Aquablu One Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Manual
Aquablu One
Manufactured in The Netherlands

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the One and is the answer not in the manual?

Questions and answers

Related Manuals for Aquablu One

Summary of Contents for Aquablu One

  • Page 1 Manual Aquablu One Manufactured in The Netherlands...
  • Page 2 In spite of its simplicity, it is essential that the system is correctly installed, maintained and used. Please allow yourself sufficient time to read and understand this manual, before you install, maintain or use the Aquablu One. With proper installation and regular maintenance, the system will provide many years of reliable service, protecting you and your family.

  • Page 3: Table Of Contents

    What is in the box? How does it work? What is under the bonnet? System overview How does it communicate? Installing your Aquablu One - Mechanical Installation - Hydraulic Installation - Electric Installation - Commissioning Using and supervising the system...

  • Page 4: Health And Safety Instructions

    Do not operate a purification system that has not been properly maintained or equipped. • Do not mount any purification system components on unsafe or unstable surfaces. This Aquablu equipment does not have an ATEX certification and must NOT be operated in hazardous or potentially explosive environments. Innovative purification solutions www.aquablu.com...

  • Page 5: What Is In The Box

    Fig. 1a: Pre-Filtration Unit Fig. 1b: Pre-filtration elements The standard inserts of the pre-filtration unit are one activated carbon cartridge and one string wound filter which prevent any particles larger than 5 micron and chlorine to harm the membrane. See figure 1b for their identification. The filters can be easily removed for replacement purposes.
  • Page 6 Each system can be identified by means of a Unit ID (serial number) which can be found by making contact with NFC using your Aquablu phone app. If no phone is near you the serial number tag can be found at the bottom of the system. See Fig. 3 for the appearance of the tag.
  • Page 7 Fig 5: DC Power Supply 4. MINERAL CARTRIDGE (OPTIONAL) The mineral cartridge consists of one canister that contains essential minerals that can be added to the filtered water to enhance the taste and add beneficial minerals (PH level) to your purified water.
  • Page 8 Aquablu purification system. The faucet is supplied in a separate box that contains the faucet, a mounting console and hardware. In the faucet a circular signal lamp is fitted to inform the operator about the status of the purification system. See Fig. 7 for the appearance of the Aquablu LED Faucet.

  • Page 9: How Does It Work

    At this entry point also a temperature sensor and a non-return valve are fitted. Innovative purification solutions www.aquablu.com...
  • Page 10 From the purification unit the water is led through the mineral cartridge (optionally) and from the mineral cartridge to the water faucet. See figure 8 for an explanation of the valve block. Fig. 8: Valve block Innovative purification solutions www.aquablu.com...

  • Page 11: What Is Under The Bonnet

    What is under the bonnet? To give an impression of the relative simplicity and compactness of the Aquablu One, see figures 9a and 9b below for an overview of the major components in the unit. Fig. 9a: Right hand side view of unit with the outer cover removed Fig.

  • Page 12: System Overview

    By monitoring flow, quality, pressure and temperature of your water, our systems give you insight into the quality of your drinking water. NFC allows information readout though our Aquablu app and ensures worldwide service and system control. Rejected water flows out of the system.

  • Page 13: How Does It Communicate

    Aquablu service partner without any additional costs or effort. On top of that, the Aquablu One is also fitted with a multi color light and a LED indication on tap level which indicate the system status in a more conventional way.
  • Page 14 No need for thick manuals or unnecessary maintenance visits. The answer is right in your hand. OFFLINE & ONLINE The NFC does not require internet, allowing the dealer to service the system in remote locations. The App automatically sends the info when back online. Innovative purification solutions www.aquablu.com...
  • Page 15 See figure 11c below for the location of the controls Fig. 11: Overview of controls Once the Aquablu One is connected to the power adapter it is always “on”. Therefore the only way to completely turn off the system is by disconnecting the 24 V DC power adapter.
  • Page 16 Audible signals are only used in “emergency” situations, where immediate action of the operator is required. The possible sound patterns are: Constant Intermittent Quick The different error codes and required actions can be found on page 26-29. Innovative purification solutions www.aquablu.com...

  • Page 17: Installing Your Aquablu One

    Installing your Aquablu One The installation of the system can be divided in four stages: Mechanical installation Hydraulic installation Electrical connection Commissioning 1. Mechanical installation The mechanical installation consist of installing the filtration unit, the mineral cartridge and the LED water faucet.
  • Page 18 It is advised to insert the water hose that connects the water faucet with the mineral cartridge into the push-in coupling of the water faucet before you fix it to your sink. Once installed, the fitting can be difficult to reach. See chapter “Hydraulic installation” for further instructions. Innovative purification solutions www.aquablu.com...
  • Page 19 Fig.15: Correctly mounted water faucet 11. Turn the screw in with the Allan key provided until tight. Please do not over tighten the screw to prevent any accidental damage. 12. The mechanical installation of the water faucet is ready. Innovative purification solutions www.aquablu.com...

