- Page 1 User Manual HDBT70RxP HDBaseT Receiver All Rights Reserved Version: HDBT70RxP_2016V1.0...
- Page 2 HDBaseT Receiver SAFETY PRECAUTIONS To insure the best from the product, please read all instructions carefully before using the device. Save this manual for further reference. Unpack the equipment carefully and save the original box and packing material for possible future shipment ...
- Page 3 Please refer to the dealers for the latest details. This manual is copyright Eurosound. All rights reserved. No part of this publication may be copied or reproduced without the prior written consent of Eurosound.
-
Page 4: Table Of Contents
HDBaseT Receiver Table of Contents 1. Introduction ......................... 1 1.1 Introduction to HDBT70RxP ................1 1.2 Features ......................1 1.3 Packing List ....................... 1 2. Panel Description ......................2 3. System Connection ..................... 4 3.1 Usage Precautions .................... 4 3.2 System Diagram ....................4 3.3 Connection Procedure .................. -
Page 5: Introduction
1. Introduction 1.1 Introduction to HDBT70RxP HDBT70RxP is a mini-size HDBaseT Receiver which adopts HDBaseT technology to receive high-resolution 1080p/ 4k signal from HDBaseT transmitter via a CAT5e/CAT6a cable at a distance of up to 70/40m. Moreover, it support CEC, bi-directional RS232&IR control, and bi-directional PoH function. -
Page 6: Panel Description
HDBaseT Receiver 2. Panel Description LINK HDCP Name Description HDBT Link status indicator: OFF: No Link ① LINK GREEN:Link Successful Blinking GREEN: Link abnormal HDCP compliant indicator OFF: No HDMI traffic (no picture) ② HDCP GREEN: Traffic with HDCP. - Page 7 HDBaseT Receiver Connect with power supply (Not necessary if HDBaseT Transmitter ⑨ DC 24V connects with power). Pictures shown in this manual are only for reference.
-
Page 8: System Connection
Step2. Connect HDBT OUT port of HDBaseT Transmitter and HDBT IN port of HDBT70RxP, with single CAT5e/CAT6a cable. Step3. Connect HDMI displayer (such as HDTV) to HDMI OUT port of HDBT70RxP with HDMI cable. Step4. Both HDBaseT Transmitter and HDBT70RxP have IR IN and OUT. When one end is used as an IR receiver, the signal sent from the end can only be transmitted via the other end. -
Page 9: Application
For example: When “IR IN” of HDBaseT Transmitter connects with an IR receiver, the IR emitter must connect to IR OUT of HDBT70RxP. Step5. Connect the RS232 port of the devices to be controlled and the HDBT70RxP or the HDBaseT Transmitter. -
Page 10: Specification
HDBaseT Receiver 4. Specification Input& Output 1 IR (3.5mm mini jack) Input 1 HDBT (RJ-45) 1 RS232 (3-pin pluggable terminal block) 1 HDMI (HDMI female) Output 1 IR (3.5mm mini jack) 1RS232 (3-pin pluggable terminal block) General Video Signal HDMI 1.4 and HDCP2.2 compliant Audio Signal Digital audio, transmit through HDMI audio Resolution Range... -
Page 11: Supported Resolution
HDBaseT Receiver 4.1 Supported Resolution Aspect Ratio Resolution Refresh Rate 4096x2160 30Hz 4Kx 2K 3840x2160 24/25/30Hz 1920x1080 60Hz 1600x900 60Hz 16:9 1366x768 60Hz 1280x720 60Hz 1024x576 60Hz 1920x1200 60Hz 1680x1050 60Hz 16:10 1360x768 60Hz 1280x800 60Hz 1600x1200 60/65/70/75/85Hz 1280x1024 60/75/85/96Hz 1024x768 60/70/75/85Hz 800x600... -
Page 12: Panel Drawing
HDBaseT Receiver 5. Panel Drawing LINK HDCP 115 mm... -
Page 13: Troubleshooting & Maintenance
HDBaseT Receiver 6. Troubleshooting & Maintenance No image on display: Ensure that the display device has been set to the correct input. Ensure that the HDMI cables used for both the source/transmitter and the receiver/display are properly connected and are working. Test the HDMI cables directly from a source to display and ensure their operation. -
Page 14: After-Sales Service
Any transport costs are borne by the users during the warranty. 1) Product Limited Warranty: Eurosound warrants that its products will be free from defects in materials and workmanship for one years, which starts from the first day the product leaves warehouse (The purchase invoice shall prevail).
