HIKVISION HD IP PoE KIT Quick Start Manual

HD IP PoE KIT QUICK START GUIDE
STEP
Connect the NVR to your TV / monitor
1
Or
Connect NVR to your HDTV using HDMI just like a digital satellite box. It
should be noted that not all the TV can automatically adjust the correct
HDMI input, please check your TV's user guide for this information.
STEP
Connect the cameras and power up
4
48V Poweradapter
- Power up the NVR
- Connect the Plug-and-Play cameras via the PoE interfaces.
- Enter the Camera Management interface. (Menu> Camera> Camera)
- You can see the connected cameras are listed.
STEP
Connect the NVR to your network
2
Use the RJ45 Ethernet cable to connect your Internet router for mobile
monitoring. NVR can work without Internet network connection but some
functions may be a ected.
STEP
Log-in to your NVR
5
Use your TV or monitor to log in the NVR operation interface
Simpli ed Management
NVR with 4 PoE ports
2x IR Bullet cameras
STEP
Connect the mouse to your NVR
3
You can connect the USB mouse supplied to operate the NVR, just like
plugging a mouse in to a PC or Laptop.
STEP
Add a normal Camera
6
- Click the edit button, and select the Adding Method as Manual in the
drop-down list.
- Now You have disabled the PoE interface by selecting the Manual while
the current channel can be used as a normal channel and the parame-
ters can also be edited.
- Click Apply to nish adding.
STEP
Password Modi cation
7
*The default account and password is admin and 12345.
- Enter the User Management interface. (Menu> Configuration> User)
- Select the user that you want to modify the password. Click the icon .
- Tick the Change Password box. Enter the new password in the New
Password and Con rm elds.
