DutchWest Sequoia 2160 Installation And Operating Manual

Vermont castings fireplace homeowner's installation and operating manual 2160
Hide thumbs Also See for Sequoia 2160:
Table of Contents

Advertisement

Quick Links

See also: Homeowner's Installation and Operating Manual
Homeowner's Installation and Operating Manual
If this Sequoia is not properly installed, operated, and maintained, a
house fire may result. For safety, follow all installation, operation and
Maintenance directions. Contact local building officials about restric-
tions and installation inspection requirements in your area.
DO NOT DISCARD THIS MANUAL: Retain for future use

SAFETY NOTICE

CFM Specialty Home Products
410 Admiral Blvd. • Mississauga, Ontario, Canada L5T 2N6 • 905-670-7777
www.majesticproducts.com • www.vermontcastings.com
Sequoia
Model 2160
2001049 4/04 Rev. 4

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Sequoia 2160 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for DutchWest Sequoia 2160

Summary of Contents for DutchWest Sequoia 2160

  • Page 1 DO NOT DISCARD THIS MANUAL: Retain for future use SAFETY NOTICE CFM Specialty Home Products 410 Admiral Blvd. • Mississauga, Ontario, Canada L5T 2N6 • 905-670-7777 www.majesticproducts.com • www.vermontcastings.com Sequoia Model 2160 2001049 4/04 Rev. 4...
  • Page 2 California Health & Safety Code Sec. 25249.6 This manual describes the installation and operation of the Sequoia Model 2160 catalytic-equipped wood heater. This heater meets the U.S. Environmental Protection Agency’s emission limits for wood heaters sold after July 1, 1990. Under specific test conditions this heater has been shown to deliver heat at a rate ranging from 10,400 to 31,700 Btu’s/Hr.
  • Page 3 Sequoia, Model 2160 Range of heat output ... 10,400 to 31,700 Btu’s/hr.*** Maximum heat output ... 50,000 Btu’s/hr.***** Maximum burn time ... 8 hours* Area heated** ... 1,000-2,000 Square feet (65-130m Log lengths ... 23” (580mm) Loading ... Side or Front Chimney Flue Size ...
  • Page 4 Dutchwest Sequoia SAFETY NOTICE: IF YOUR SEQUOIA HEATER IS NOT PROPERLY INSTALLED, OPERATED AND MAINTAINED, A HOUSE FIRE MAY RESULT. FOR SAFETY, FOLLOW ALL INSTALLATION, OPERATION AND MAINTENANCE DIRECTIONS. CONTACT LOCAL BUILDING OFFICIALS ABOUT RESTRICTIONS AND INSTALLATION INSPECTION REQUIREMENTS IN YOUR AREA. Before you begin the installation, review your plans to confirm that: •...
  • Page 5 Prefabricated Chimneys A prefabricated metal chimney must be one tested and listed for use with solid-fuel burning appliances to the High-Temperature (H.T.) chimney Standard UL-103- 1985 (2100°F.) for the United States, and High Tem- perature (650°C) Standard ULC S-629 for Canada. DO NOT CONNECT THIS UNIT TO A CHIMNEY FLUE SERVING ANOTHER APPLIANCE.
  • Page 6 Dutchwest Sequoia stove. The entire chimney connector should be ex- posed and accessible for inspection and cleaning. Do not use galvanized chimney connector; it cannot withstand the high temperatures that can be reached by smoke and exhaust gases and it may release toxic fumes under high heat.
  • Page 7 A special piece called the "thimble sleeve," slightly smaller in diameter than the standard connector and most thimbles, will ease the removal of the chimney connector system for inspection and cleaning. (Fig. 6) Thimble sleeves should be available from your local dealer.
  • Page 8 Dutchwest Sequoia Wall Pass-Throughs Whenever possible, design your installation so the connector does not pass through a combustible wall. If you must use a wall pass-through in your installation, check with your building inspector before you begin and construct it in accordance with local building codes.
  • Page 9 completely noncombustible surface such as unpainted concrete over earth may be used without the heat shield. Even when the bottom heat shield is installed, you must provide special protection to the floor beneath. For installation with the heat shield attached, use a noncombustible floor protector such as 1/4"...
  • Page 10 Dutchwest Sequoia Hearth rugs do not satisfy the requirement for floor protection as they are not fire proof. Fireplace installations also have special clearance requirements to the side walls, side decorative trim and fireplace mantel. Refer to the information on fireplace and mantel trim shields in this section.
  • Page 11 Fig. 15 Maintain clearances to combustible components of the mantelpiece. 2001049 Fireplace and Mantel Trim Clearances Unprotected A. Mantel 24” (610mm) B. Trim 24” (610mm) C. Side Walls 32” (813mm) Dutchwest Sequoia ST731...
  • Page 12 Dutchwest Sequoia No stove heat shields (813mm) Stove, top exit with rear heat shield, no connector (813mm) heat shields Stove, top exit with rear (M) 32” heat shield, and heat (813mm) 1,2,3 shields on connector Stove, rear exit with rear (S) 32”...
  • Page 13 Unprotected Surfaces Stove Installed Stove in Corner Parallel to Wall Top Exit Installations, no heat shields Top Exit Installations, rear heat shield, no connector heat shields. Top Exit Installations, rear heat shield, heat shield on connector. Rear Exit Installations, rear heat shield only. 2001049 Sequoia Clearance Diagrams Stove Installed Parallel...

