KSOL-2 UNIVERSAL CONSTRUCION WITH MULTIPLE KS2500
1
3
Spacing of openings for the assembly of the KSOL-2 2500 universal structure
1a
COLLECTORS ASSEMBLY INSTRUCTION
8
4
19
8
18
9
1b
20
2
6
5
7
11
10
19
20
No
Name
1
Vertical bar
2
Upper horizontal bar
3
Lower horizontal bar
4
Bottom connector
5
Back connector
6
Diagonal connector
7
Base
8
Collector grasper
9
Connector
10
Connector
11
Insert
12
Screw M6x40
13
Nut M6
14
Screw M8x16
15
Screw M8x20
16
Washer Ø8
17
Nut M8
18
Nut cap
19
Cap
20
Connector
21
Screw M6x20
1c
Mount
2
2
2
2
2
1
4
8
4
4
12
8
10
28
4
32
32
16
4
2
2

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the KSOL-2 and is the answer not in the manual?

Questions and answers

Summary of Contents for Hewalex KSOL-2

  • Page 1 Bottom connector Back connector Diagonal connector Base Collector grasper Connector Connector Insert Screw M6x40 Nut M6 Screw M8x16 Screw M8x20 Washer Ø8 Nut M8 Nut cap Connector Screw M6x20 Spacing of openings for the assembly of the KSOL-2 2500 universal structure...
  • Page 2 The KSOL-2 universal structure is used to mount a set of 2 KS2500 collectors. Steps of the assembly: 1. Attach the connectors (10) to the horizontal bars (2, 3). Attach the top horizontal bar (2) and the bottom one (3) to the vertical bars (1).
