AvalonMiner1026 User Manual
Overview
Thank you for choosing AvalonMiners. Please read through this user manual carefully before
mining as to ensure the correct opera<on and installa<on of the products, and keep the manual
properly for future reference.
Safety Regula9on
Warning: In order to prevent human safety accidents, such as Mining machine and power
damage, fall, electric shock and fire, please install and use the machine strictly in accordance
with the instruc<ons. It's prohibited to modify the Mining machine or power, and replace the
components personally.
▪
Don't use the power supply beyond the rated voltage range.
▪
Don't put the Mining machine in unstable places.
▪
When inspec<ng and repairing the Mining machine or the power supply, please entrust
professional personnel for the opera<on.
▪
When abnormal phenomena of Mining machine or power supply occurs, cut off the
power immediately and contact the aFer-sale personnel.
Hardware Connec9on
Connect the power supply and products as below Figs.
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 1026 and is the answer not in the manual?

Questions and answers

Related Manuals for AvalonMiner 1026

Summary of Contents for AvalonMiner 1026

  • Page 1 AvalonMiner1026 User Manual Overview Thank you for choosing AvalonMiners. Please read through this user manual carefully before mining as to ensure the correct opera<on and installa<on of the products, and keep the manual properly for future reference. Safety Regula9on Warning: In order to prevent human safety accidents, such as Mining machine and power damage, fall, electric shock and fire, please install and use the machine strictly in accordance with the instruc<ons.
  • Page 2 Power Connec<on Please fix the conversion card with the miner via 6M3*4screwsand insert the PSU into the slot as below Figs...
  • Page 3 Please stretch the output copper wire to connect the PSU with the miner via 12 M4*8 screws as the below Fig. Please insert the 6-pin wire into the matching socket. Each unit is born with 2 RJ45 ports available for a daisy-chain (sugges<on: beYer to be 12 units at most as one group).

  • Page 4: Indicator Lamps

    Keys and Indicator Lamps Keys RESET：System reset key, and system reset will not affect network series connec<on FUNC：Func<onal keys can be used to reset the miner back to the factory se]ngs, enter the configura<on mode, and switch ligh<ng status in opera<on, etc. Indicator Lamps ➢...

  • Page 5: Work Mode

    ➢ The indicator lamp is green under normal mining condi<on. ➢ The indicator is yellow during system prepara<on. ➢ The indicator lamp is red when the system is overheated. ➢ During system opera<on, the indicator lamp turns white by FMS soFware or manually pressing the FUNC key, and the lamp reset to original color aFer the Key pressed again.
  • Page 6 1. Please right click to “open network and internet se]ngs”; 2. Go to “change adapter op<ons” to disable WLAN and enable Ethernet. Then use browser to access hYp://192.168.168/to configure the device. (Modify sta<c IP, etc) AFer configura<on, nothing will take effect unless machine rebooted. Users are free to either click Reboot key on the leF part of the interface or power off...

  • Page 7: User Login

    User Login Default username: root, default password: root, it can enter the Overview page aFer login. Network SeHng Click on the leF Network of the console to set it to DHCP (dynamic acquisi<on) or IP(Sta<c). Note: AFer pressing the save key，please remember to restart the machine to make sure your network se]ng effec<ve.

  • Page 8: User Password

    User Password Default username: root, default password: root Click Administrator on the leF side of the console to set a new password and save it. Management SoKware FMS FMS User Guide ● Installa<on 1. Double click fms.exe icon to start the installer.
  • Page 9 2. Specify the installa<on directory in the following installer window: 3. Click Next:...
  • Page 10 4. Click Next:...
  • Page 11 5. Click Install to start installa<on:...
  • Page 12 Once the progress is done:...
  • Page 13 Click finish to complete the installa<on. ● User interface Introduc<on 1. Double click the desktop icon to enter FMS:...
  • Page 14
 manual scanning
 firmware upgrade
 change se]ngs

 temperature monitoring

 miner monitoring...
  • Page 15

 hash rate monitoring state: current status, marked or normal Pool & Worker:，pool & worker: pool configured and miner operator No. Number of Miner in Pool: Number of Miner in Pool: how many miners in pool IP address: miner IP address AUC count: number of AUC Miner Count: number of miners Elapsed Time: current opera<ng <me...
  • Page 16 The following figures represent: the monitoring <me interval (minutes); the high temperature alarm threshold for ambient temperature; the low temperature alarm threshold for ambient temperature; the temperature unit configura<on (Celsius, Fahrenheit) Click “+” buYon and enter the subnet IP range for the miners (e.g. 192.168.193.1-192.168.193.255), and click Confirm to auto-discover the miners.
  • Page 17 Select miners and click Save, the discovered miner’s IP addresses will be shown in the main window: 2. Firmware Upgrade Select the miner to be upgraded in the main window, and click Upgrade...
  • Page 18 Select the firmware file in the popup window: Click Open to begin the upgrade process. The following dialog will be shown if the upgrade is successful:...

  • Page 19: Firmware Upgrade

    Firmware Upgrade The upgrade package file’s format of this device is *. aup, which can be downloaded through the official website or via customer service. The device’s firmware upgrade can only be carried out through FMS soFware. Rest the Miner to Factory SeHng Press the FUNC key for five to ten secs (Before the indicator lamp turning red) when the power is on, and the system will automa<cally clear the saved configura<on, including network, mining...

  • Page 20: Warranty

    pool, password and other informa<on. AFer the configura<on cleared, the white indicator lamp will flash frequently indica<ng that the recovery configura<on is successful. AFer loosening the FUNC key, press the RESET key to restart, or cut off the power supply to restart, and the system will use the default factory configura<on to work.
