- Page 1 PRODUCT SANDOR WS Product code SANDOR WS SMA SANDOR WS SMA DOUBLE OPTIC PERIMETER BARRIER INSTALLATION AND MOUNTING MANUAL VERSION 3.1...
-
Page 2: Table Of Contents
13.Intervention time adjustment ………………..…………………………………………………………..……………… 18 14.Details and functions …………………………..………………..………………………………………………………...……... 19 14.1 SK WS TX motherboard 14.2 SK WS RX motherboard 14.3 Transmitter optic 14.4 Receiver optic 15.Technical specifications ……………………………………………………………………………………………………..……… 23 16.FAQ…………………………………………………………….…………………………………………………………..….………….…24 17.Product disposal………………………………………………..……………………………………………….....……..…… 26 SANDOR WS SMA POLITEC | INSTALLATION MANUAL - VER.3.1... -
Page 3: Introduction
The system has been designed to detect intrusions and activate the alarm; it is not a device that prevents intrusion.Politec is not responsible for damage, injury or loss caused by accidents, theft, force majeure (including momentary lightning-induced overcurrent), abuse, improper or incorrect use, faulty installation or inadequate maintenance. -
Page 4: General Warnings
• Manufacturer's liability:Politec assumes no liability for failures resulting from incorrect installation; lack of maintenance, incorrect assembly or use. • Politec is also not liable for incorrect or incomplete operation of the product or failure to detect intrusion. •... -
Page 5: List Of Main Components
The package contains the following components and accessories. When opening the package, check that everything has been included. COMPONENT Aluminium profile Caps Transmitter\Receiver optics SK WS RX / TX motherboard 3.6V 19Ah lithium battery Black polycarbonate cover SANDOR WS SMA POLITEC | INSTALLATION MANUAL - VER.3.1... -
Page 6: Preparation For Installation
• Check that the surface chosen for the installation of the product is sturdy so as to ensure stable fixing and that it is adequately protected against possible impacts or the elements. SANDOR WS SMA POLITEC | INSTALLATION MANUAL - VER.3.1... -
Page 7: Assembly And Positioning Of The Cable Pit
Pole mounting Wall mounting with Wall mounting with with SAN/PL SAN/SD brackets SAN/PL pole brackets brackets (recommended protection of sections along the wall) SANDOR WS SMA POLITEC | INSTALLATION MANUAL - VER.3.1... - Page 8 WARNING: Product warranty is invalid if there is any hole in the aluminium profile or any component. SANDOR WS SMA POLITEC | INSTALLATION MANUAL - VER.3.1...
-
Page 9: Evaluations Before Installation
TX and RX, thereby ensuring a good amount of signal constantly, even in case of particular climatic conditions. SANDOR WS SMA POLITEC | INSTALLATION MANUAL - VER.3.1... -
Page 10: Barrier Positioning
DO NOT place barriers close to roads: vehicle lights directed towards the RX could create disturbances DO NOT place barriers near automatic gates: photocell signals can create interference. SANDOR WS SMA POLITEC | INSTALLATION MANUAL - VER.3.1... -
Page 11: Installation Examples
9.Installation examples 9.1 Barrier positioning All Politec products can be customised according to the installation needs, including column height and consequently the number of beams inside which can vary in different ways and work in parallel or crossing. This is a type of barrier that lends itself very well to single barrier systems and for the protection of facades, as well as in the open field, following the recommended distances. -
Page 12: Ws Rx Motherboard Connections
Output of masking signal given by the closing to negative of an open collector ANTIMASK (NO) Removing the jumper disables the optical reception of the tamper alarm of TAMPER TX the transmitter barrier, in case of tampering SANDOR WS SMA POLITEC | INSTALLATION MANUAL - VER.3.1... -
Page 13: Ws Tx Motherboard Connections
Heater power supply 24V / 12V (only from external source) Not used The tamper opening information of the transmitter column is sent optically to the receiver column after 30 ''; as well as low battery information. SANDOR WS SMA POLITEC | INSTALLATION MANUAL - VER.3.1... -
Page 14: Barrier Alignment
It is sufficient to apply the filter only on the TX, there is no need to repeat the operation also on the RX. SANDOR WS SMA POLITEC | INSTALLATION MANUAL - VER.3.1... -
Page 15: Alignment
3 seconds or until the orange TEST LED lights up, in addition to the intermittent acoustic signal of the BUZZER, accompanied intermittent flashing of the long-range high-intensity LEDs for alignment. TEST BUTTON SANDOR WS SMA POLITEC | INSTALLATION MANUAL - VER.3.1... - Page 16 After calibration, tighten the horizontal adjustment screw, and exit the test function by pressing the TEST button on the TX and RX optics for 3 seconds. • Repeat all the operations on each beam of the barrier. SANDOR WS SMA POLITEC | INSTALLATION MANUAL - VER.3.1...
