INSTRUCTION MANUAL
MODEL NO:
DL8071
TODDLER
UPC CODE:
BED
0-65857-19823-2
NOTE:
THIS INSTRUCTION BOOKLET
CONTAINS IMPORTANT SAFETY
INFORMATION. PLEASE
READ AND KEEP FOR
FUTURE REFERENCE.
LOT NUMBER:
(LOCATED ON CARTON)
DATE OF PURCHASE:
______ / ______ / ______
DO NOT RETURN PRODUCT TO THE RETAILER
If a part is missing or damaged, Contact our
customer service department. We will
replace the part FREE of charge.
Tel # : 1-800-295-1980
E-Mail: das@dorel.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DL8071 and is the answer not in the manual?

Questions and answers

Summary of Contents for Dorel Living DL8071

  • Page 1 INSTRUCTION MANUAL MODEL NO: DL8071 TODDLER UPC CODE: 0-65857-19823-2 NOTE: THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE. LOT NUMBER: (LOCATED ON CARTON) DATE OF PURCHASE: ______ / ______ / ______ DO NOT RETURN PRODUCT TO THE RETAILER If a part is missing or damaged, Contact our customer service department.
  • Page 2: Customer Service

    CUSTOMER SERVICE You can also contact us by writing to the address listed below. Please include the product model number, color and a detailed description of your enquiry. Dorel Living - Customer Service Department 12345 Albert-Hudon Boulevard, Suite 100 Montreal, Quebec...
  • Page 3: Care, Cleaning And Maintenance

    CARE, CLEANING AND MAINTENANCE Dust regularly with a soft, lint-free cloth to prevent soil build-up. A damp cloth may be used occasionally to clean surface. Dry immediately. Do not use any abrasives that may damage finish. Excessive exposure to sunlight and extreme changes in temperature and moisture can damage wood furniture.
  • Page 4: Hardware List

    TODDLER BED DL8071 HARDWARE LIST HARDWARE LIST HARDWARE LIST HARDWARE LIST Ø 1/4" x 2-1/2" Ø 1/4" x 1-3/4" Ø 1/4" x 2-1/2" Ø 1/4" x 1-3/4" ∅ ∅ 1/4" x 2-3/4" 1/4" x 1-3/4" Ø 1/4" x 2-1/2" Ø...
  • Page 5: Parts List

