- Page 1 PRODUCT ADEBUS Product code ADEBUS ADEBUS MONITORING CONTROL UNIT INSTALLATION AND WIRING MANUAL VERSION 2.1...
-
Page 2: Table Of Contents
4.1 The control unit 5.Description of the boards ………………………………………………………………………………………………………… 7 5.1 ADEBUS SC - Adebus motherboard 5.2 ADEBUS ESP - Expansion board with 16 relay outputs for Adebus 5.3 ALPO2B 6.Preparation for installation ………………………………………………..…………………………………………………..10 6.1 Preparing the components before installation 6.2 It is advisable to carry out... - Page 3 14.Appendix D - Sectioning ….…………… .. ……………………………………………… ..29 14.1 Enabling in pairs - Sectioning 14.2 Area configuration - Sectioning 14.3 Software configuration - Sectioning 15.Technical characteristics …………….……………………………………………. ………… .30 16.Product disposal ………….………………. …………………………………. ……….….…. ..31 ADEBUS POLITEC | INSTALLATION MANUAL - VER.2.1...
-
Page 4: Introduction
The barriers and the monitoring control unit have been designed to detect intrusions and activate the alarm; it is not a device that prevents intrusion.Politec is not responsible for damage, injury or loss caused by accidents, theft, force majeure (including momentary lightning-induced overcurrent), abuse, improper or incorrect use, faulty installation or inadequate maintenance. -
Page 5: General Warnings
• Manufacturer's liability:Politec assumes no liability for failures resulting from incorrect installation; lack of maintenance, incorrect assembly or use. • Politec is also not liable for incorrect or incomplete operation of the product or failure to detect intrusion. •... -
Page 6: The Control Unit
COMPONENT CODE DESCRIPTION ADEBUS Adebus motherboard ADEBUS ESP Expansion board with 16 relay outputs ADEBUS S2 BOARD TRANSF LAR22S 18/24 Vac transformer ALPO2B Power supply board BATTERY (not included) 17 Ah Battery compartment TAMPER ADEBUS POLITEC | INSTALLATION MANUAL - VER.2.1... -
Page 7: Adebus Sc - Adebus Motherboard
5.Board Description 5.1 ADEBUS SC - Adebus motherboard. Control board, to which RS485 is connected for barriers, Adebus Esp and LAN port COMPONENT Serial input line COM0 Serial input line COM1 0-12 Vdc input LAN socket Relay outputs block Inputs... - Page 8 5.2 ADEBUS ESP - Adebus ESP Relay board Interface board between configured relay outputs and universal alarm control unit COMPONENT 0-12 Vdc input Relay outputs block 1-8 Output connector to next expansion board Relay outputs block 9-16 Input connector from CA 230...
- Page 9 5.3 ALPO2B - Power supply board. COMPONENT 18 Vac input 24 Vac input 24 Vac output 0-13.8 Vdc outputs Battery 12V - 17Ah output Signalling outputs 10 A fuse (24 Vac) 3 A fuse (12 Vac) ADEBUS POLITEC | INSTALLATION MANUAL - VER.2.1...
-
Page 10: Preparation For Installation
• Alignment and functional verification of all barriers in the field without the use of software; • Taking note of the serial numbers of the individual barriers; • Site creation from Adebus Explorer software; • Barrier addressing; • System start-up via WEB page, System Configuration menu and individual column flags;... -
Page 11: Connections
7.Connections 7.1 Adebus internal connections It is necessary to make the power supply connections for all the boards present, Adebus SC and Adebus ESP respecting the polarity.Also check the connection between the Adebus board and Adebus +12Vdc 7.2 Adebus- barrier connections Connect the columns to the Adebus SC board using the dedicated shielded double twisted cable.It is... -
Page 12: Examples Of Cable Connections
Adebus and all the columns E.g.Synchronism ADEBUS connects all the columns.Bus ADEBUS connects Adebus and all the columns E.g.Synchronism connects all the ADEBUS ADEBUS columns.Bus connects Adebus and all the columns ADEBUS POLITEC | INSTALLATION MANUAL - VER.2.1... -
Page 13: Installation And First Access - Default Static Ip 192.168.1.222
The ADEBUS system is managed via a LAN port with a static IP address.The system can be accessed remotely by activating the public IP address and opening the dedicated ports (port forwarding).For full use of the system it is necessary to use the Adebus Explorer software and the web page located on ports 8000 and 80 respectively. -
Page 14: Main Screen
.sdf format is created.These folders can be edited via the Settings menu, Working folders. By copying the database file and the site plan image file it is possible to manage the systems from different PCs. ADEBUS POLITEC | INSTALLATION MANUAL - VER.2.1... -
Page 15: Site Creation
8.6 Site Creation Through the "SITE EDITOR" menu, it is possible to create\edit the installation under management New Site: • Site Name • IP address • Serial • Site plan image (.jpg, .png only) ADEBUS POLITEC | INSTALLATION MANUAL - VER.2.1... -
Page 16: Configuration Mode
