Ip Remote Access Case Study - US Robotics Total Control NETServer/16 Command Reference Manual

IP Remote Access Case Study

UserA, UserB and UserC will be dialing to connect with the
local network. UserC will be a dialback user.
This case study assumes the following:
The configuration will take place from the Command Line
The NETServer has the correct IP address and netmask
All other settings remain at factory defaults
Configure the ports
This example will use ports 3 and 4 to answer calls from dial in
user. In order to accommodate the dialback user, port 4 will also
be configured for dial out.
When users connect to the port, the NETServer will greet them.
Although the greeting says the same thing. Port 3 will write it
all on one line, while port 4 will split it up over three lines.
IP Remote Access Case Study
set s3 network dialin
set s4 network twoway
set s3 message Welcome to the Computer Center
set s4 message Welcome^to the^Computer Center
Network Dial In Access 5-11