    TODDLER BED DL8071 PARTS LIST HEADBOARD POST HEADBOARD TOP HEADBOARD PANEL 2 PCS 1 PC 1 PC HEADBOARD BOTTOM RAIL FOOTBOARD POST FOOTBOARD PANEL 1 PC 2 PCS 1 PC LEFT SIDE RAIL RIGHT SIDE RAIL GUARDRAIL 1 PC 1 PC...
  • Page 6 TODDLER BED DL8071 STEP 1 Attach headboard top (B) to headboard post (A) using bolt (2) as shown. Use the Allen Key (4) to tighten the bolt. NOTE: Do not fully tighten the bolts. Leaving the bolts loose will facilitate assembly in the following steps.
  • Page 7 TODDLER BED DL8071 STEP 2 Insert stoppers (7) into the groove of headboard bottom rail (D) as shown. Insert wood dowel (5) into the headboard bottom rail (D). Attach headboard bottom rail (D) to headboard post (A). Ensure the headboard panel (C) is in the groove of bottom rail (D).
  • Page 8 TODDLER BED DL8071 STEP 3 Insert wood dowel (5) into the post (A) as shown. Attach headboard post (A) to the top (B) and rail (D) with bolts (1 & 2). Use the Allen Key (4) to tighten the bolts.
  • Page 9 TODDLER BED DL8071 STEP 4 Insert wood dowels (5) to the footboard panel (F). Attach footboard posts (E) to panel (F) with bolt (1). Use the Allen key (4) to tighten the bolts.
  • Page 10 TODDLER BED DL8071 STEP 5 Insert barrel nuts (3) into side rails (G & H) as shown. Attach side rails (G & H) to the headboard with bolts (1) Use the Allen key (4) to tighten the bolts (1). NOTE: The barrel nut (3) can be rotated using a screwdriver (not included) to properly align...
  • Page 11 TODDLER BED DL8071 STEP 6 Insert barrel nuts (3) into center support slat (J) as shown. Ensure the barrel nuts (3) are flush with center support slat (J). Attach center support slat (J) to side rails (G & H) with bolts (1). Use the Allen Key (4) to tighten bolts (1).
  • Page 12 TODDLER BED DL8071 STEP 7 Insert barrel nuts (3) into side rails (G & H) as shown. Attach the footboard to the side rails (G & H) with bolts (1). Use the Allen key (4) to tighten bolts (1). NOTE: Do not fully tighten the bolts. This will facilitate assembly in the following steps.
  • Page 13 TODDLER BED DL8071 STEP 8 Insert wood dowels (6) into wide and narrow slats (K & L) as shown. Attach slats (K & L ) to side rails (G & H). Tighten all bolts previously installed.
  • Page 14 TODDLER BED DL8071 STEP 9 Attach guardrails (I) to headboard posts (A) and side rails (G & H) with bolts (1 & 2) as shown. Use the Allen key (4) to tighten bolts (1 & 2).
  • Page 15 TODDLER BED DL8071 CAUTION: This unit is intended for use only with the products and/or maximum weights indicated. Use with other products and/or products heavier than the maximum weights indicated may result in instability or cause possible injury. NEVER use bed with...
  • Page 16 MANUAL DE INSTRUCCIONES Modelo No: DL8071 CAMA PARA NIÑOS PEQUEÑOS CODIGO UPC 0-65857-19823-2 NOTA: ESTE MANUAL DE INSTRUCCIONES CONTIENE INFORMACIÓN DE SEGURIDAD IMPORTANTE. POR FAVOR LÉALA Y CONSÉRVELA PARA REFERENCIA FUTURA. Numero de lote: (TOMADO DEL CARTON) ___________________ Fecha de compra: _______ / _______ / _______ NO DEVUELVA EL PRODUCTO A LA TIENDA.
  • Page 17: Servicio Al Cliente

    También puede contactarnos escribiendo a la dirección que figura a continuación. Por favor incluya el número de modelo del producto, el color y una descripción detallada de su pregunta. Dorel Living - Customer Service Department 12345 Albert-Hudon Boulevard, Suite 100...
  • Page 18: Garantía Limitada De 1 Año

    CUIDADO, LIMPIEZA Y MANTENIMIENTO Límpiela regularmente con un paño suave para evitar la acumulación de suciedad. Ocasionalmente se puede usar un paño húmedo para limpiar la superficie. Séquela inmediatamente. No utilice productos abrasivos que puedan dañar la terminación. Una exposición excesiva a la luz del sol y a cambios extremos de temperatura y humedad puede dañar los muebles de madera.
  • Page 19: Hardware List

    CAMA PARA NIÑOS PEQUEÑOS DL8071 HARDWARE LIST HARDWARE LIST LISTA DE ACCESORIOS HARDWARE LIST Ø 1/4" x 2-1/2" Ø 1/4" x 1-3/4" Ø 1/4" x 2-1/2" Ø 1/4" x 1-3/4" ∅ ∅ 1/4" x 2-3/4" 1/4" x 1-3/4" Ø 1/4" x 2-1/2"...
  • Page 20: Lista De Piezas

