- Page 1 Manual Aquablu Pro Manufactured in The Netherlands...
- Page 2 Please allow yourself sufficient time to read and understand this manual, before you install, maintain or use the Aquablu Pro. With proper installation and regular maintenance, the system will provide many years of reliable service, protecting you and your family.
-
Page 3: Table Of Contents
DANGER / WARNING This symbol indicates situations of serious danger which, if ignored, may result in serious risks to the health and safety. IMPORTANT This symbol indicates important and technical information Innovative purification solutions www.aquablu.com... -
Page 4: Health And Safety Instructions
Do not operate a purification system that has not been properly maintained or equipped. • Do not mount any purification system components on unsafe or unstable surfaces. This Aquablu equipment does not have an ATEX certification and must NOT be operated in hazardous or potentially explosive environments. Innovative purification solutions www.aquablu.com... -
Page 5: What Is In The Box
The instructions in this manual are not a substitute for, but a supplement to the applicable local health and safety regulations. What is in the box? 1. GENERAL The Aquablu Pro purification system consists the following parts, delivered in two separate boxes: Box 1: Box 2: •... - Page 6 Care must be taken during installation that the filters are installed in the correct order. Starting from the inlet side, first filter is the 20 micron string wound element, second the activated carbon block cartridge and third the 5 micron sting wound filter element. Innovative purification solutions www.aquablu.com...
- Page 7 Each system can be identified by means of a Unit ID (serial number) which can be found by making contact with NFC using your Aquablu phone app. If no phone is near you the serial number tag can be found at the bottom of the system. See Fig. 3 for the appearance of the tag.
-
Page 8: How Does It Work
From the entry point the feed water is pushed under feed water pressure to an electrical pump that forces the feed water under high pressure through the membrane. Pump pressure is monitored in the pressure line to the membrane, while pump motor current is also measured as a process parameter. Innovative purification solutions www.aquablu.com... - Page 9 When placed as a vending or whole house solution the water will go to a permeate tank. See figure 8 for an explanation of the valve block. Fig. 8: Valve block Innovative purification solutions www.aquablu.com...
-
Page 10: What Is Under The Bonnet
What is under the bonnet? To give an impression of the relative simplicity and compactness of the Aquablu Pro see figure 9a below for an overview of the major components in the unit. Fig. 9a Front view of unit with cover plate removed. -
Page 11: System Overview
In water mains fed systems, the reject water may under no circumstances be fed back into the system. Not observing this may cause a serious health hazard to the water mains system! Discard the reject water in the sewage system or (preferably) in a grey water system. Innovative purification solutions www.aquablu.com... -
Page 12: How Does It Communicate
Aquablu service partner without any additional costs or effort. On top of that, the Aquablu Pro is also fitted with a multi color light and a LED indication on tap level which indicate the system status in a more conventional way. - Page 13 No need for thick manuals or unnecessary maintenance visits. The answer is right in your hand. OFFLINE & ONLINE The NFC does not require internet, allowing the dealer to service the system in remote locations. The App automatically sends the info when back online. Innovative purification solutions www.aquablu.com...
- Page 14 The default “no problem” standby status is a steady green light. Audible signals Audible signals are only used in “emergency” situations, where immediate action of the operator is required. The possible sound patterns are: Constant Intermittent Quick Innovative purification solutions www.aquablu.com...
-
Page 15: How To Install It
How do I install it? The installation of a complete Aquablu Pro solution includes as mentioned three main stages of water treatment. Pre-filtration, purification and post-filtration. Besides the treatment equipment a variation of feed, respectively storage tanks as well as feed and/or booster pumps may be required. - Page 16 Please install the unit as close to horizontal as possible to prevent air gapes. It is advised to fit the filter cartridges to the unit at this stage. Starting with 20 micron, the activated carbon and 5 micron filter. MOUNTING THE AQUABLU PRO PURIFIER Fig. 13 Installation dimensions Function...
-
Page 17: Hydraulic Installation
Hydraulic installation The Aquablu Pro system can be used in different ways. For direct flow (single tap) installation follow guide 1. For a whole house solution please follow installation guide 2. Mineral Water cartridge faucet Pre- Aquablu Whole house solution... - Page 18 Only follow this step if you have purchased an additional mineral cartridge with your Aquablu Pro. Connect the Aquablu pro with a 15 mm hose using a threaded G 3/4” M - 15 mm push-in connector. Use a 15 - 12 mm converter to connect the Aquablu Pro with the mineral cartridge.
- Page 19 8. CONNECTING THE POST FILTRATATION TO YOUR MAIN WATER PIPE A threaded G 3/4” connection is supplied in the kit to connect the post filtration to your water pipe. The connection with your water pipe can vary and need to be sourced locally. Innovative purification solutions www.aquablu.com...
- Page 20 Tube). To protect the O-ring, do not over tighten. Tightly connect the 4-pin Electrical Socket with the UV Lamp pins. Carefully insert the UV Lamp into the Quartz Tube through Open End Nut. Install the Protective Cap on the Open End Nut by hand. Innovative purification solutions www.aquablu.com...
