- Page 1 Saltwater Chlorination System - Installation and Operation Guide Models: RJ16 RJ20 RJ30 RJ45 RJ60 RJ-Classic Series Salt Systems Advanced Swimming Pool Sanitation...
-
Page 2: Table Of Contents
TABLE OF CONTENTS SAFETY INSTRUCTIONS INTRODUCTION GETTING STARTED SYSTEM OVERVIEW WATER CHEMISTRY & SALT LEVELS Preparing the Pool Water Ideal Salt Level & Pool Size Adding Salt Ideal Water Chemistry Levels OPERATION How it Works Initial Start Up General Operation Using the Control Module LED Indicator Lights MAINTENANCE... -
Page 3: Safety Instructions
Save all instructions. When installing and using this electrical equipment, basic safety precautions should always be followed, including the following. • WARNING: Follow all aspects of local and National Electrical Code(s) when installing the CircuPool RJ Series. Disconnect all electrical power during installation & service. •... -
Page 4: Introduction
Please choose your installer with great care! Be sure to familiarize yourself with the pool chemistry requirements and maintenance procedures. Please visit www. circupool.com/help for more information, tips, and troubleshooting assistance. -
Page 5: System Overview
RJ SERIES SYSTEM OVERVIEW RJ-Series The Generation system utilizes two main components for operation: Control Module: This component supplies power to the Cell and allows you to customize the system's operation in order to meet your pool's unique needs. Electrolytic Cell: This component creates chlorine as the water inside passes through and returns to the pool. -
Page 6: Water Chemistry & Salt Levels
WATER CHEMISTRY & SALT LEVELS Preparing the Pool Water RJ-Series It is important that the pool's water chemistry is balanced before the is powered on and used. In order for the system to be able to work, there must be a minimum level of salt in the pool water, see “Salt Levels”... -
Page 7: Adding Salt
Adding Salt IMPORTANT: Before adding salt at any time, ALWAYS perform an independent water test to measure pre-existing salt levels. If the salt level (PPM) in your pool is currently… 1000 1500 2000 2500 3000 3500 4000 4,000 6,000 8,000 10,000 12,000 14,000... -
Page 8: Ideal Water Chemistry Levels
Ideal Water Chemistry Levels It is important to maintain these chemistry levels in order to ensure that the pool can be enjoyed safely, to minimize the amount of effort required to sanitize the water, and to prevent corrosion or scaling. The only unique requirement for a pool with a chlorine generator is the low level of salt (salinity) to be maintained in the water. -
Page 9: Operation
OPERATION How it works RJ-Series Think of the as a chlorine generator; set it to create a steady supply of chlorine for the pool, instead of buying and adding chlorine by hand. How it works: Using electrolysis, it creates chlorine from the salt molecules (NaCL) in your water in order to sanitize your pool. -
Page 10: Using The Control Module
CONTROL BUTTONS: 1) ON/OFF : For normal operation, the system should be left in the “On” position. In this position, the CircuPool RJ Series will produce chlorine according to the desired output %. When using an external timer to provide power, the system will return to the last settings entered each time power is restored. -
Page 11: Led Indicator Lights
Polarity two. This reading may also vary somewhat from independent tests done at the pool store or at poolside. Most electronic testers are subject to a variation of up to fifteen percent. The CircuPool unit works well in a wide salinity range so a great deal of precision is not required. High salt conditions will not harm your CircuPool unit. -
Page 12: Maintenance
MAINTENANCE Expected Maintenance Monitor your pool’s salinity level as frequently as you check your other water chemistry levels. After the system has run for a time, your Cell will eventually need to be cleaned due to natural mineral scaling. The system will notify you of this by turning on the “Water Fault”... -
Page 13: General Maintenance
When the titanium blades inside the Electrolytic Cell have reached the end of their lifespan, replacements are readily available so that the whole system does not have to be replaced. Replacements are easily switched out. To ensure quality and value, only genuine CircuPool replacement parts may be used. -
Page 14: Installation
INSTALLATION RJ-Series IMPORTANT: If you haven’t already done so, it is necessary to balance the pool's water chemistry before the powered on and used. See pages 6 - 8 for more information. The following are guidelines for the typical installation using 2” plumbing, which should be performed by a qualified individual. If 1.5”... -
Page 15: Installing The Electrolytic Cell And Flow Switch
Installing the Electrolytic Cell The Cell is to be fitted into the return line as the last piece of equipment the water passes through before returning to the pool: always after the pump, filter, heater (if applicable), etc. If a heater is present, all equipment must be a minimum distance away, per heater manufacturer recommendations. -
Page 16: Installing The Control Module
Wiring CAUTION: Power must be shut off at the circuit breaker before performing any wiring. Be sure to follow local and NEC/CEC electrical codes. The system has been designed to easily wire into typical in-ground pool systems. To provide safe operation, the unit must be properly grounded and bonded. For operation, the Control Module must be wired in to the pump's power source so that both turn on and off together (see diagram below). - Page 17 Wiring (Continued) For use with Variable Speed Pumps: When used with variable-speed or other electronically controlled pumps, use a timer to coordinate SJ run time with full-flow pump operation. Power Protection Mechanism: The Control Module has a power protection mechanism, an external Fuse Reset button located on underside of unit.
-
Page 18: Voltage Conversion
VOLTAGE CONVERSION Always double-check the voltage of your power source. Connection to improper voltage can: a) cause severe damage/harm, or b) cause lights and screen to power on without system function. All service should only be attempted by a person with appropriate electrical skills, with all equipment disconnected from power. -
Page 19: Installation Checklist
INSTALLATION CHECKLIST □ Barrel Unions installed and glued into pipe work. □ Titanium Blade assembly is fitted tightly into the cell housing. □ All three Threaded collars on Cell are hand tight. □ Mounting Bracket is affixed to wall or support. □... -
Page 20: Helpful Hints
HELPFUL HINTS For more detailed information and useful tips, visit www.circupool.com/help. Proper operation of the chlorine generator can be easily verified by checking the lights on the control panel. However, if the pool remains cloudy, or the chlorine residual tests low, then the chlorine being produced is being lost due to high chlorine demand or improper water conditions. -
Page 21: Troubleshooting
TROUBLESHOOTING For more detailed information and extensive troubleshooting, visit www.circupool.com/help. Power LED and LCD Screen Not Turning On • Double verify whether connected to 120 or 240 VAC input power • Verify connection internally to the proper screw terminals. • Verify input voltage with a voltmeter. -
Page 22: Warranty
2. Should a defect in any item or part covered by the warranty become evident during the warranty's term, CircuPool Products will at its sole discretion repair or replace such item or part. CircuPool Products reserves the right to replace defective parts with new or refurbished parts. - Page 23 RJ Series Owner's Manual Notes:...
- Page 24 Notes:...
