Summary of Contents for Muller Elektronik SMART-CPC
Page 1
Assembly Instructions SMART-CPC basic vehicle harness Version: V1.20200518 3032257601-02-EN Read and follow these instructions. Keep these instructions in a safe place for later reference. Please note that there might be a more recent version of these instructions on the homepage.
Table of contents Table of contents For your safety Basic safety instructions Intended use Layout and meaning of warnings Disposal Product description Connecting the basic vehicle harness Technical specifications V1.20200518...
For your safety Basic safety instructions For your safety Basic safety instructions Carefully read the following safety instructions before installing the basic vehicle harness. ▪ Only install the product if you are specially trained in the field of electronics. In all other cases, have the work performed by a specialist.
For your safety Disposal There are some actions that need to be performed in several steps. If there is a risk involved in carrying out any of these steps, a safety warning appears in the instructions themselves. Safety instructions always directly precede the step involving risk and can be identified by their bold font type and a signal word.
Product description Product description With the SMART-CPC basic vehicle harness, you can establish an interface on the vehicle between the SMART terminal and the ISOBUS job computer of the agricultural implement. This allows you to transmit data between the terminal and the job computer.
Connecting the basic vehicle harness Connecting the basic vehicle harness Distribution unit Prepared fuse holder with 20 A fuse Prepared fuse holder with 7.5 A fuse 16-pin AMP connector for connection to the job computer (cable length 2.5 m or 10 m) 3-pin implement connector for the 9-pin CPC connector for connection to...
Technical specifications Technical specifications Technical specifications Operating voltage 9-16 V Max. current consumption 15 A Max. output current on the CPC connector 5.5 A Pin assignment for 3-pin implement connector Signal Colour ∅ Black Ignition Pin assignment 9-pin CPC connector Signal Colour ∅...
Page 9
Technical specifications Pin assignment 16-pin AMP connector Signal Colour ∅ Wheel sensor White-green CAN_L Green TBC_RTN Black ECU_GND Blue Black Black Black Black Sprayer on/off White-yellow CAN_H Yellow TBC_PWR ECU_PWR Brown V1.20200518...