    CAMA PARA NIÑOS PEQUEÑOS DL8071 LISTA DE PIEZAS PARTE SUPERIOR DE LA POSTE DE LA CABECERA PANEL DE LA CABACERA CABECERA 2 PZAS 1 PZA 1 PZA RIEL INFERIOR DE LA POSTE DEL REPOSAPIÉS PANEL DEL REPOSAPIÉS CABECERA 2 PZAS...
  • Page 21 CAMA PARA NIÑOS PEQUEÑOS DL8071 ETAPA 1 Fije la parte superior de la cabecera (B) al poste de la cabecera (A) usando el perno (2) como se muestra. Use la llave Allen (4) para apretar el perno. NOTA: No apriete completamente los pernos. Los pernos sueltos facilitarán el montaje en las siguientes etapas.
  • Page 22 CAMA PARA NIÑOS PEQUEÑOS DL8071 ETAPA 2 Inserte los topes (7) en la ranura del riel inferior de la cabecera (D) como se muestra. Inserte la espiga de madera (5) en el riel inferior de la cabecera (D). Fije el riel inferior de la cabecera (D) al poste de la cabecera (A). Asegúrese de que el panel de la cabecera (C) esté...
  • Page 23 CAMA PARA NIÑOS PEQUEÑOS DL8071 ETAPA 3 Inserte la espiga de madera (5) en el poste (A) como se muestra. Fije el poste de la cabecera (A) a la parte superior de lal cabecera (B) y al riel inferior (D) con los pernos (1 y 2).
  • Page 24 CAMA PARA NIÑOS PEQUEÑOS DL8071 ETAPA 4 Inserte las clavijas de madera (5) en el panel del reposapiés (F). Fije los postes del reposapiés (E) al panel (F) con el perno (1). Use la llave Allen (4) para apretar los pernos.
  • Page 25 CAMA PARA NIÑOS PEQUEÑOS DL8071 ETAPA 5 Inserte las tuercas de barril (3) en los rieles laterales (G y H) como se muestra. Fije los rieles laterales (G y H) a la cabecera con los pernos (1) Use la llave Allen (4) para apretar los pernos (1).
  • Page 26 CAMA PARA NIÑOS PEQUEÑOS DL8071 ETAPA 6 Inserte las tuercas de barril (3) en el listón de soporte central (J) como se muestra. Asegúrese de que las tuercas de barril (3) estén al ras con el listón de soporte central (J).
  • Page 27 CAMA PARA NIÑOS PEQUEÑOS DL8071 ETAPA 7 Inserte las tuercas del barril (3) en los rieles laterales (G y H) como se muestra. Fije el reposapiés a los rieles laterales (G y H) con los pernos (1). Use la llave Allen (4) para apretar los pernos (1).
  • Page 28 CAMA PARA NIÑOS PEQUEÑOS DL8071 ETAPA 8 Inserte las clavijas de madera (6) en los listones anchos y estrechos (K y L) como se muestra. Fije los listones (K y L) a los rieles laterales (G y H). Apriete todos los pernos previamente instalados.
  • Page 29 CAMA PARA NIÑOS PEQUEÑOS DL8071 ETAPA 9 Fije las barandillas (I) a los postes de la cabecera (A) y a los rieles laterales (G y H) con los pernos (1 y 2) como se muestra. Use la llave Allen (4) para apretar los pernos (1 y 2).
  • Page 30 CAMA PARA NIÑOS PEQUEÑOS DL8071 PRECAUCIÓN: Esta unidad está diseñada para ser utilizada únicamente con los productos y/o pesos máximos indicados. Su uso con otros productos y/o productos más pesados que los pesos máximos indicados puede provocar inestabilidad o causar lesiones Nunca utilice la cama para pequeños para niños menores...
  • Page 31: Manuel D'instructions

    MANUEL D'INSTRUCTIONS Modèle No: DL8071 LIT POUR JEUNES ENFANTS CODE CUP: 0-65857-19823-2 NOTE: CE LIVRET D'INSTRUCTIONS CONTIENT DES INFORMATIONS IMPORTANTES SUR LA SÉCURITÉ. S.V.P. LIRE ET CONSERVER POUR RÉFÉRENCE ULTÉRIEURE. Numéro de lot (SITUE SUR LA BOÎTE) ___________________ Date d'achat: _______ / _______ / _______ NE PAS RETOURNER LE PRODUIT AU DETAILLANT.
  • Page 32: Service À La Clientèle

    Vous pouvez également nous contacter en écrivant à l'adresse ci-dessous. S'il vous plaît inclure le numéro de modèle du produit, la couleur et une description détaillée de votre demande. Dorel Living - Customer Service Department 12345 Albert-Hudon Boulevard, Suite 100...
  • Page 33 SOIN, NETTOYAGE ET ENTRETIEN Époussetez régulièrement avec un chiffon doux, non pelucheux, pour empêcher la poussière de s'accumuler. Un chiffon humide peut être utilisé à l'occasion pour nettoyer la surface. Séchez immédiatement. Ne pas utiliser des produits abrasifs pouvant endommager la finition. Une exposition excessive à la lumière du soleil, à des changements extrêmes de température et à...
  • Page 34 LIT POUR JEUNES ENFANTS DL8071 HARDWARE LIST HARDWARE LIST LISTE DE QUINCAILLERIE HARDWARE LIST Ø 1/4" x 2-1/2" Ø 1/4" x 1-3/4" Ø 1/4" x 2-1/2" Ø 1/4" x 1-3/4" ∅ ∅ 1/4" x 2-3/4" 1/4" x 1-3/4" Ø 1/4" x 2-1/2"...
  • Page 35: Liste De Pièces

