- Page 1 YARA manual WWW.CLF-LIGHTING.COM V1.0 DECEMBER 2016...
-
Page 2: Table Of Contents
table of CONTENTS Dimensions Safety Information Fixture overview Introduction AC power Power voltage Power cables Relaying power to other devices Data link Tips for reliable data transmission Physical installation Fastening the fixture to a flat surface Setup Control panel and menu navigation DMX address setting Control Mode Static Color options... -
Page 3: Dimensions
Dimensions All dimensions are in millimeters WWW.CLF-LIGHTING.COM... - Page 4 WARNING! Read the safety precautions in this section before installing, powering, operating or servicing this product The following symbols are used to identify important safety information on the product and in this manual: DANGER! DANGER! WARNING! WARNING! WARNING! WARNING! WARNING! Safety hazard.
- Page 5 Do not expose the fixture to rain or moisture Refer any service operation not described in this manual to a qualified technician. Socket outlets used to supply the fixture with power or external power switches must be located near the fixtures and easily accessible so that the fixtures can easily be disconnected from power.
-
Page 6: Fixture Overview
fixture overview 5P DMX input 5P DMX output 3 P DMX input (optional) 3 P DMX output (optional) # CLF-13-453 # CLF-13-454 AC mains power AC mains power output input LCD Display Control buttons Safety cable attachment point G Clamp with Quicklock # 875760 (Optional) Omega bracket with... -
Page 7: Introduction
Introduction Outdoor RGBW LED Fixture Affordable lighting essential Unique bracket design ¢ Touring proof ¢ Smooth RGBW color mixing ¢ Ip65 rating ¢ Silent operation ¢ Smooth projection ¢ ® Powercon true 1 in & out ¢ RDM ready ¢ Using for the first time Warning! Read “Safety Information”... -
Page 8: Power Cables
power cables Power input and output cables must be rated 20A minimum, have three conductors 1.5 mm² (16 AWG) minimum conductor size and an outer cable diameter of 5 - 15 mm. Cables must be hard usage type (SJT or equivalent) and heat- resistant to 90°C minimum. -
Page 9: Physical Installation
Physical installation Warning! The fixture must be either fastened to a flat surface such as a stage or wall, or clamped to a truss or similar structure in any orientation using a rigging clamp. Warning! If the fixture can cause injury or damage if it falls, attach an approved safety cable to one of the safety cable attachment points on the base (see “Fixture overview”... -
Page 10: Setup
SETUP Warning! Read “Safety Information” on page 2 before installing, powering, operating the fixture. Control panel and menu navigation The onboard control panel and backlit graphic display are used to set the fixture’s DMX address, configure individual fixture settings (personality), read out data and execute service utilities. See “Onboard control menus”... -
Page 11: Static Color Options
Static Color options There are three options for static color: FIXED Color Several options from combinated RGBW values. Use Up and Down to scroll through the options. R = Red RB = Red & Blue BW = Red & White G = Green GB = Green &... -
Page 12: Auto Show
Auto show The auto function gives 10 auto programs and custom programs RGBW color combinations which are working Hit [ENTER] to adjust the speed of the without any DMX console. Auto program from 1-20. Auto program 1 pre-program 1 1) Auto 1 11) Program 1 Auto program 2 pre-program 2... -
Page 13: Personality
personality Here you can set all functions for the fixture. Information Factory reset Resets the fixture to its factory default settings. Please reboot power before reset takes effect. WWW.CLF-LIGHTING.COM 11.0... - Page 14 dmx protocols Function Value Setting Remark 0 - 100 Saturation 0 - 100 Value 0 - 100 Note: In HSV mode, Hue stands for the visible light, such as red, yellow, and cyan, etc. Saturation refers to the dominance of hue in the color; when saturation is at 100%, then the color is at its purest. Value is the color's brightness; when value is at 100%, then the color is at its brightest.
- Page 15 dmx protocols 7 CH Function Value Setting Remark Dimmer 0 - 100 0 - 100 Green 0 - 100 Blue 0 - 100 White 0 - 100 000 - 024 Shutter open Strobe 1 (fast → slow) 025 - 064 065 - 069 Shutter open Strobe 2: opening pulse (fast →...
- Page 16 11 CH Function Value Setting Remark Dimmer 0 - 100 0 - 100 Green 0 - 100 Blue 0 - 100 White 0 - 100 000 - 024 Shutter open Strobe 1 (fast → slow) 025 - 064 065 - 069 Shutter open Strobe 2: opening pulse (fast →...
-
Page 17: Dimmer Speed
Onboard control menus Main Menu Menu level 2 Menu level 3 Remark DMX ADDRESS <001> Default 1. Red 2.Green 3.Blue 4.White 1. Dimmer 2.Red 3.Green 4.Blue 5.White , 6.Strobe 1. Dimmer, 2.Red, 3.Green, 4.Blue, 5.White, 6.Strobe, 7.CCT Default : 11CH CONTROL MODE 1. -
Page 18: Blow-Out Diagram
Blow-out Diagram Description Part Number Front Cover ring CLF-14-003 Rubber glass ring CLF-14-010 Tempered front glass CLF-14-013 CLF-14-005 Lens kit CLF-14-035 Led board LED board radiator CLF-14-002 CLF-14-016 CLF-14-017 Fan cover Power supply CLF-14-015 Power supply support bracket CLF-14-007 Case body CLF-14-001 CLF-14-034 Display board... -
Page 19: Specifications
Specifications Physical Length 259mm Width 179mm Height 290mm Weight 3.8 kg without accessories Dynamic Efects beam angle 15° Optics Light source 14 pcs high-power LED(RGBW) Control and Programming Control DMX channels 4 / 6 / 7 / 11 / HSV / HSI Setting and addressing Control panel with backlit LCD graphic display Protocol... - Page 20 Outdoor IP-rated fixtures CLF products are applied to official classified IP norm levels. For this product the IP rate is IP65 when using the covers for the chassis parts. IP65 means according classified norm: shielded against dust and pressurized water from any side. Typical use for outdoor rated stage events with normal weather acceptance.
- Page 21 YARA CLFLIGHTING WWW.CLF-LIGHTING.COM...
