- Page 1 Keysight E5810 LAN/GPIB Gateway Keysight E5818 LXI Class-B Trigger Box Rack Mount Installation Note...
- Page 3 One rack mount kit contains the hardware to mount a single E5810/E5818 or two E5810s/E5818s, side-by-side.
- Page 4 This rack mount is suitable for both E5810 and E5818 units. E5810 E5818 Rack Mounting Single E5810/E5818 (see other side to rack mount two E5810s/E5818s) Parts needed to install a single E5810/E5818 in a rack: E5810-00021 Rack Ear - Full Pack 0570-1581 Screw, Machine E5810-00022...
- Page 5 4. Do the connections based on the diagrams below: GPIB RS-232 Power A. Rear View of the E5810 B. Rear View of the E5818 TTL2 EXT2 TTL1 EXT1 1PPS Power GPIB RS-232 Power TTL 2 EXT 2 TTL 1 EXT 1 1PPS POWER 100-240VAC...
- Page 6 Rack Mounting Two E5810s/E5818s (see other side to rack mount single E5810/E5818) Parts needed to install two E5810s/E5818s, side-by-side, in a rack: 0050-2166 Lock Link 0515-1367 Screw, Flathead, M4x8 E5810-00023 Bracket, Rear E5810-00021 Rack Ear - Full Rack 0570-1581 Screw, Machine 0515-1114 Screw, Panhead, M4x10 0590-0804...
- Page 7 5. Do the connections based on the diagrams below: GPIB RS-232 Power A. Rear View of the E5810 B. Rear View of the E5818 TTL2 EXT2 TTL1 EXT1 1PPS Power GPIB RS-232 Power TTL 2 EXT 2 TTL 1 EXT 1 1PPS POWER 100-240VAC...
- Page 8 This information is subject to change without notice. © Keysight Technologies 2004 - 2015 Edition 4, January 2015 *E5810-99100* E5810-99100 www.keysight.com...
