MZDV2
M u l t i m e d i a I n t e r f a c e
Installation
Guide
for
Car model:
All New MAZDA-2
All New MAZDA-3
All New MAZDA-CX3
All New MAZDA-CX5
All New MAZDA-MX5
All New MAZDA-6
Contents
1. Multimedia Interface x1
2. Main cable x1
3. NAVI RGB cable x1
4. Video cable(w/power) x4
5. AUX Audio cable x1
6. Audio cable x1
7. CCD+LVDS cable x1
Double
Intelligence
Technology
http://www.navi-tuner.com
1. Multimedia Interface
2. Main cable
3. NAVI RGB cable
4. Video cable
5. AUX Audio cable
(w/power)
6. Audio cable
7. CCD+LVDS cable
P1
Cables' Connection
Multimedia Interface
Main
DVR
DTV F-CCD GPS
R-CCD
1
2
3
4
5
6
(Main Body)
(Monitor)
Original
Infotainment
System
P2
LVDS
AUX
Audio
7
8
