- Page 1 Slinger® Slingshot T-One Launcher & Oscillator USER MANUAL ® Designed and Developed by Slinger®. Patent Pending. Covered by International Patent Applications 2709 N. Rolling Road Suite 138 Windsor Mill 21244 MD...
- Page 2 Slingshot T-One Tennis Ball launcher. Thousands of hours of design, prototyping and both off and on-court testing have gone into making your Slinger® Launcher a performance piece of tennis equipment and providing you with an ideal partner for practice sessions, court drills or workouts.
- Page 3 The serial number can be found here: CAUTION CONSUMER SAFETY INFORMATION Please note that Slinger Slingshot T-One Launcher operates through a 12V Lithium battery and by definition is an electrically operated machine. Please ensure that the power is switched to “OFF” and unplugged from any electrical connection before attempting any activity which involves reaching into the launcher mechanism for any reason including for maintenance or cleaning.
- Page 4 AT ALL TIMES THE USER MUST NOT UNDER ANY CIRCUMSTANCES: • Reach into the ball launching exit chute when the power is “ON” • Look into the ball launching exit chute when the power is “ON” • Stand directly in front of the ball launching exit chute at any time when the power is “ON” •...
- Page 5 WARNING To reduce the risk of electrical shock, fire, injury to persons, and other damage when using this product, please follow these basic safety precautions. 1. Read all instructions carefully before operating this launcher. 2. To protect against the risk of electrical shock, never immerse any part of this launcher in water or any other liquid.
- Page 6 THE GLOBAL COMPLIANCE User Guide 06/20...
- Page 7 User Guide 06/20...
- Page 8 THE GLOBAL COMPLIANCE This product complies with applicable requirements for performance, construction, labelling and information. EUROPEAN COMPLIANCE As indicated by this symbol, disposal of this product is governed by Directive 2012/19/EU of the European Parliament and of the Council on waste electrical and electronic equipment (WEEE). WEEE could potentially prove harmful to the environment and as such the Directive requires that the battery in this product must not be disposed of as unsorted municipal waste, but rather col- lected separately and disposed of in accordance with local WEEE ordinances and guidelines.
- Page 9 Slinger Tennis Balls. Please avoid using either old or soft tennis balls as this will reduce performance of the Launcher. The SLINGSHOT T-ONE LAUNCHER is designer for use by tennis players of all ages and abilities. The SLINGSHOT T-ONE LAUNCHER weighs 15kg or 33 lbs (excluding tennis balls). It is one of the lightest performance ball launchers of its kind on the market.
- Page 10 SLINGSHOT T-ONE LAUNCHER AT A GLANCE & 8 1 0 9 User Guide 06/20...
- Page 11 SLINGSHOT T-ONE LAUNCHER AT A GLANCE 1. EXTENDABLE 2. CLIP ON CAMERA 3. TELESCOPIC BALL 4. USB PHONE CHARGING TROLLEY HANDLE HOLDER PORT (LOCATED INSIDE POCKET) PICK-UP TUBE HOLDER CLIP* 5. SIDE POCKET 6. SIDE CARRY STRAPS 7. BALL ELEVATION KNOB 8.
- Page 12 GETTING STARTED The Slinger® Slingshot T-One Launcher battery is shipped at a maximum 30% charge in accor- dance with federal requirements for shipment of Lithium Batteries. BATTERY Before using the Launcher for the first time please make sure that the battery is left to charge overnight in order to optimize the battery life.
- Page 13 ELEVATION BAR The elevation bar gives the user an option to change the launching angle of the ball – the launching angle ranges between 10 and 40 degrees. 1. Open the side pocket 2. Rotate the knob clockwise to release the bar 3.
- Page 14 45mph / 73kmph ball with tournament level topspin. 7. SPEAKER: A beep sounds when operating the launcher as follows: •Short Beep: When turning the Slingshot T-One Launcher on. •Short Beep: When pressing the remote On / Off. •Long Beep: 15 seconds after pressing the on switch to ‘ON’ position indicating that the feeder has started rotating.
- Page 15 CONTROLS User Guide 06/20...
- Page 16 QUICK START SLINGSHOT T-ONE LAUNCHER ONLY Only after the battery has been fully charged (as per above) can the Slingshot T-One Launcher be used on the court. Please then follow these quick start operations: 1. Position Slingshot T-One Launcher on the court in your desired launching position. See suggested positions based on level of play (below).
- Page 17 1. Position the Oscillator on the court in your desired launching position. See suggested positions based on level of play. 2. Make sure that the Slinger® logo on the top of the Oscillator is facing forwards to the net and the wheel location slots are at the rear.
- Page 18 15. The first ball may take 10 seconds to fire. 16. Start playing. REMOTE CONTROL INSTRUCTIONS IMPORTANT: Your Slingshot T-One Launcher cannot operate without the remote control for safety reasons. Please DO NOT misplace the remote. The remote has 2 buttons:...
- Page 19 BATTERY L.E.D. INDICATORS Battery L.E.D. lights will illuminate to indicate level of battery power as follows (looking at the control panel): • Red indicates low power •Yellow indicates medium power. • Green indicates medium to full power To ensure proper performance of the battery: •...
- Page 20 Battery L.E.D.’s Indicator Oscillator L.E.D. User Guide 06/20...
- Page 21 NOTE: Poor quality or condition of the tennis balls used and the outdoor weather conditions will also affect the need to adjust the court placement. The illustrations below can be used as a reference for locating the Slingshot T-One on the court for ground strokes drills / practice.
- Page 22 User Guide 06/20...
- Page 23 User Guide 06/20...
- Page 24 REPLACING THE BATTERY • Please visit wwww.slingerbag.com/FAQ • Open 4 screws of the battery compartment (on the left side tof the launcher). • Pull the drawer a little up and out of the launcher. • Carefully release the Electrical connector. •...
- Page 25 Follow these steps to charge the battery using the smart cable charger. • Before shipping, every Slingshot T-One Launcher is fully QC tested. As a result, there could be some residual ball fuzz inside or on your Launcher and/or other marks as a result of this testing.
- Page 26 TROUBLESHOOTING For more information visit: www.slingerbag.com/FAQ WARNING: PLEASE MAKE SURE THAT THE LAUNCHER POWER IS IN ‘OFF’ POSITION BEFORE INVESTIGATING ANY ISSUES For additional or specific help please email support@slingerbag.com ACTION TO REQUIRED CAUSE PROBLEM Ball is not launched A ball is jammed TURN OFF POWER and remove any jammed balls from the feeder plate.
- Page 27 ACTION TO REQUIRED CAUSE PROBLEM Loud noise and / or Loose elevation bar knob Tighten the elevation knob vibration Battery Not Charging Charger cable is not fully in- Check all connections. and has no light when serted in control panel Check power socket adapter is connected to a power correctly selected and connected.
