Rowlinson Sorrento set Assembly Instructions

3. Coffee Table

Place the table top upside down and attach a leg to each corner using 1 x 15mm bolt per leg.
Position the shelf between the four legs and attach to the legs using 2 x 15mm bolts per leg.
Put a plastic cap on the head of each bolt and then turn the table over the right way and place the glass in
the centre of the table top.
If in doubt of any aspect regarding the assembly, use or safety of your furniture set please contact us :
Help Line (Normal Office Hours) 01829 261 121
ROWLINSON GARDEN PRODUCTS LIMITED
Green Lane
Wardle Nr. Nantwich
Cheshire
CW5 6BN
We constantly improve the quality of our products, occasionally the
components may differ from the components shown and are only
correct at time of printing. We reserve the right to change the
specification of our products without prior notice.
2010 © Rowlinson Garden Products Ltd
Sorrento set assembly
Assembly Instructions

Before assembly

•
We recommend that time is taken to
read the instructions before starting
assembly, then follow the easy step by
step guide. The instruction sheet is only
a guide to the assembly.
Certain items may not be shown
to scale.
•
Check all components prior to assembly
•
We recommend this product should be
assembled by no less than two people
x 2

Recommended tools for assembly

•
Allen Key (supplied with kit)
No. Components Qty.
1 Left arm 3
2 Right arm 3
3 Sofa seat 1
4 Sofa back 1
5 Armchair back 2
6 Armchair seat 2
7 Table leg 4
8 Table top 1
9 Table shelf 1
10 Table glass 1
11 Cushions 4
No. Fixing kit Qty.
12 30mm bolts 31
13 15mm bolts 12
14 Plastic caps 43
15 Allen key 1