- Page 21 To save the energy, turn off the power and water supply if you do not use the equipment for a long time. POST FILTRATION Attach the post filtration after the permeate tank. This filtration is installed similarly to the pre- filtration unit. The post-filtration consists of one housing containing a Activated carbon (AC) filter. Innovative purification solutions www.aquablu.com...
-
Page 22: Commissioning The System
Purifier is still at “0”. THE COMMISSIONING SEQUENCE BELOW MUST BE FOLLOWED TO LETTER. Use these commissioning steps if you connect the Aquablu Pro to a tap (direct flow) Open the raw water supply (feed water). Slowly fill the pre-filtration unit with water by slightly opening the vent plugs (Flathead screw on top of the filtration head) until it is completely filled. - Page 23 Use these commissioning steps if you connect the Aquablu Pro to a water tank. Open the raw water supply (feed water). Slowly fill the pre-filtration unit with water by slightly opening the vent plugs (Flathead screw on top of the filtration head) until it is completely filled. Follow this process with the pre-filters one after the other, be prepared that there will be some water coming out.
-
Page 24: Using And Supervising The System
In essence using the system consists of operating the water faucet, and enjoying the safety and good taste provided by the Aquablu Pro unit. The system is designed in such a way that routine checks and regeneration of the membrane is taken care of by the system itself. -
Page 25: Troubleshooting The System
Unit ID to your closest dealer or Aquablu HQ and we help you further. Always make sure to update the App to have the latest version. - Page 26 Light on water faucet steady blue, light on unit yellow triple flash in combi- nation with a continuous sound Status: Water production has run for more than 8.5 minutes. REQUIRED ACTION Close the tap. If not closed within 30 seconds the unit will stop automatically. Innovative purification solutions www.aquablu.com...
- Page 27 See Chapter “Installation” INDICATION: Light on water faucet steady red, purple light on the unit in combination with intermittent sound Innovative purification solutions www.aquablu.com...
- Page 28 When this indication returns immediately after resetting a service technician should be called. INDICATION: Light on water faucet steady red, red Single (1) flash in combination with continuous sound Status: Feed water temperature too high (over 40°C) REQUIRED ACTION 1. Operator to interrupt power supply, and reconnect. Innovative purification solutions www.aquablu.com...
-
Page 29: Servicing The System
Check if the tap is still open. Connect the power supply again. The system will directly perform a flush. To reset the remin counter in the machine, please click the black button at the back of the machine, 3 Innovative purification solutions www.aquablu.com... - Page 30 To keep track of the replacement intervals it is advised to scan the NFC chip and let the aquablu App show you when to replace the filters. If suddenly the replacement intervals significantly shorten, it is advised to contact your local dealer.
- Page 31 See figure 23 below for the membrane removal sequence. Fig. 23: Removal sequence of the membrane Put the old membrane aside for discarding. If difficulties are encountered with removing the membrane as described, a pipe wrench or suitable pair of pliers may be used. Innovative purification solutions www.aquablu.com...
- Page 32 Open the feed water supply again and reconnect the power supply to the machine. The machine will enter the commissioning mode. Look in the chapter “commissioning” for an explanation of this procedure. Innovative purification solutions www.aquablu.com...
- Page 33 HOW TO PROPERLY STORE A WORKING MEMBRANE FILTER When the Aquablu unit is not connected to power supply for a longer period of time, the membrane should be taken out and stored properly to avoid contamination and termination of the membrane. No power supply means the system cannot take care of the membrane itself as no automatic back-flush can be performed.
-
Page 34: Service History
Service History 0) Installing and commissioning the system 1) Replacing carbon pre filter 2) changing particle pre filter 3) changing membrane 4) Replacing mineral Cartridge 5) Dealer inspection/repair Action Date - Month - Year By (name) Remarks Innovative purification solutions www.aquablu.com... -
Page 35: Technical Data
Purified water volume at 25°C 100 to 240 litres a hour Max. Hardness 180 mg CaCO3/L or 10°DH *NTU = Nephelometric Turbidity Units **TDS = Total Dissolved Solids *** PPM = Parts per million **** uS/cm = Microsiemens per centimeter Innovative purification solutions www.aquablu.com... -
Page 36: Warranty
Aquablu agrees to correct the cost of repair of parts and labour. Any parts replaced during the repair will become the property of Aquablu. If in the opinion of Aquablu, a water purifier is beyond economic repair, Aquablu reserves the right to provide customers with a new product of equivalent specification. - Page 37 Aquablu water purifier system. Aquablu shall not be liable for loss of goods, loss of use, or any special, indirect, or pure economic loss, costs, damages, charges or expenses except for liability that Aquablu is not allowed to exclude by law.
-
Page 38: Declaration Of Conformity
Aquablu Addres: ‘s Gravendamseweg 53, 2215TC Voorhout, the Netherlands Details Equipment: Water treatment solutions Model types: One, Pro, Custom Tradenames: Aquablu Reviewed Guide lines and standards 1. Equipment guide line 2006/42/EC (EN12100) 2. LVD guide line 2006/95/EC (EN60204-1, NEN3140, (NEN1010) 3. -
Page 39: The Small Print
This User Manual has been created with great care, however Aquablu Innovative purification solutions cannot be held responsible for errors in this publication or for the impact of any of these possible errors. This User Manual has... - Page 40 Just pure, even better. member of Stokvis Group...
