- Page 1 Quick Start Guide 18.5” Widescreen Short Depth VGA LCD KVM Console GCL1900W PART NO. Q1602 www.iogear.com...
-
Page 2: Package Contents
Package Contents 1 x 18.5” Widescreen Short Depth VGA LCD KVM Console 1 x USB VGA KVM Cable 1 x Firmware Upgrade Cable 1 x Grounding Wire 1 x Power Cord 1 x Standard Rack Mounting Kit 1 x Quick Start Guide System Requirements Computers: •... - Page 3 Overview Front View Rear View GCL1900W 1. Upper Handle with Release Bar 10. Power LED 2. LCD Module 11. USB Port 3. LCD Controls 12. Touchpad 4. LCD ON/OFF Button 13. Keyboard Module 5. Firmware Upgrade Switch 14. Power Socket 6.
-
Page 4: Hardware Installation
Hardware Installation Standard Rack Mounting 1. Please use the included standard rack mounting kit to mount the GCL1900W in a rack with a depth of 16.5"-28.3" Note: a. We highly recommend two people to mount the module: one to hold it in place and the other person to screw the module in b. - Page 5 Hardware Installation Connecting Cables 1. Connect the VGA and audio connectors of the included KVM cable into the KVM ports located in the CPU section on the rear of the GCL1900W Note: The GCL1900W supports speakers only. It does not support microphones. Connect the KVM cable’s speaker jack (green) to the GCL1900W’s audio port 2.
-
Page 6: Operation
Operation Opening the Console 1. Pull on the Release bar on the Upper Handle 2. Slide the console module out until it clicks in place then raise the LCD Module lid Closing the Console 3. Lower the LCD Module until it lies flat and slide the full console in Operating Precautions The maximum load bearing capacity of the keyboard module is 66 lb. -
Page 7: Hotkey Commands
Hotkey Commands Combination Action [Ctrl][Alt][Shift][P][C][Enter] To select normal mode (PC, etc) [Ctrl][Alt][Shift][M][A][C][Enter] To select Mac [Ctrl][Alt][Shift][S][U][N][Enter] To select SUN [Ctrl][Alt][Shift][L][Enter] Activates the Firmware Upgrade Mode Note: this Hotkey sequence only works when the Firmware Upgrade Recovery Switch is in NORMAL position [Ctrl][Alt][Shift][L][Enter] Enable Local (LCD) console Disable 2nd console or external... -
Page 8: Limited Warranty
Limited Warranty This product carries a 3 Year Limited Warranty. For the terms and conditions of this warranty, please go to https://www.iogear.com/support/warranty Register online at https://www.iogear.com/register Important Product Information Product Model Serial Number... - Page 9 Contact WE’RE HERE TO HELP YOU! NEED ASSISTANCE SETTING UP THIS PRODUCT? Make sure you: 1. Visit www.iogear.com for more product information 2. Visit www.iogear.com/support for live help and product support IOGEAR https://iogear.custhelp.com support@iogear.com www.iogear.com...
-
Page 10: Emc Information
• Consult the dealer or an experienced radio/TV technician for help. CE Statement This device has been tested and found to comply with the following European Union directives: Electromagnetic Capability (2004/108/EC), Low Voltage (2006/95/EC) and R&TTED (1999/5/EC). © 2020 IOGEAR...
