PROMARKS TM-1500 Operation Manual

Vacuum tumbling machine

Advertisement

Quick Links

ISO 9001:2000
TM-1500
Vacuum Tumbling Machine
Operation Manual
PROMARKS INC U.S.A.
1599 Monte Vista Ave., Claremont CA 91711 U.S.A
TEL:(909)482-1133
FAX:(909)482-1633

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TM-1500 and is the answer not in the manual?

Questions and answers

Summary of Contents for PROMARKS TM-1500

  • Page 1 ISO 9001:2000 TM-1500 Vacuum Tumbling Machine Operation Manual PROMARKS INC U.S.A. 1599 Monte Vista Ave., Claremont CA 91711 U.S.A TEL:(909)482-1133 FAX:(909)482-1633...
  • Page 2: Table Of Contents

    INDEX 1. Installation ………………………………………………………………………………2 2. Maintenance …………………………………………………………………… ………2 3. Functions and operations …………………………………………………… ………2 4. Control panel …………………………………………………………………… ……3-4 5. Machine diagram ……………………………………………………………… ………5 6. Electrical diagram …………………………………………………………… ………6 7. Machine operation explain………………………………………………………………7 8. Typical vacuum control settings…………………………………………………………8 9. Replacement parts……………………………………………………………………9-15 8.1 Drum body diagram………………………………………………………………10-11 8.2 Machine case diagram ……………………………………………………12-13...
  • Page 3: Installation

    1. INSTALLATION. Please check the electric power listed on the vacuum pump and install the vacuum pump correctly, ground line must on the floor. 2. MAINTENANCE. A. To ensure vacuum pump works smoothly suggest change the vacuum oil every 500 working hours or every a half year.
  • Page 4: Control Panel

    4.CONTROL PANEL. PV-03 CONTROL PANEL ○ ○ ○ 1 Control panel 6 Program number up 10 Edit ○ ○ ○ 2 Program number 7 Program number down 11 Shift / Save value ○ ○ 3 Function value 8 Increase value ○...
  • Page 5 ○ 4 : To start / pause machine function by pressing Start / Pause button. ● Start/Pause ○ Stop 5 : Ends current cycle in process and skip to ventilation. ○ Program number up 6 : Program number goes up by pressing button.
  • Page 6: Machine Diagram

    5.MACHINE DIAGRAM Model Capacity TM-1500 1900 1565 2280 1700 Φ1250 700Kg Machine Case Vacuum Cover Drum Body...
  • Page 7: Electrical Diagram

    6.ELECTRICAL DIAGRAM.
  • Page 8: Machine Operation Explain

    7.MACHINE OPERATION EXPLAIN. Check the right power source with the name plate of the machine. Plug in the power and ready to operate the machine. Turn on main power switch and set the value on control panel. After finish all of the setting push down the safety bar and press “Start/Pause”...
  • Page 9: Typical Vacuum Control Settings

    8. Typical vacuum control settings. % OF CTRL SPEED PRODUCTS TUMBLING TIME VACUUM SETTING RPM 10 1/2 Boneless chicken breast 15 min 10 1/2 Boneless pork chops 15 min 7 1/2 Rufy fillet 12~24 min 6 1/2 Whitefish fillet on 5 off 5 on 5 done 6 1/2 Peeled &...
  • Page 10: Replacement Parts

    Vacuum Tumbling Machine Drum Body Control Box Machine Case...
  • Page 12 Drum Body Part List Name Quantity Parts No Note Vacuum lid SD100224010D Lid gasket PA0410200100 Nozzle SD100228010D Nozzle cap SD100201010E Spring washer NA0806000001 Washer NA0706000001 Screw NA0406001501 Hex head Oil sealer BA0503020080 Retaining ring QA2223191010 10 Socket PD300012010D 11 Drum body SD100217010D 12 Screw NA0406002501 Hex head...
  • Page 14 Machine Case Part List Name Quantity Parts No Note Name Quantity Parts No Note 1 Machine Case SD300232010E 22 Nipple CA0208005022 2 Locker QA3100401010 23 Femal tee connector CA0408008010 3 Washer NA0720000001 24 Nipple CA0208015020 4 Screw nut NA1020000001 25 Pipe clamp QA1118323100 5 Vacuum pump TA0001433100...
  • Page 16 Control Box Part List Name Quantity Parts No Note 1 Control panel HA1303020300 2 Sensor switch EA3621000000 3 Main power switch HA2502020000 4 Select switch EA2202200200 5 Select switch EA2202200200 6 Invertor EA5203022011 Vacuum pump 7 Joystick EB1303010000 8 Contactor EA1602125200 Motor 9 Overload relay EA1702030000...