(COM0-COM1) • Enter the 6-digit serial number on the base of the column and on the motherboard E.g. 015476 • Select the unique address from 1 to 32 ADEBUS POLITEC | INSTALLATION MANUAL - VER.2.1... -
Page 17: Adding Or Replacing Barrier
It is possible to enable alarm\tamper\offline popups.These Popups are used only if there is a PC always connected to the Adebus, otherwise the display of the Popups takes place for all the events previously recorded but not yet on the PC ADEBUS POLITEC | INSTALLATION MANUAL - VER.2.1... -
Page 18: Access To The Columns - Adebus Explorer
9.Access to the columns - Adebus Explorer Access the site via Adebus Explorer software and connect using the «Connect» button 9.1 Key • Green: column in rest status • Light blue: column in tamper status • Red: column in alarm status •... -
Page 19: New Configuration
The Copy button copies the current configuration of the barrier in the New Configuration section and by selecting the desired options it is possible to configure the barrier The Advanced button is dedicated to a reserved section that is not accessible ADEBUS POLITEC | INSTALLATION MANUAL - VER.2.1... -
Page 20: Input/Output Associations
9.4 Input/Output associations It is possible to associate each recorded event to a relay output/open collector present on the Adebus and on the Adebus ESP boards.In the Outputs item inside the "New Configuration" it is possible to have access to these settings. - Page 21 The events are recorded continuously by default.For controlled recording start, it is necessary to act by balancing with 1K resistor on INPUT 1 of the Adebus SC board.Via the WEB page go to the "Output Configuration" menu and flag Master Input 1 enabled storage.The storage in this case occurs if the input is balanced.
- Page 22 The statuses and some configurations can be managed via the WEB page 11.1 Columns detail Display of the status of each column. 11.2 Columns status Display of the communication status between adebus and column.Good communication is with a ratio:GOOD COM:BAD COMM> 300:1 ADEBUS POLITEC | INSTALLATION MANUAL - VER.2.1...
- Page 23 11.4 Network Configuration It is possible to change the Adebus address.By default the ports are the 8000 not editable for the software and the 80 editable for the web page. ADEBUS POLITEC | INSTALLATION MANUAL - VER.2.1...
- Page 24 SECTIONING furthest in ascending order Crawl sector All rays obscured RAY ALARM Status of the rays resulting in alarm RAY LOW Rays in low signal area (disqualification) RAY MASK Rays in masking status ADEBUS POLITEC | INSTALLATION MANUAL - VER.2.1...
- Page 25 Allows you to configure the alarm relay on the column to close (or open) according to an event at your discretion SECTIONING It enables the SECTIONING function ADEBUS POLITEC | INSTALLATION MANUAL - VER.2.1...
- Page 26 Special Input 2 (AND input) and one on the Special Input 3 (Gin input).For details, see the MANA barrier manual It is the intervention time of the barrier expressed SPEED in milliseconds.By default it is set to 50ms ADEBUS POLITEC | INSTALLATION MANUAL - VER.2.1...
-
Page 27: Connection In Barrier
15k or 30k. 13.2 Enabling and software status Status of the special inputs IN1, IN2, IN3 ENABLE SPEC INP to activate the reading function of the external inputs ADEBUS POLITEC | INSTALLATION MANUAL - VER.2.1... -
Page 28: Output Configuration
2 to status 1 (e.g. relay 609) INPUT3: The set relay will change status if the input switches from DC to AC with respect to GND (e.g. relay 410) ADEBUS POLITEC | INSTALLATION MANUAL - VER.2.1... -
Page 29: Appendix D - Sectioning
From the WEB page select the pairs that are working in sectoring.In the example only the pairs 1- 2 and 5-6 work with this function.The outputs for the sectoring function in this case will be present on column 1 and column 5. ADEBUS POLITEC | INSTALLATION MANUAL - VER.2.1... -
Page 30: Area Configuration - Sectioning
If selected, information is provided on all the All beams obscured obscured beams of the barrier Special sectors Crawling If selected, the crawling information is provided Columns The distance between the columns of the barrier must be selected distance ADEBUS POLITEC | INSTALLATION MANUAL - VER.2.1... -
Page 31: Software Configuration - Sectioning
Outputs of the first column of the barrier and configure the sectors concerned. The Outputs to be enabled for sectioning are exclusively on the first column of the enabled pair. COLUMN COLUMN COLUMN COLUMN ADEBUS POLITEC | INSTALLATION MANUAL - VER.2.1... -
Page 32: Product Disposal
Event storage capacity 32000 exportable Communication output Real-time visualisation Status of each column Interface outputs 3 Relays + 4 Open Collector on Adebus SC 16 Relays on Adebus ESP 6 Adebus ESP Power supply 220V with dedicated 13.8V power supply Battery housing...
