Summary of Contents for Fender COMPUGILIST
- Page 1 COM PUGI L I ST...
- Page 2 LEDs 9V DC INPUT TONE GAIN RECOVERY COMP BASS LEVEL BOOST LEVEL G.R. C OM PU G I LI ST DIST COMP 1. Distortion Bypass 9. Level (Compressor) 10. Gain Reduction LED Footswitch & LED 11. Input Jack 2. Output Jack 3.
- Page 3 Level controls, with a Gain Reduction indicator light. The Distortion side offers familiar Gain, Tone and Level controls. The Compugilist is a great way to get that classic “mastered” rock tone in a single pedal. DESIGNED IN CALIFORNIA, U.S.A.
- Page 4 Distortion Bypass Footswitch & LED Footswitch bypasses distortion effect. LED Illuminates when distortion effect is active. Level (Distortion) Controls overall distortion output level. Tone Similar to tone control on a guitar — turn counterclockwise to decrease treble frequencies; turn clockwise for full-range tone. Gain Controls amount of distortion added to signal.
-
Page 5: Input Jack
Input Jack High-impedance input suitable for electric guitar, bass, acoustic guitars with pickup systems, keyboards and other instruments. Output Jack Low-impedance output jack connects to amp or to next effect pedal in signal chain. DC Power Connector Standard center-negative 9VDC jack for use with appropriate power supplies. - Page 6 A PRODUCT OF: FENDER MUSICAL INSTRUMENTS CORPORATION CORONA, CALIFORNIA, USA Fender® is a registered trademark of FMIC. Copyright © 2019 FMIC. All rights reserved. P/N 7717097000 - REV 1 Important Safety Instructions •WARNING: To prevent damage, fire or shock hazard, do not expose the unit or its AC power to rain or moisture.
- Page 7 NOTES:...
- Page 8 © FENDER MUSICAL INSTRUMENTS 2019...