- Page 17 TRANSMITTER optic with your hand: if the RECEIVER continues to give a continuous beep, it means that it sees another infrared source that must be turned off and eliminated. SANDOR WS SMA POLITEC | INSTALLATION MANUAL - VER.3.1...
-
Page 18: Intervention Time Adjustment
(e.g. animal crossing). By adjusting the potentiometer clockwise, the intervention time decreases down to 50ms.In this condition, the alarm of a person crossing the barrier running at maximum speed is guaranteed. ALARM SANDOR WS SMA POLITEC | INSTALLATION MANUAL - VER.3.1... -
Page 19: Details And Functions
Activates all transmitters in test during the alignment phase (DIP 1 BEAM ON ON).Steady TEST LED Deactivates all the transmitters during the alignment phase (DIP 1 BEAM OFF ON).Steady TEST LED SANDOR WS SMA POLITEC | INSTALLATION MANUAL - VER.3.1... -
Page 20: Ws Rx Motherboard
In ON the "ANTIMASK" function is activated, therefore in case of masking the alarm is inhibited for the duration.The condition information can be transferred from the output of the dedicated terminal. TEST In ON the programming and test phase is activated. SANDOR WS SMA POLITEC | INSTALLATION MANUAL - VER.3.1... -
Page 21: Receiver Optic
N.B.:The settings relating to the addresses are already set by default, and shown here in the maximum configuration. N.B.:The barrier can result in an alarm even if the WEAK LED SIGNAL is off.The cause may be the lack of synchronism or a misaligned transmitter. SANDOR WS SMA POLITEC | INSTALLATION MANUAL - VER.3.1... - Page 22 Test button 1 2 3 4 5 6 1 2 3 4 5 6 N.B.:The settings relating to the addresses are already set by default, and shown here in the maximum configuration. SANDOR WS SMA POLITEC | INSTALLATION MANUAL - VER.3.1...
-
Page 23: Technical Specifications
60mm x 60mm x from 1000mm to 4000mm INGRESS PROTECTION RATING IP 54 or 65 on request WARRANTY 2 YEARS * It is possible to insert a second battery on each board to increase the autonomy SANDOR WS SMA POLITEC | INSTALLATION MANUAL - VER.3.1... -
Page 24: Faq
For more precise alignment, position one side of the column cover in front of the lenses in order to have two surfaces interposed between TX and RX to double the attenuation of the beam. SANDOR WS SMA POLITEC | INSTALLATION MANUAL - VER.3.1... - Page 25 For more precise alignment, position one side of the column cover in front of the lenses in order to have two surfaces interposed between TX and RX to double the attenuation of the beam. SANDOR WS SMA POLITEC | INSTALLATION MANUAL - VER.3.1...
-
Page 26: Product Disposal
Warning!- Local regulations can impose heavy penalties for incorrect disposal of these products. SANDOR WS SMA POLITEC | INSTALLATION MANUAL - VER.3.1... - Page 28 For technical support, contact your security systems distributor...
