ADC Unshielded Specification Sheet page 4

O r d e r i n g I n f o r m a t i o n
Description
24 AWG STC
Unshielded Riser
Jacket color: Gray
Packaging: Reel
*To designate reel length,
replace XX as follows:
02 = 304 m (1000 ft)
04 = 609 m (2000 ft)
05 = 762 m (2500 ft)
06 = 914 m (3000 ft)
10 = 1524 m (5000 ft)
Web Site: www.adc.com
From North America, Call Toll Free: 1-800-366-3891 • Outside of North America: +1-952-938-8080
Fax: +1-952-917-3237 • For a listing of ADC's global sales office locations, please refer to our web site.
ADC Telecommunications, Inc., P.O. Box 1101, Minneapolis, Minnesota USA 55440-1101
Specifications published here are current as of the date of publication of this document. Because we are continuously
improving our products, ADC reserves the right to change specifications without prior notice. At any time, you may
verify product specifications by contacting our headquarters office in Minneapolis. ADC Telecommunications, Inc.
views its patent portfolio as an important corporate asset and vigorously enforces its patents. Products orfeatures
contained herein may be covered by one or more U.S. or foreign patents. An Equal Opportunity Employer
101308AE 9/06 Original © 2006 ADC Telecommunications, Inc. All Rights Reserved
Number Unit
of Pairs Makeup
2 None
3 None
4 None
5 None
6 None
8 None
10 None
12 None
16 None
20 None
25 None
32 1 @ 25, 1 @ 7
40 2 @ 20
50 2 @ 12, 2 @ 13
75 3 @ 25
100 4 @ 25
125 5 @ 25
150 6 @ 25
175 7 @ 25
200 8 @ 25
Outer Weight
Diameter Kg/Km
mm (inches) (lbs/1000')
3.3 (.13) 16.4 (11.0)
3.6 (.14) 20.8 (14.0)
4.1 (.16) 26.8 (18.0)
4.3 (.17) 30 (20.0)
4.6 (.18) 35.7 (24.0)
5.1 (.20) 44.6 (30.0)
5.6 (.22) 52.1 (35.0)
5.8 (.23) 68.4 (46.0)
6.1 (.24) 86.3 (58.0)
7.4 (.29) 96.7 (65.0)
8.1 (.32) 136.9 (92.0)
9.1 (.36) 169.6 (114.0)
10.4 (.41) 193.4 (130.0)
11.4 (.45) 261.9 (176.0)
14 (.55) 378 (254.0)
15.7 (.62) 485 (326.0)
17.8 (.70) 648.8 (436.0)
19.1 (.75) 809.5 (544.0)
20.8 (.82) 946 (635.0)
23.1 (.91) 1133.9 (762.0)
Catalog Number
T0224H0-GYXX
T0324H0-GYXX
T0424H0-GYXX
T0524H0-GYXX
T0624H0-GYXX
T0824H0-GYXX
T1024H0-GYXX
T1224H0-GYXX
T1624H0-GYXX
T2024H0-GYXX
T2524H0-GYXX
T3224H0-GYXX
T4024H0-GYXX
T5024H0-GYXX
T7524H0-GYXX
T0024H0-GYXX
TC224H0-GYXX
TC524H0-GYXX
TC724H0-GYXX
TCC24H0-GYXX
