Item # 46027 CLE / 7.5 ft. Nordman Fir Pro Shape Tree with 900 ct. Clear Lights
Item # 46027 MUL/ 7.5 ft. Nordman Fir Pro Shape Tree with 900 ct. Multi Lights
PACKED IN ONE REUSABLE CARTON
• 1 EA. TREE STAND (with 3 screws)
• 1 EA. BOTTOM SECTION OF TREE "A"
• 1 EA. LOWER MIDDLE SECTION OF TREE "B"
• 1 EA. UPPER MIDDLE SECTION OF TREE "C"
• 1 EA. TREE TOP SECTION OF TREE "D"
• 1 EA. REMOTE ON AND OFF UNIT
• 1 EA. WARRANTY AND INSTRUCTIONS
• 1 EA PACKET OF EXTRA BULBS AND FUSES
• 1 EA. TREE CARTON-WITH EXPANDABLE FEATURE
• 1 PAIR ARTIFICIAL CHRISTMAS TREE SHAPING GLOVES
1. Unpack:
Carefully remove the contents from the carton and keep the carton for future storage. Some
sections of the tree may be heavy and assistance may be required. Be sure to untangle any
wires that may be caught with other items. (Please DO NOT forcibly remove any contents.)
Remove any outer foam wrapping from the tree and its branches (See Fig. 1A).
2. Basic Assembly Steps:
CAUTION: Two people may be needed to balance and assemble tree's upper
sections. Please use a ladder, if needed, and follow all ladder safety instructions.
46027 / 7.5 ft. Nordman Fir Pro Shape Tree
INSTRUCTIONS FOR:
BILL OF MATERIAL (BOM)
TREE ASSEMBLY INSRUCTIONS
Fig. 1A
Page 1
