- Page 1 VACUUM CLEANER Instruction Manual LUVC700R...
-
Page 2: Table Of Contents
Contents 03 Important Safety Instruction 05 Product Overview 06 INSTRUCTIONS 08 CLEANING AND MAINTENANCE 10 Other Useful Information 11 TROUBLESHOOTING 11 Changing the Drive Belt... -
Page 3: Important Safety Instruction
Important Safety Instruction IMPORTANT SAFETY INSTRUCTIONS READ CAREFULLY AND KEEP FOR FUTURE REFERENCE Read this manual thoroughly before first use, even if you are familiar with this type of product. The safety precautions enclosed reduce the risk of fire, electric shock and injury when correctly adhered to. Keep the manual in a safe place for future reference, along with the completed warranty card, purchase receipt and carton. - Page 4 16. Do not use without the filter in place. 17. This appliance is intended for normal household use only. 18. If the supply cord is damaged, it must be replaced by the manufacturer or its service agent or a similarly qualified person in order to avoid a hazard.
-
Page 5: Product Overview
Product Overview Handle Wheel Dust cup release button Brush hose Dust cup 3 in 1 brush Handle hose Power cord Switch pedal Power cord holder Brush assembly Turbo brush Air outlet plate... -
Page 6: Instructions
INSTRUCTIONS Assembling your upright Insert the handle hose end into the Insert the crevice tool Insert the handle into the Place the dust container onto onto the machine. body, fasten the screw into connector hose and rotate the joint the machine and push until it body through the handle. - Page 7 Using the Turbo brush Or you can insert the 3 in 1 brush or the turbo The handle hose can be used directly Remove hose handle brush into the hose handle. from the machine and 3 in 1 brush from the machine.
-
Page 8: Cleaning And Maintenance
CLEANING AND MAINTENANCE Always switch off the appliance and unplug from the mains socket before carrying out any maintenance or cleaning. Clean the outside of the appliance with a slightly damp cloth. Dry thoroughly before use. Emptying and cleaning the dust cup Close the base of the dust container, Press the dust container release Hold the dust container over a bin and... - Page 9 Tap the filter Holder to remove Wash the filter and the filter Tap the filter over a bin to the inner filter. holder under running water(40°C release any dirt and dust. Note this should be performed in a max) ventilated area. Leave to fully dry for a least 24 hours before placing back in the machine...
-
Page 10: Other Useful Information
Cleaning the Dust Filter (2) Remove the dust cup as per instructions before this step: Turn the dust filter Leave to fully dry for a least Wash the dust filter Empty the dust container over and hold, then tap it to under running water. -
Page 11: Troubleshooting
TROUBLESHOOTING Please check the following details before you have your appliance repaired by an authorised servicing agent. Problem Possible Cause Possible Solution 1. Insert the plug back into the 1. Check if the power plug is firmly power outlet and ensure it is Vacuum inserted into the power outlet. - Page 12 Stage 2. Remove the Brush Ease the Right end of the brush out of its bearing. Repeat for the Left edge. Now lift out the brush with both hands. Be careful as the belt is still under tension. Pull out the brush from the belt. Stage 3.
- Page 13 Stage 6. Re-assembly Rotate the brush by hand to ensure that the mechanism moves freely and that the belt does not foul the guides and is central on the motor spindle. Now replace the cover plate . Place the cover plate into position and press the plate to the cleaner body all round to ensure a good fit. Screw the plate to the cleaner body.
- Page 14 Technical Specifications 220-240V 50/60Hz 900W Dust canister capacity: 2L Customer Service Number: 0800 422 274 MON – FRI: 8AM – 5PM SAT – SUN: 9AM – 4PM Responsible disposal At the end of its working life, do not throw this appliance out with your household rubbish. Electrical and electronic products contain substances that can have a detrimental effect on the environment and human health if disposed of inappropriately.
- Page 15 Warranty We pride ourselves on producing a range of quality home appliances that are both packed with features and completely reliable. We are so confident in our products, we back them up with a 1 year warranty. Now you too can relax knowing that you are covered. Customer Helpline NZ: 0800 422 274 This Product is covered by 1 year warranty when accompanied by proof of purchase.
