
