Quick Start Guide
Planmeca PlanMill® 40 S
Guidelines for getting started with the Planmeca PlanMill 40 S
New mill purchase: after installation, verify you
have everything!
1 Accessories Kit (black box)
1 Defoamer Kit
1 Circulation Tank
Turning ON the Mill
Turning the software and mill OFF
The mill should remain ON during the week. Turn it OFF at the end of the week.
1. Touch the X in the top-right corner of the display. A verification screen appears, touch OK.
2. Close the lid if it is open. The lid stays closed while the mill runs its closing procedure. The lid
opens automatically, leave the lid open.
The desktop for the operating system (Windows) appears.
3. Ensure that all mill motor movement has stopped. Press and hold down the green power
button for approximately 10 seconds. This process will prompt the operating system (Windows)
to shut down.
The screen and red button will go dark.
Starting a milling job
Download the User Manual!
Press the green button on the front of the mill to turn it ON.
When the mill software loads, the initializing screen appears. Close the lid firmly and wait for
the software to automatically load.
Pending Jobs list is the default screen.
1. Touch the desired job to select it.
2. The system opens the lid and prompts you to insert the block that matches the material
and block size selected in the Design software.
3. Lock the block into place firmly with the T-handle and close the lid.
Inserting the blocks
Vertical Orientation - notch
points to the bottom-right
Go to planmecacadcam.com/material-bank to digitally download the Planmeca PlanMIll 40 S
User Manual or call 800.537.6070 to request a printed copy.
1 E4D Starter Kit
1 Premier Starter Kit*
1 Ivoclar Vivadent Starter Kit*
*If purchased, these kits are shipped separately by their manufacturer.
Horizontal Orientation -
notch points to the top-right
