Summary of Contents for Coppernic C-five
- Page 1 C-five | C-five Ex Quick Start and Regulatory Guide 180127 A20 | Non-Contractual Pictures |...
-
Page 2: Safety Precautions
The device may only be used with battery pack type BP16-001510. The device may be used without handstrap, screen protector or carry case. • Only protective case and handstrap allowed to use: PN 6070-000110 purchased to COPPERNIC. • • Usage only in controlled environment with suitably reduced pollution. -
Page 3: What's In The Box
C-five | C-five Ex Quick Start and Regulatory Guide 180127 A20 WHAT'S IN THE BOX ? C-five C-five ATEX DEVICE PLUGS : UK or EU BATTERY (VARIES BY CONFIGURATION) PROTECTIVE CASE & HANDSTRAP NOTICE CABLE MICRO USB | USB A... -
Page 4: Product Overview
C-five | C-five Ex Quick Start and Regulatory Guide 180127 A20 PRODUCT OVERVIEW C-five 2D imager C-five ATEX led indicators power key function key volume keys +/- KEY LEFT UP (P1) 5’’ touch panel function key function key SCAN | KEY RIGHT... -
Page 5: Important Warning
C-five | C-five Ex Quick Start and Regulatory Guide 180127 A20 Setting up your device IMPORTANT WARNING • The Micro SIM must be inserted parallel to the battery compartment. If not, there is a risk to damage the SIM connector. - Page 6 C-five | C-five Ex Quick Start and Regulatory Guide 180127 A20 Setting up your device Battery installation Insert the battery, top side first. • Rotate the bottom side of the battery in the compartment. • Press down the battery cover until you hear a “click” sound.
-
Page 7: Back View
Charge the BATTERY Before using the C-five, please charge the battery using one of the following accessories approved by COPPERNIC. Insert the micro USB cable into the C-five and USB A cable into the power supply. - Page 8 C-five | C-five Ex Quick Start and Regulatory Guide 180127 A20 Setting up your device LED indicators DEVICE: C-FIVE Low battery Red LED blinks (LED1) Battery is charging Red LED (LED1) Battery is fully charged Green LED (LED1) BT devices connected or receiving messages/notifications...
-
Page 9: Using Your Device
C-five | C-five Ex Quick Start and Regulatory Guide 180127 A20 Using your device TURNING ON | TURNING OFF your device Power Off | Press and hold during 5 sec. the power button and select “Power off” in the dialog box. - Page 10 Complies with 21cfr1040.10 and 1040.11 except for deviations pursuant to laser notice no. 50, dated June 24, 2007 and IEC/EN 60825-1:2014. NOTE Please remove the protector film before using scanner. Scan with the imager Use "barcode settings" provided by Coppernic. • Side-Key Remapping for scanning Go to "Settings" > Select "Remap key & Shortcut" •...
-
Page 11: Regulatory Information
802.11a : 14.87 802.11n HT20 (5GHz) : 14.82 802.11n HT40 (5GHz) : 14.75 Bluetooth : 1.86 NOTE : C-five: Maximum reported SAR value (head) 0.730 W/kg (10g) C-five: Maximum reported SAR value (body-worn @5mm) 1.71 W/kg (10g) Page 11 | 13... -
Page 12: Laser Devices
These requests are designed to prevent possible interference with sensitive medical equipment. Safety Information – Europe This device was tested for typical body-worn operation. Use only COPPERNIC tested and approved accessories to ensure EU compliance. Laser Devices Class 2 laser scanners use a lower power, visible light diode. -
Page 13: Battery Safety
Power Adaptor Use only a C-five approved Power Adaptor with electrical ratings: Output 5VDC, min 2A, with a maximum ambient temperature of at least 45°C. Use of alternative power adaptor will invalidate any approvals given to this device and maybe dangerous.
