Quick Installation Guide for OACIS-2XC
O A C I S
Open Architecture Control Integrated System
Version 01.06
http://www.atainc.com
ata@atainc.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the OACIS-2XC and is the answer not in the manual?

Questions and answers

Related Manuals for ATA OACIS-2XC

Summary of Contents for ATA OACIS-2XC

  • Page 1 Quick Installation Guide for OACIS-2XC O A C I S Open Architecture Control Integrated System Version 01.06 http://www.atainc.com ata@atainc.com...

  • Page 2: Package Contents

    14. Brake Cable £ 15. Motor Encoder Cable £ 16. CN1 Cable £ 17. STO Cable £ l SERVO CONTROLLER 18. OACIS-2XC £ 19. Firmware Download Cable £ l ETC 20. Quick Installation Guide £ 21. CD-ROM with Setup Software £...
  • Page 3 Quick Installation Diagram Check Up the Package Hardware Installation Software Installation OACIS Power On...
  • Page 4 I. Check up the Package £ Case I. One Servo Press with OACIS-2XC ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ £ Case II. One Nut Runner with OACIS-2XC ○ ○ ○ ○ ○ ○...
  • Page 5 Case III. Two Servo Presses with OACIS-2XC ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ £ Case IV. One Servo Press & One Nut Runner with OACIS-2XC ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○...
  • Page 6 DO NOT CONNECT ALL THE CABLES WITH POWER ON. All the wirings should be connected after switch off. Otherwise severe damage for the devices might happen.

  • Page 7: Hardware Installation

    ü Signal Type Selection Switch (ONLY AI#5, 6) needs to be set properly per the input signal type. l Allowable Signal Range with Input Setting Voltage Input Current Input ±10V 4~20mA OACIS – 2XC OACIS-2XC POWER CBL POWER CBL AMP CBL AMP CBL ANALOG IN 1~4 [V] +24VDC...
  • Page 8 Connect Home & Limit Sensors LIMIT SENSOR LIMIT SENSOR (PROXIMITY SENSOR) (PROXIMITY SENSOR) HOME SENSOR HOME SENSOR (CONTACT SENSOR) (CONTACT SENSOR) BROWN-24V BLACK -Sensing Signal BROWN-24V BLUE-0V BLUE-HOME Home sensor cable should be connected with power off. Connect Servo Motor and Drive. ü...
  • Page 9 Do not guide the encoder cable through the same duct as the power cable, nor bind them together. THREE PHASE DIRECT CURRENT 380V ±10% 24V ±10% +24V OACIS-2XC OACIS PROGRAM No. STEP No. POWER CABLE SERVO MOTOR SERVO DRIVE RS-232...

  • Page 11: Safety Circuits

    Safety Circuits ü The circuits should meet ISO standard safety requirement. -. EN ISO 13849-1 / 14121-1 -. EN/IEC 61508 -. EN/IEC 62061 ü Safety circuit example for Cat 3...
  • Page 12 Servo Drive...
  • Page 13 This circuit does not meet ISO standard safety requirement. It can cause severe damage to the operator or people who work for maintenance. So, any kinds of damage caused by this operation is not responsibility of ATA ü Potential quality related issues with stop and resume function.
  • Page 14 III. Software Installation Install OACIScom. ü Double click “…\OACIScom_v4.01.02.01\setup.exe” Special Settings for Window 7 ü Desktop → OACIScom Icon right click → Properties →Compatibility mode check → Privilege Level check...
  • Page 15 Connect to OACIS. ü PC IP Address needs to be set properly as shown below. It is strongly recommended that the Ethernet cable be directly connected to OACIS without any communication hub. Do not combine the network PLC and OACIS ü...
  • Page 16 Connect to EtherNet/IP Module OACIS-2XC ü EtherNet/IP module IP address needs to be set properly as shown below. ü Install ‘IP Config’ application and Run the program. n You can download ‘IP Config’ application from ATA or HMS website, https://www.anybus.com/support/file-doc-downloads/anybus-support- tools?orderCode=tools...
  • Page 17 ü Double-click on its entry in the list. And the network information will be updated if you click Set after changing IP address and subnet mask properly. ü Default IP address is 192.168.3.3 ü When the program runs, the network is automatically scanned for EtherNet/IP module products.
  • Page 18 IV.OACIS Power On Turn ON the Servo Drive & OACIS power after confirming a proper wiring. OACIS Check up the LoadCell ü With your hands, please press the shaft of servo press upward and downward. See the value of analog inputs is reasonable. OACIScom Confirm the Brake Wiring of Servo Motor.

  • Page 19: Servo Controller

    +24 VDC 0 VDC MOTOR BRAKE SERVO CONTROLLER OACIS BRAKE BRAKE COMMON Move Jog. ü You can move an axis forward or backward manually by operating COMMAND menu. It comes in quite handy when you build the machine up for the first time or some errors happen with high load.
  • Page 20 Homing. Select “OPERATING” tab on the Command window. ü...