  • Page 20: Hydraulic Installation

    With the kit two of screw/push-in connectors are supplied to connect the system to the water supply, and to the drain system. See figure 17 below for their appearance and application. Fig. 17: Screw on connection Innovative purification solutions www.aquablu.com...
  • Page 21 3 bar maximum. The screw/push in connector must be attached to the low pressure side of the pressure reducer. The pressure reducer can be bought at the Aquablu web shop. INSTALLATION IN AREAS WITH LOW WATER PRESSURE BELOW 1.5 BAR In installations where the pressure on the input side of the purification unit is below 1.5 bar, it is...
  • Page 22 10 mm diameter hose must be securely fitted to the push-in coupling side of the coupling. The other end of the hose must be securely fitted to the push-in coupling of the reject water port of the purification unit. Innovative purification solutions www.aquablu.com...
  • Page 23 Make sure to install all cables in such a manner that they are not in contact or exposed to a heat source and cannot be accidently be pulled off the system. See figure 19 below for an illustration of a completed purification system with all components arranged in the correct order. Fig. 19: System overview Innovative purification solutions www.aquablu.com...

  • Page 24: Commissioning

    If the process is complete, fasten the vent plugs hand tight. Open the Aquablu faucet. Press and hold the mode button on the rear of the unit.

  • Page 25: Using And Supervising The System

    Using and supervising the system Innovative purification solutions www.aquablu.com...
  • Page 26 Using and supervising the system Using the Aquablu system is convenient and easy as it only requires the use of the water faucet, and enjoying the safety and good taste provided by the Aquablu One unit. The system is designed in such a way that routine checks and regeneration of the membrane is taken care of by the system itself.

  • Page 27: Troubleshooting The System

    Unit ID to your closest dealer or Aquablu HQ and we help you further. Always make sure to update the App to have the latest version.
  • Page 28 Light on water faucet steady blue, light on unit yellow triple flash in combi- nation with a continuous sound Status: Water production has run for more than 8.5 minutes. REQUIRED ACTION Close the tap. If not closed within 30 seconds the unit will stop automatically. Innovative purification solutions www.aquablu.com...
  • Page 29 INDICATION: Light on water faucet blinking blue, light on the unit blinking yellow with one intermittent sound. Status: Membrane is blocking the flow of purified water. Membrane is starting to block due to fouling of the membrane REQUIRED ACTION Operator is to interrupt power supply and to replace the membrane.
  • Page 30 2. The unit should automatically start bacteria flushing and auto-restore to standby. 3. When this indication returns immediately after resetting the temperature of the feed water is still too high and has to drop below the temperature threshold. Innovative purification solutions www.aquablu.com...

  • Page 31: Servicing The System

    Unpack the new filter insert, and place in the container. The particle filter can be fitted with either side up, the carbon filter (black) needs to be fitted with the seal on one end pointing upwards as shown in figure 1b on page 4.
  • Page 32 The replacement intervals are dependent on the degree of water contamination and will typically vary between one and two years. To keep track of the replacement intervals it is advised to scan the NFC chip and let the aquablu App show you when to replace the filters. If suddenly the replacement intervals significantly shorten, it is advised to contact your local dealer.
  • Page 33 On the membrane an arrow is placed, the membrane should be inserted in the direction of the arrow. In case of doubt, see figure 24 for the correct membrane position. Innovative purification solutions www.aquablu.com...
  • Page 34 Open the feed water supply again and reconnect the power supply to the machine. The machine will enter the commissioning mode. Look in the chapter “commissioning” for an explanation of this procedure. Innovative purification solutions www.aquablu.com...
  • Page 35 HOW TO PROPERLY STORE A WORKING MEMBRANE FILTER When the Aquablu unit is not connected to power supply for a longer period of time, the membrane should be taken out and stored properly to avoid contamination and termination of the membrane. No power supply means the system cannot take care of the membrane itself as no automatic back flush can be performed.

  • Page 36: Service History

    Service History 0) Installing and commissioning the system 1) Replacing carbon pre filter 2) changing particle pre filter 3) changing membrane 4) Replacing mineral Cartridge 5) Dealer inspection/repair Action Date - Month - Year By (name) Remarks Innovative purification solutions www.aquablu.com...
  • Page 37 Extra notes: Action Date - Month - Year By (name) Remarks Innovative purification solutions www.aquablu.com...

  • Page 38: Decommissioning The System

    Max. Hardness 180 mg CaCO3/L or 10°DH *NTU = Nephelometric Turbidity Units **TDS = Total Dissolved Solids *** PPM = Parts per million **** uS/cm = Microsiemens per centimeter Warranty Card & Serial Number: Manual version: 1001 Innovative purification solutions www.aquablu.com...

  • Page 39: Warranty

    If Aquablu replaces the prod- uct, the warranty will become invalid. Exclusions In the event any of the following matters result in system failure to, Aquablu will reject any war- ranty claim and its complementary costs: •...
  • Page 40 Aquablu water purifier system. Aquablu shall not be liable for loss of goods, loss of use, or any special, indirect, or pure eco- nomic loss, costs, damages, charges or expenses except for liability that Aquablu is not allowed to exclude by law.

  • Page 41: Declaration Of Conformity

    Name: Aquablu Addres: ‘s Gravendamseweg 53, 2215TC Voorhout, the Netherlands Details Equipment: Water treatment solutions Model types: One, Pro, Custom Tradenames: Aquablu Reviewed Guide lines and standards 1. Equipment guide line 2006/42/EC (EN12100) 2. LVD guide line 2006/95/EC (EN60204-1, NEN3140, (NEN1010) 3.

  • Page 42: The Small Print

    Contact the Aquablu Innovative purification solutions technical department in case extra information is required, for example, maintenance and repair.
  • Page 43 After installation, you will experience the convenience of having an Aquablu system at home. Aquablu’s purifiers are no ordinary purifiers. They can truly be relied upon as a friend. We deliver a maximum of one filter package per installation.
  • Page 44 Just pure, even better. member of Stokvis Group...
