- Page 1 Installation manual Mobeye Call-Key GSM Door Opener In combination with Mobeye Internet Portal SW version 7.n...
- Page 2 • Do not let it fall from height. • Do not use in an environment where any inflammable gases, vapours or dust are present or could be present. • Repair of the device may only be carried out by people, trained for Mobeye ® repair.
-
Page 3: Table Of Contents
Table of Content Introduction To get ready Place the SIM Card Connect a lock to the output Connect the power supply Sign up in the Mobeye Internet Portal Activate the SIM-card Activate the Mobeye device in the Portal 2.6.1 Installation code 2.6.2... -
Page 4: Introduction
1. INTRODUCTION The Mobeye Call-Key is a GSM door opener. The electronic door is connected to the relay output. Via an incoming call from an authorised number, the relay output will switch and the door or port is opened. The Mobeye Call-Key has two inputs for additional sensors. If one of these is activated, the set contact persons will receive a notification. -
Page 5: To Get Ready
10. See historical events 2.1 PLACE THE SIM CARD Use the Mobeye M2M SIM card which was included in the delivery. If no SIM card was included, please ask Mobeye (info@mobeye.eu). The SIM card needs to be inserted before the batteries. -
Page 6: Connect The Power Supply
LED flashes about 1 time per second. As soon as the connection is made, it will flash once in (about) 3 seconds. Optionally 4 batteries (4 * CR123) can be placed. If these are inserted, the Mobeye Call Key will send an alarm message in the event of a power failure. After sending the outage report the unit itself will go to the "Low Power”... -
Page 7: Activate The Sim-Card
2.5 ACTIVATE THE SIM-CARD First the Mobeye SIM card needs to be activated in the Mobeye Internet. At this point in time you confirm the subscription. Choose ‘activate new SIM card’. Enter the SIM card number. This is the number written on the plastic SIM card. Only take the last 8 digits of the last two lines (incl. -
Page 8: Activate The Mobeye Device In The Portal
Click ‘finish’. 2.6 ACTIVATE THE MOBEYE DEVICE IN THE PORTAL Next the Mobeye Call-Key can be activated in the portal. Be sure the SIM card was placed, the external power supply was connected and the GSM network connection was established.. - Page 9 If it takes longer than 5 minutes, the set-up was not done correctly; click ‘previous’ and try again. If it still does work, please contact Mobeye (info@mobeye.eu).. As soon as communication is set-up, next screen appears. 1. Enter a name for the device 2. Enter a location for the device Click “next”...
-
Page 10: Contacts, Contact Persons, User Groups And Users
Select a device and click it. Note: After entering the settings on the screen, these are not automatically programmed in the Mobeye Call Key. This only happens when you synchronize the data between the portal and the device. See section 2.8. - Page 11 Contacts are the people who can receive alarm messages or service messages from the Mobeye Internet Portal. It is an option, not obligatory, to set contact persons. It is possible to connect several people to the messages. It is possible to send alarm messages to a set of persons and the status messages to others.
- Page 12 User groups A user goup defined the access that users will be granted. Several user groups can be created, each having its own time window. User will be assigned to a user group. Before user will be authorised, at least one user group needs to be created. The users first need to be created as Contact (see before).
-
Page 13: Synchronisation Of Data From And To The Device
2.8 SYNCHRONISATION OF DATA FROM AND TO THE DEVICE Each hour the Mobeye Call-Key will pick-up new settings from and send log data to the portal. Only after the data exchange new authorised numbers will be able to open the door. -
Page 14: Additional Settings
• If an authorised number calls the number of the SIM card inside the Mobeye Call-Key, the output 1 switches for 10 seconds (pulse time). • If one of the inputs is activated by a sensor, the Mobeye Call-Key sends message to the alarm contacts numbers (others than authorised numbers!). -
Page 15: Installation Code
3.2 INSTALLATION CODE The installation code is the 4-digit code for programming the settings. The initial code is 1111. Please change the code to make the unit more secure. 3.3 OUTPUT BEHAVIOUR: SWITCH OR PULSE TIMES The time the output is activated can be set between 1 and 999 seconds. If the setting is set to 0, the output does not return to its previous state automatically. -
Page 16: Unauthorised Switching Of Output
3.10 UNAUTHORISED SWITCHING OF OUTPUT Although the Mobeye Call-Key is designed to only switch the output by an incoming call or SMS from an authorized phone, there is also an option to let them be switched by any incoming call/SMS, without being authorised. To disable the need for authorised numbers,... -
Page 17: Alternative Way Of Programming Via Sms Commands
3.11 ALTERNATIVE WAY OF PROGRAMMING VIA SMS COMMANDS In the event that the Internet Portal is out of order and the settings need to be changed, it is possible to change the settings via SMS commands. Please follow next steps: - Be sure the unit is connected to an external power supply - Send an SMS message with following content: CODE COMMAND:OPTION... -
Page 18: Action Rules
4. ACTION RULES The behaviour of the Mobeye Call-Key is programmed by action-reaction patterns. These so-called Action Rules are pre-programmed, according to the needs of many applications. However, it is possible to change these action rules (for advanced users only!). -
Page 19: Programming Action Rules
1111 IN1:O1ON • Do not forget the space between CODE and the TRIGGER. • The Mobeye MS100E will play a short melody to indicate a successful configuration. In case of a wrong command, a long beep will sound. 4.4 TIME-BASED ACTION RULES It is possible to let the action be daily performed at a certain time. -
Page 20: List Of Programmed Action Rules
4.5 LIST OF PROGRAMMED ACTION RULES A list of programmed action rules, the Action Rules List (ARL), can be requested by sending following SMS to the unit. Example: Request programmed action rules: 1111 ARLREPORT? CODE ARLREPORT? 4.6 DELETE ACTION RULES An action rule can be deleted by an SMS by the command below incl. -
Page 21: Reset The System
5. RESET THE SYSTEM A Mobeye Call-Key can be reset to its factory settings and be connected to another SIM card. It is also possible to assign a free number to a new device (verify that the contract type is correct). -
Page 22: Issue Solving And Technical Data
• Batteries: 4 x CR123 Lithium 3.0 V • Only battery operated, no external power: 50 μA, short peaks of max. 2 A • Externally powered 50 mA, short peaks of max. 2 A For support on technical problems regarding Mobeye Call-Key please contact info@mobeye.eu. - Page 23 Declaration of Conformity Herewith we, Mobeye, declare that the product Mobeye XM2 telemetry module And the derived products MS100, MS200, MS300, Call-Key are in compliance with the essential requirements of the following European standards / EU Directives: Directive 73/23/EEC (low voltage directive)