  • Page 14: Wall Shield Requirements For Common Sequoia Installations

    Dutchwest Sequoia Wall Shield Requirements for Common Sequoia Installations 32" (810mm) 1" (25mm) 14" (356mm) 36" (914mm) 60" (1524mm) 32" (813mm) (813mm) 1" (25mm) 58" (1473mm) 12" (305mm) 36" * (914mm) 1" (25mm) ST751 * When optional pedestal is used instead of standard legs, the wall shield height is 39 ”...
  • Page 15 Distance from the Center of the Flue Collar to the Wall in Top Exit Sequoia Installations The information on this page is helpful in planning stove placement for top exiting installations, particularly those installations with chimneys that pass through the ceiling. However, this is not a clearance chart. For clearance infor- mation, refer to the clearance chart on Page 12.
  • Page 16 Dutchwest Sequoia Unpack the Parts Remove all loose parts from the firebox and the ash pan. Check to make sure all the parts are included and intact. You should have received: • 1 fully assembled heater body, (with catalytic burner installed in its chamber below the stove top) •...
  • Page 17 Install Air Duct for Outside Air If your installation will include outside air for combus- tion, follow these directions for attaching the three inch duct to the stove: • Screw a #10 x 1/2” sheet metal screw into the duct. Tighten the screw, then back it off two turns.
  • Page 18 Dutchwest Sequoia The Sequoia Controls Air Controls The Sequoia has three air controls that regulate the amount of air drawn into the stove. Generally, more air entering the stove makes the fire burn hotter and faster, while less air prolongs the burn. The Primary Air Control is the lever located on the upper right side of the stove front and is the primary source of air for starting and maintaining wood fires.
  • Page 19 Successful Wood Burning Burning wood and coal is often said to be more of an art than a science. You will easily master the art if you start by using good, dry fuel and by understanding how the stove’s air supply system operates. Burn Only High-Quality Fuel This heater is designed to burn natural wood only (or coal, when the catalytic combustor has been removed...
  • Page 20 Dutchwest Sequoia Fig. 20 The Sequoia’s primary air supply is closed at the 5 o’clock position, and fully open at 8 o’clock or more. Sequoia Control Settings for Coal Fires (The primary air and combustor air controls always remain closed. Primary air is closed a the 5:00 position, while the combustor air is closed when rotated fully clockwise.) Burn Rate...
  • Page 21 Never kindle a fire with colored paper or paper that has colored ink or a glossy surface, and never burn treated wood, garbage, solvents, or trash. All of these may poison the catalyst and prevent it from operating properly. Never burn cardboard or loose paper except for kindling purposes.
  • Page 22 Dutchwest Sequoia correct this situation, roll up a couple pieces of newspa- per, place them on top of the kindling and toward the back of the stove, light them and close the doors. This should heat the chimney enough to initiate a draft. Once the draft is established, open the front door and light the rest of the fuel from the bottom.
  • Page 23 Keep Your Stove Looking New And Working Its Best Care of the Cast Iron Surface An occasional dusting with a dry rag will keep the painted cast iron of your Sequoia looking new. If the paint needs retouching, allow the stove to cool completely.
