GLD Products Viper ILLUMISCORE Mounting Instructions

b y G L D P R O D U C T S
TOOLS REQUIRED
• Pencil or marker
• Phillips screwdriver
• Power drill with either:
∕
"
1 (0.0625 inch)
16
•
drill bit, or
∕
" (0.25 inch)
1
4
•
• 4 AA batteries
• 4 mounting screws with
wall anchors (included)
• Level
• Stud finder (optional)
POWER INSTALLATION
The IllumiScore scoreboard requires 4 AA batteries (not
included). Open the two battery covers at the front. Insert 4
AA batteries following the + and – guides. A 5-volt 500 mA
adapter with positive outer may also be used. Adapter item
#42-9988 is available from GLD Products.
UNPACKING THE SCOREBOARD
After unpacking the IllumiScore, save the original box, all
packing material, and the receipt in case you must return
the product for service. The scoreboard may have a clear
protective film attached to prevent scratching during
shipping. Remove this film before use.
SAFETY PRECAUTIONS
1. The IllumiScore is not intended for children under the age
of 12 years old.
2. The IllumiScore must only be used with the
recommended batteries.
3. The IllumiScore is not a toy.
ILLUMISCORE
Mounting Instructions
drill bit
GLD Customer Service:
Email: info@gldgames.com
www.gldproducts.com
Drilling Instructions
Use a stud finder prior to
drilling to determine which
drill bit to use.
If drilling into a stud use a
" drill bit.
1 16
If there is no stud use a
" drill bit.
1
4
Drill a hole for the anchor, then tap
the anchor into the hole before
tightening the screw into the anchor
If drilling into a cabinet, use smaller
screws and drill the board directly onto
the cabinet door. (Screws not provided)