    LIT POUR JEUNES ENFANTS DL8071 LISTE DE PIÈCES POTEAU DE LA TÊTE DE LIT HAUT DE LA TÊTE DE LIT PANNEAU DE LA TÊTE DE LIT 2 PCES 1 PCE 1 PCE RAIL INFÉRIEURE DE LA TÊTE POTEAU DE MARCHEPIED...
  • Page 36 LIT POUR JEUNES ENFANTS DL8071 ÉTAPE 1 Fixez le haut de la tête de lit (B) à son poteau (A) à l’aide du boulon (2) comme indiqué. Utilisez la clé Allen (4) pour serrer le boulon. NOTE: Ne serrez pas complètement les boulons. Laisser les boulons desserrés facilitera l'assemblage dans les étapes suivantes.
  • Page 37 LIT POUR JEUNES ENFANTS DL8071 ÉTAPE 2 Insérez les butées (7) dans la rainure du rail inférieur de la tête de lit (D) comme indiqué. Insérez la cheville en bois (5) dans le rail inférieur de la tête de lit (D).
  • Page 38 LIT POUR JEUNES ENFANTS DL8071 ÉTAPE 3 Insérez le goujon en bois (5) dans le poteau (A) comme indiqué. Fixez le poteau de la tête de lit (A) au haut de la tête de lit (B) et au le rail inférieur (D) à...
  • Page 39 LIT POUR JEUNES ENFANTS DL8071 ÉTAPE 4 Insérez des goujons en bois (5) dans le panneau de marchepied (F). Fixez les poteaux de marchepied (E) au panneau (F) à l’aide du boulon (1). Utilisez la clé Allen (4) pour serrer les boulons.
  • Page 40 LIT POUR JEUNES ENFANTS DL8071 ÉTAPE 5 Insérez les écrous à tête cylindrique (3) dans les rails latéraux (G & H) comme indiqué. Fixez les rails latéraux (G & H) à la tête de lit avec des boulons (1) Utilisez la clé Allen (4) pour serrer les boulons (1).
  • Page 41 LIT POUR JEUNES ENFANTS DL8071 ÉTAPE 6 Insérez les écrous à tête cylindrique (3) dans la latte de support centrale (J), comme indiqué. Assurez-vous que les écrous (3) son a niveau avec la latte de support centrale (J). Fixez la latte de support centrale (J) aux rails latéraux (G & H) à l’aide des boulons (1).
  • Page 42 LIT POUR JEUNES ENFANTS DL8071 ÉTAPE 7 Insérez les écrous à tête cylindrique(3) dans les rails latéraux (G & H) comme indiqué. Fixez le marchepied aux rails latéraux (G & H) à l’aide des boulons (1). Utilisez la clé Allen (4) pour serrer les boulons (1).
  • Page 43 LIT POUR JEUNES ENFANTS DL8071 ÉTAPE 8 Insérez les goujons en bois (6) dans les lattes larges et étroites (K & L) comme indiqué. Fixez les lattes (K & L) aux rails latéraux (G & H). Serrer tous les boulons précédemment installés.
  • Page 44 LIT POUR JEUNES ENFANTS DL8071 ÉTAPE 9 Fixez les barrières de sécurité (I) aux poteauxs de la tête de lit (A) et aux rails latéraux (G & H) à l’aide des boulons (1 et 2) comme indiqué. Utilisez la clé Allen (4) pour serrer les boulons (1 & 2).
  • Page 45 LIT POUR JEUNES ENFANTS DL8071 ATTENTION: Cette unité est conçue pour être utilisée uniquement avec les produits et/ou les poids maximum indiqués. L'utilisation avec d'autres produits et/ou des produits plus lourds que les poids maximum indiqués peut causer de l'instabilité ou des blessures.
