Summary of Contents for Propeller AEROPOINTS
- Page 1 USER MANUAL...
- Page 2 An up-to-date version of this manual is available at: propelleraero.com/aeropoints-help. Propeller PPK users should refer to the PPK User Manual for additional information on how to use their AeroPoints. AeroPoint 1.2 Contains FCC ID: 2AHMR-ESP12S IC ID: 22439-APV102 Battery: 5000 mAh 3.2 V (16 Wh) LiFePO...
-
Page 3: Table Of Contents
Troubleshooting Before your flight During your flight After your flight Appendix I: AeroPoints correction methods Upload your AeroPoints data Appendix II: Configure Apply corrections and share your smartphone hotspot your AeroPoints data to act as Propeller WiFi Open the AeroPoints portal... -
Page 4: Introducing Aeropoints
INTRODUCING AEROPOINTS AeroPoints are the world’s first smart ground control points. Purpose-built for drone surveying, each AeroPoint includes a solar panel, battery, GPS, and WiFi inside a fully sealed, durable, lightweight shell. One-button operation In-built GPS Just place and press. Records positioning data Indicator light displays every 10 seconds. -
Page 5: Product Specifications
GCP data in CSV format certifications Care instructions AeroPoints are built tough, but you can extend their life by keeping them clean and dry when not in use. Simply remove dirt and dust with a damp cloth once your job is complete or soon after. -
Page 6: Integrated Cloud-Based Processing
AeroPoints together with Propeller’s cloud-based visualization and analysis platform. (Access to the Propeller Platform is available only with a software license purchase. Without it, you only have access to the AeroPoints dashboard, where you can process and export data to use elsewhere.) -
Page 7: Activate Online
AeroPoints Group. If you have more than one code, please use all codes simultaneously to assure AeroPoints are grouped together on your user portal. Under Portal Name, enter the business/entity you wish your AeroPoints to be assigned to. -
Page 8: Conduct A Flight
If you’re flying inside the Network, proceed as normal. If not, turn to Appendix I (page 16) to learn about alternative correction methods. Distribute the full set of AeroPoints (10 units) around your site, paying special attention to the perimeter. -
Page 9: During Your Flight
After you place each AeroPoint, press the button Avoid placing AeroPoints where they will be disturbed to start recording. The light will turn on, indicating by people, animals, or vehicles. (You should notify site AeroPoints are in “recording mode.” manager/personnel that AeroPoints are in use.) -
Page 10: Upload Your Aeropoints Data
In “upload mode,” the AeroPoint’s light will blink fast, indicating that it is connected and uploading data to Propeller. At the same time, you’ll see a blue bar at the top of your device screen, indicating that your hotspot connection is active. -
Page 11: Apply Corrections And Share Your Aeropoints Data
Select your AeroPoints Group from the left-hand menu. “Waiting for correction data” Click “Show all AeroPoints” to see the unique ID code For some locations, retrieving Propeller Corrections Network data can take a little longer (several hours). In this case, your associated to each AeroPoint, along with the time interface will display the above message. -
Page 12: Turn Your Drone Images
With the purchase of a Propeller Platform software license, we’ll process your drone images in 24 hours and integrate your corrected AeroPoints data to deliver accurate 3D site models. Want to learn more? Find detailed articles on the drone image upload process and the Propeller Platform at help.propelleraero.com... -
Page 13: Aerostencils: For Frequent Flyers
Do you fly the same site every day? If so, you can avoid placing and For PPK users, please refer to the picking up your AeroPoints each time by using AeroStencils to mark PPK User Manual your AeroPoint positions semipermanently. for specific guidance on AeroStencil use. -
Page 14: Faq
(7am–5pm MST; 9am–5pm AEST). How big an area can I cover with one set of AeroPoints? A set of 10 AeroPoints can achieve accurate results for an area up to 80ha/180 acres. For larger areas (up to 120ha/360 acres), we recommend using two sets. -
Page 15: Troubleshooting
Windows 10 Hotspot. (Find information on various hotspot setups at help.propelleraero.com.) I can’t see any of the AeroPoints in my images. It may be that your image resolution isn’t high enough, Alternatively, your AeroPoints may have been obscured your images are blurry, or your ground sample distance by trees, walls, or other objects. -
Page 16: Appendix I: Aeropoints Correction Methods
APPENDIX I: AEROPOINTS CORRECTION METHODS For accurate positions, corrections must be applied to AeroPoints data using one of the methods below. (Note: some methods have specific logging and/or placement requirements that should be adhered to.) The Propeller Using A Known Mark Corrections Network If you’re flying within the Propeller Corrections Network,... - Page 17 Local Site Calibration: If your site has its own local calibration, we can correct your AeroPoints to positions in your local site coordinates. You’ll just need to upload a local site calibration file (e.g., a Trimble .CAL) or send us or a point pair file (i.e.
- Page 18 Global accuracy: accuracy of your data, and consistency over time, will be 500mm/500mm/500mm reduced. Consistency: However, you can still use AeroPoints to get an internally 500mm/500mm/500mm accurate reconstruction—measurements and distances Internal accuracy: will be precise. 10mm or less (precise internal reconstruction) If you’re only capturing a site once (like a damage...
-
Page 19: Appendix Ii: Configure
Using an iOS device Change your device name From Settings, navigate to General > About > Name. Change the name of your device to “propeller.” Change your Personal Hotspot password From Settings, navigate to Personal Hotspot. Change WiFi password to “propeller” and toggle Personal Hotspot to On (green). - Page 20 SUPPORT Need help? Visit help.propelleraero.com for how-to articles, tutorial videos, and more. Email techsupport@propelleraero.com to get in touch with our tech support team. Propeller Aero Sydney, AU | Denver, USA Talk to us: hello@propelleraero.com propelleraero.com...
