C.E.C. CD5 Installation And Setup Manual page 16

CD PLAYER / USB SOUND SYSTEM CD5
BRAVO-HD Control Panel
1. Start "BRAVO-HD Audio CPL" from the short-
cut on desktop or programs menu. BRAVO-
HD control panel will appear.
16
2. Turning on CD5 connected via USB cable the
BRAVO-HD control panel will change to show
a current setting.
In the area marked with Ⓐ click to change
the sample rate and/or bit rate to be used on
Windows sharing mode.
Note: WindowsXP does not have the sample
rate and bit rate settings for sharing
mode, thus Ⓐ is not showed.
In the area marked with Ⓑ the current setting
and playback via foobar2000 ASIO output are
displayed. And click to change the bit rate and
buffer size.
Note: Ⓑ does not work on playback via other
than ASIO.
