Luis 7"-System Basic Operating Manual page 27

4.2. LUIS BASIC CAMERA
4.2.1. VIEW
4.2.2. TECHNICAL DATA
Produkt
Sensor
Resolution
View angle
Protection class
Light sensitivity
Backlight compensation
Working voltage
Current consumption
Working temperatur
Video out signal
Power consumption
Measures (H x B X T)
incl. mount
weight (Camera and mount)
Basic Camera
1/3 CMOS-Color-Sensor
600 TV-Lines
120°
IP68
0,1Lux (0 Lux if IR LEDs on)
Automatic
12-24 V
Max. 250mA
-20 °C bis +70 °C
1.0Vp-p 75 Ohms
2W
42 x 69 x 58 mm
87 x 78 x 64 mm
280 g
27