  • Page 24 Dutchwest Sequoia Repair Missing Cement in Seams The cement in the stove seams may deteriorate over time and fall out in places. Just as with the stove doors, it is necessary to keep the seam seals in good condition. Spot-fix with furnace cement (available from your local dealer) any areas where the cement seal is visibly deteriorated.
  • Page 25 9. Test the damper mechanism. If further adjustment is necessary, continue to tighten the adjusting bolt until the damper closes snugly. 10. When final adjustment has been made, tighten the adjusting bolt lock nut. 11. Tighten the anchor bolt. Tighten the anchor bolt lock nut.
  • Page 26 Dutchwest Sequoia • For a visual inspection for blockage that can be performed without removing the combustor, have an assistant shine a bright flashlight beam up through the combustor from inside the stove’s firebox. • If combustor removal is necessary for cleaning or closer inspection, lift it gently out of its chamber.
  • Page 27 Clean the chimney using a specially designed chimney cleaning brush, the same size and shape as the flue liner, attached to flexible fiberglass rods designed for this purpose. Run the brush up and down the liner so that any deposits fall to the bottom of the chimney where they can be removed through the clean-out door.
  • Page 28 Dutchwest Sequoia In any chemical reaction, including the combustion process, there are certain conditions which must be met before the reaction can take place. For example, a reaction may require a certain temperature, or a certain concentration of the reactants (the combustion gases and oxygen), or a certain amount of time.
  • Page 29 Your stove is only one part of a system that includes the chimney, the operator, the fuel, and the home. The other parts of the system will affect how well the stove works. When there is a good match between all the parts, the system works well.
  • Page 30 Dutchwest Sequoia Single Venting Your stove requires a dedicated flue. Do not connect the stove to a flue used by any other appliance. Chimney draft is a natural form of energy and follows the path of least resistance. If the stove is vented to a flue that also serves an open fireplace or another appliance, the draft will also pull air in through those avenues.
  • Page 31 1049 CFM Specialty Home Products reserves the right to make changes in design, materials, specificaitons, prices and discontinue colors and products at any time, without notice. Sequoia Woodburning Stove Model 2160 Item Description 1. Bottom 2. Back 3. Bottom, Inner 4.
  • Page 32 Dutchwest Sequoia Sequoia Woodburning Stove Model 2160 (continued) Item Description 15. Side, Left 16. Plate, Side Door Hinge 17. Door, Side 18. Front, Sequoia 19. Door, Front 20. Gasket, Fiberglass 3/8 - Low D, 6ND 21. Hinge, Front Door Upper 23.

  • Page 33: Limited 1 Year Warranty

    Warranty Limited 3 Year Warranty CFM Specialty Home Products warrants that this woodburning stove will be free of defects in material and workmanship for a period of three years from the date you receive it, except that the catalyst, thermostat assembly, handles, glass door panels, cement, and gasketing shall be warranted as described below.
  • Page 34 CFM Specialty Home Products 410 Admiral Blvd. • Mississauga, Ontario, Canada L5T 2N6 • 905-670-7777 www.majesticproducts.com • www.vermontcastings.com...
