- Page 1 ASSEMBLY INSTRUCTIONS Articulating Keyboard Tray Lot Code # NEED HELP? Call 1−800−950−4782 www.bbffits.com Part Number A163898B Keep manual for future reference.
-
Page 2: Important Safety Information
IMPORTANT SAFETY INFORMATION A163898B WARNING This shelf is intened for keyboard use only. Other use may cause instability, collapse, and/or tip over resulting in serious injury. Esta tablilla ha sido diseñada para el uso del teclado solamenta. Otro uso de la tablilla puede causar... -
Page 3: Exploded View
EXPLODED VIEW A163898B Articulating Keyboard Assembly S164746 [ 1 ] S163755 Keyboard Mechanism [ 1 ]... - Page 4 FASTENERS A163898B Fasteners are shown in actual size. Los fijadores son demonstrados en su tamaño actual. Les attaches sont montrées dans l'échelle grandeur. [ 8 ] H93264 #10 x 5/8" [ 4 ] H164745 M5 - .8 x 16mm [ 4 ] H164744 Acorn Nut M5 - .8...
- Page 5 A163898B HARDWARE [ 1 ] H93178 Rubber stop [ 1 ] H163758 Mouse fence [ 1 ] H163754 Plastic stop [ 1 ] H163867 Lock out key [ 4 ] H163757 Anti skid pad [ 1 ] H163756 Mouse pad...
- Page 6 MODEL SPECIFIC A163898B AC99889 [ 1 ] H93180 Track (Long) AC99888 [ 1 ] H161806 Track (Short)
- Page 7 STEP A163898B [ 2 ] [ 1 ] #10 x 5/8" Rubber stop Surface can have additional holes. Superficie puede tener agujeros adicionales. La surface peut avoir des trous supplémentaires. AC99889 AC99888 [ 1 ] [ 1 ] Track (Long)
- Page 8 STEP A163898B [ 4 ] #10 x 5/8" AC99889 Screws are self tapping. Los tornillos son autorroscantes. Les vis sont auto taraudage. AC99888...
- Page 9 STEP A163898B AC99889 Remove and save screw. AC99888 Retire y guarde el tornillo. Retirez et conservez la vis.
- Page 10 STEP A163898B [ 4 ] M5 - .8 x 16mm [ 4 ] Acorn Nut M5 - .8...
- Page 11 STEP A163898B...
- Page 12 STEP A163898B [ 3 ] [ 1 ] #10 x 5/8" Plastic stop Screws are self tapping. Los tornillos son autorroscantes. Les vis sont auto taraudage.
- Page 13 STEP A163898B [ 2 ] Cord clip Optional Opcional Optionnel...
- Page 14 STEP A163898B [ 4 ] Anti skid pad Apply to underside of keyboard. Aplicar a la parte inferior del teclado. Appliquer au dessous du clavier. [ 1 ] [ 1 ] Mouse fence Mouse pad Optional location ubicación Opcional emplacement optionnel...
- Page 15 STEP A163898B...
- Page 16 STEP A163898B Maximum Weight: 16 Lbs. Peso Máximo: 16 Libras Poids Maximum: 7.25 kilogramme...
