MZDV2 Car Video Interface
On-Car Installation Guide
MZDV2 interface of cable link-1
Infotainment
System
Original
Cable
MZDV2 of Main Cable
18pin
M-Connector
to AM
MZDV2 of Main Cable
28pin
M-Connector
to BF
18pin
F-Connector
AF
Original
Cable
18pin
M-Connector
AM
18pin
M-Connector
to AF
28pin
F-Connector
to BM
28pin
F-Connector
BF
28pin
M-Connector
BM
