Summary of Contents for MasterCraft 060-1350-6
- Page 1 060-1350-6 CORDLESS BRUSHLESS 2-IN-1 LAWN MOWER INSTRUCTION IMPORTANT : Read and understand this instruction manual thoroughly MANUAL before using the product.
- Page 2 headline bars continuation tabs notes warnings...
-
Page 3: Table Of Contents
TABLE OF CONTENTS Technical Specifications Safety Guidelines Key Parts Diagram Operating Instructions Maintenance Troubleshooting Parts List Warranty NOTE: If any parts are missing or damaged, or if you have any questions, please call our toll-free helpline at 1-800-689-9928. SAVE THESE INSTRUCTIONS •... -
Page 4: Technical Specifications
060-1350-6 | contact us 1-800-689-9928 TECHNICAL SPECIFICATIONS Rated Voltage 40 V d.c. Deck Size 19” (48 cm) Cutting Height 1 1/2 to 3” (3.8 to 7.6 cm) *Maximum battery voltage without workload; with workload nominal voltage is 18 V. -
Page 5: Safety Guidelines
SAFETY GUIDELINES: WARNING! Safety symbols in this Instruction Manual are used to flag possible dangers. The safety symbols and their explanations require your full understanding. The safety warnings do not, by themselves, eliminate any danger, nor are they substitutes for proper accident prevention measures. - Page 6 060-1350-6 | contact us 1-800-689-9928 • Keep children out of the operating area and under the watchful care of a responsible adult other than the operator. OPERATING • Only operate the machine in daylight or good artificial light.
- Page 7 • If lawn mower strikes a foreign object, follow these steps: 1) Stop lawn mower; release the switch. 2) Unplug power cord. 3) Inspect for damage. 4) Repair any damage before restarting and operating the lawn mower. • Use identical replacement blades only. •...
- Page 8 060-1350-6 | contact us 1-800-689-9928 • Mow across the face of slopes; never mow up and down. Exercise extreme caution when changing direction on slopes. • Watch for holes, ruts, rocks, hidden objects, or bumps which can cause you to slip or trip. Tall grass can hide obstacles.
- Page 9 ....DANGER–Steep slope hazard. Use extra caution on slopes. Do not mow slopes greater than 15 degrees. WARNING! To reduce the risk of electric shock or damage to the charger and battery, use only the Mastercraft battery and chargers listed. ® BATTERY PACK...
-
Page 10: Key Parts Diagram
060-1350-6 | contact us 1-800-689-9928 PACKAGE CONTENTS: Cordless lawn mower, (2) cable clamps, grass collection bag, (2) bolts, (2) knobs, (2) locking levers, (2) washers, (2) nuts, upper handle bar, lower handle bar, mulching insert (inside of the mower). -
Page 11: Operating Instructions
OPERATING INSTRUCTIONS fig 1a ASSEMBLE THE LOWER HANDLE BAR 1. Align one hole of the lower handle bar with the rib on the mower, attach the lower handle bar onto the rib, and then align the other side of the lower handle bar to attach the bar onto the other rib (fig 1a). - Page 12 060-1350-6 | contact us 1-800-689-9928 ASSEMBLE THE UPPER HANDLE BAR fig 2 Upper handle bar (fig 2) 1. Align the holes on the upper handle bar with the Washer holes on the lower handle bar. 2. Insert the locking levers with washers into the...
- Page 13 ATTACH/REMOVE THE GRASS fig 5 COLLECTION BAG (fig 5) Rear-discharge 1. Remove the pre-installed mulching insert before door attaching the grass collection bag to the mower. 2. Use one hand to lift the rear-discharge door; use your other hand to hold the handle bar of the grass collection bag, and align the rods on the grass Handle bar collection bag with the slots on the mower to...
- Page 14 060-1350-6 | contact us 1-800-689-9928 TO DETACH THE BATTERY (fig 7) fig 7 Battery-release 1. Open the protective cap of the battery button compartment. Protective 2. Depress the battery-release button located on the front of the battery pack to release the battery.
-
Page 15: Maintenance
MAINTENANCE fig 10a Bolt REMOVE/INSTALL THE BLADE (fig 10) Blade After prolonged use, especially in sandy soil conditions, the blade will become worn and lose some of the original shape, which will reduce the cutting efficiency. Therefore, the blade should be replaced to ensure a good cutting performance. - Page 16 060-1350-6 | contact us 1-800-689-9928 STORAGE (fig 11) fig 11a 1. Switch the product off and remove the safety key and battery packs. 2. Store the product and its accessories in a dark, dry, frost-free, and well-ventilated place.
-
Page 17: Troubleshooting
TROUBLESHOOTING Problem Possible causes Solutions The battery is depleted. Charge the battery pack. The motor or the battery is over- Raise the cutting height, and restart loaded. the tool again. The mower doesn’t Wait for the battery or tool to cool work. -
Page 18: Parts List
060-1350-6 | contact us 1-800-689-9928 EXPLODED VIEW continuation tabs continuation tabs notes notes warnings warnings... - Page 19 No. Part no. Description No. Part no. Description 0601350601 Blade Bolt 0601350633 Plate 0601350602 Blade 0601350634 Grass Guide Plate 0601350603 0601350635 Front Face 0601350604 Power Head 0601350636 Square Head Bolt 0601350605 Right Front Wheel Cover 0601350637 Hexagonal Nut 0601350606 Right Front Wheel 0601350638 Back Cover 0601350607...
- Page 20 060-1350-6 | contact us 1-800-689-9928 0601350665 Knob 0601350679 Switch Cover 0601350666 Protective Hose 0601350680 Rubber Hose 0601350667 Cable Clamp 0601350681 Upper Handle Bar 0601350668 Terminal Sleeve 0601350682 Wire Trigger 0601350669 Switch Box 0601350683 Trigger Seat...
-
Page 21: Warranty
This product is guaranteed for a period of 3 years from the date of original retail purchase against defects in workmanship and materials, except for the following components: a) Component A: Batteries, chargers and carrying case, which are guaranteed for a period of 2 years from the date of original retail purchase against defects in workmanship and materials;... - Page 22 060-1350-6 | contact us 1-800-689-9928 to, scratches, dents, paint chips, or to any corrosion or discolouring by heat, abrasive and chemical cleaners; and i) this warranty will not apply to component parts sold by and identified as the product of another company, which shall be covered under the product manufacturer’s warranty, if any.
