Summary of Contents for Leon FLEX
- Page 1 FLEX MOUNT BRACKET I N S T A L L A T I O N G U I D E...
- Page 2 Questions? Call Customer Service 1.888.213.5015 Mon-Fri 8am-6pm EST Visit us online for product support, guides and videos www.leonspeakers.com/support...
- Page 3 FLEX : Flex Mount Bracket The Leon Flex Mount Bracket is a versatile speaker mounting system that provides freedom of adjustment in a minimized form factor. This bracket will also work with any small to medium size speaker with a flat back plate.
-
Page 4: Bracket Hardware
Bracket Hardware *Not to scale FlexMount Bracket : FLEX... -
Page 5: Parts List
~ Swivel Mount (installed on speaker) ~ Drywall Anchor ~ Bracket ~ Drywall or Wood Screw Parts List *Not to scale For assistance, call: 1.888.213.5015 | Mon-Fri 8am-6pm EST... - Page 6 Run Speaker Wire to mount location and level Bracket Plate to wall *Allow 12” of loose wire for easy install **Top of speaker is higher than top of plate when mounted Bracket Plate - 6 - FlexMount Bracket : FLEX...
- Page 7 Remove Bracket and drill* Pilot Holes *3/32” bit for Wood Screws *5/16” bit for Drywall Anchors - 7 - For assistance, call: 1.888.213.5015 | Mon-Fri 8am-6pm EST...
- Page 8 Attach Bracket Plate to wall with Wood Screws or Drywall Anchors *Thread Speaker Wire through Bracket Plate Drywall Anchor Drywall Screw Bonded Washer Wood Screw - 8 - FlexMount Bracket : FLEX...
- Page 9 Hang Speaker by placing Swivel Mount on Bracket Post *Ensure Wiring is clear of Bracket Post - 9 - For assistance, call: 1.888.213.5015 | Mon-Fri 8am-6pm EST...
- Page 10 Loosen Hex Bolts on Swivel Mount to adjust horizontal pan Loosen Hex Bolt on Bracket Post to adjust vertical tilt *Do not completely remove Hex Bolts *Re-tighten Hex Bolt once adjustment is complete - 10 - FlexMount Bracket : FLEX...
- Page 11 Connect Wiring to Speaker, tighten all screws and connections *Ensure correct +Positive/-Negative connections - 11 - For assistance, call: 1.888.213.5015 | Mon-Fri 8am-6pm EST...
- Page 12 715 W. Ellsworth Road Ann Arbor, Michigan 48108 | 1.888.213.5015 | www.leonspeakers.com...
