Shappell S4000 Manual

REPLACEMENT PARTS
MODEL S4000 (58" x 92" Floor)
Part# Description
4000.1 Poly Cover
4000.2 Frame Assembly
4000.4 Floor Pole (only)
4000.5 Roof Tube (plain end)
4000.6 Roof Tube (formed end)
4000.7 Elastic Frame Cord
4000.8 Carpeting
4000.11 Roof Bow
SK4000 Skis
Accessories
IA2 Ice Anchors
NOTE: Small Holes, Tears and Cuts in Cover can be Repaired with Black and
Grey Duct Tape.
To Order Parts, give Part No., Description and Qty Needed.
SHAPPELL CORP., 3562 W. Jefferson Hwy., Grand Ledge, MI 48837
Toll Free (888) 571-1144
CONSUMER WARRANTY
SHAPPELL CORPORATION warrants its products against defects in material
and workmanship for (1) YEAR from date of purchase. We will provide FREE
repair or replacement, in whole or in part, at our option, for any product, found
in our opinion to be defective. If return is required, freight must be prepaid.
This warranty does not cover Freight Damage, Ordinary Wear and Tear, Abuse,
Misuse or Altered Product.
WINDOWS ARE NOT GUARANTEED AT TEMPERATURES BELOW
–15 DEGREES FAHRENHEIT.
For warranty claim, send letter indicating product and explanation of defect plus
dated proof of purchase to the SHAPPELL Corp., 3562 W. Jefferson Hwy,
Grand Ledge, MI 48837.
(10079)
4000.11
4000.5
4000.6
Revised 9-8-06
PORTABLE ICE FISHING SHELTER
4000.1
4000.2
4000.4
4000.8
IMPORTANT SAFETY INFORMATION
WARNING: Keep all Heat & Flame Sources away from the Shelter's Fabric
Cover. The Fabric Cover is Fire Retardant, it is not Fire Proof. The use of any
heat source can be extremely dangerous, both for Fire Hazard and Carbon
Monoxide Emissions. The Shappell Corporation does not endorse the use of any
Heater. It is the user's responsibility to follow the Instructions and Warnings
provided by the Heater Manufacturer for the safe use of a particular Heater.
C O
CARBON MONOXIDE POISONING HAZARD: This shelter is nearly air tight
and must be ventilated if using an oxygen consuming heat source. An extra zipper
pull at the top of each door provides ventilation and can also be used to form a
window for viewing. DO NOT PACK SNOW AROUND SHELTER or in any
way prevent fresh air from entering shelter. Failure to Ventilate Shelter could
create a Serious Health Hazard or Death.
Towing of shelter with a motorized vehicle is not recommended.
Windows can not be made to withstand temperatures below –15
PREVENT DAMAGE TO HINGE JOINT: Always set shelter on a level flat
surface.
MAINTENANCE: After each use, set up shelter until fabric is completely dry.
Never leave shelter folded closed with a wet cover.
NOTICE:
water repellency.
READ SETUP & TAKEDOWN INSTRUCTIONS BEFORE USING SHELTER
Model
It is normal for fabric to have some pinholes. This does not affect
S4000
o
F. (see warranty)
