GENERAL INFORMATION
The replacement of the fan coil unit and commissioning of
the device must be carried out by qualified skilled personnel
only in compliance with the current regulations.
The replacement of the motor will void the device warranty.
The device should be completely inspected after replacing
the motor.
SCHAKO | Ferdinand Schad KG
Steigstraße 25-27
D-78600 Kolbingen
OPERATING INSTRUCTIONS
Replacement of the motor SC/SP [3 speeds]
with EC [0-10V] +interface EC (CRP0023E)
AQUARIS SILENT
EXPLANATION OF SYMBOLS
Caution, electric power
Safety information
Phone +49 (0) 7463-980-0
Fax +49 (0) 7463-980-200
schako.com | info@schako.de
Fan coil unit
Advertisement
Related Manuals for Schako AQUARIS SILENT
Summary of Contents for Schako AQUARIS SILENT
- Page 1 Safety information The replacement of the motor will void the device warranty. The device should be completely inspected after replacing the motor. SCHAKO | Ferdinand Schad KG Phone +49 (0) 7463-980-0 Steigstraße 25-27 Fax +49 (0) 7463-980-200 D-78600 Kolbingen...
-
Page 2: Filter Removal
Aquaris Silent – Fan coil unit OPERATING INSTRUCTIONS Conversion SC/SP-EC (+interface) Work on the electrical system may only be carried out by skilled electricians. Before carrying out work on live parts of electrical systems and electrical equipment, disconnect them from the power supply and secure them against being reconnected for the duration of the work. - Page 3 Aquaris Silent – Fan coil unit OPERATING INSTRUCTIONS Conversion SC/SP-EC (+interface) 2 UNSCREWING AND REMOVING CONNECTING TUBES NW 10 NW 20 NW 30 NW 40 NW 50 Construction subject to change. Version: 09.04.20 | Page 3...
-
Page 4: Base Plate
Aquaris Silent – Fan coil unit OPERATING INSTRUCTIONS Conversion SC/SP-EC (+interface) 3 BASE PLATE Unscrew (x2/side). Remove the base sheet. Construction subject to change. Version: 09.04.20 | Page 4... -
Page 5: Connecting Plate
Aquaris Silent – Fan coil unit OPERATING INSTRUCTIONS Conversion SC/SP-EC (+interface) 4 COVER OF ELECTRICAL JUNCTION BOX Remove the protection box (clip or screw). 5 CONNECTING PLATE Unscrew the plate (x3) and disconnect the wiring. Remove the transformer. Construction subject to change. - Page 6 Aquaris Silent – Fan coil unit OPERATING INSTRUCTIONS Conversion SC/SP-EC (+interface) 6 SC/SP MOTOR Unscrew the plate with motor fan (x2/side) and remove the unit downward. Construction subject to change. Version: 09.04.20 | Page 6...
- Page 7 Aquaris Silent – Fan coil unit OPERATING INSTRUCTIONS Conversion SC/SP-EC (+interface) 7 EC MOTOR Install the new EC fan unit and screw it down. 8 BOX INTERFACE EC Attach the new sticker as shown in the picture. Wire the connections.
- Page 8 Aquaris Silent – Fan coil unit OPERATING INSTRUCTIONS Conversion SC/SP-EC (+interface) EC-Ventilator Anschlussplatte CEP0023E Gelb / Grün Blau Schwarz Thermostat IN: 230 Vac Blau Grau Stufe1/Vel1 Schwarz Stufe2/Vel2 Brown Stufe3/Vel3 10VDC Grün Gelb 0..10V Blau Blau Tacho Weiß +10V Tacho Construction subject to change.
- Page 9 Aquaris Silent – Fan coil unit OPERATING INSTRUCTIONS Conversion SC/SP-EC (+interface) Refit the cover. 9 INSTALLATION. CARRYING OUT STEPS 3, 2, 1 Install the base sheet, connecting tubes and filter. Construction subject to change. Version: 09.04.20 | Page 9...
