Pump Kit Parts List
PK300 pump (1)
Approx. 7" length of ½" Black non-kink tubing (1)
#7 compression stopper (1)
17" copper pipe (1)
¾" male threaded ½" barb adapter (1)
4mm Allen wrench (1)
Hose clamps (3) Note – hose clamps may be used as flow restrictor
Wedges (4)
FT-38 Palamos Fountain
(3 pieces)
COMPONENTS AND PARTS LIST
FT-38A
18 ¼"W x 19"H
79 lbs
FT-38B
10 ¾"W x 5 ¼"H
13 lbs
FT-38C
Pump
34"W x 8 ½"H
191 lbs
Revised May 24, 2012
NOTE: Component photos are not to scale
Tools you will need
Level
4mm Allen wrench (included)
This fountain uses cover
FTNCOV-MED
Advertisement
Table of Contents
Related Manuals for Campania Palamos FT-38
Summary of Contents for Campania Palamos FT-38
- Page 1 FT-38 Palamos Fountain (3 pieces) Revised May 24, 2012 COMPONENTS AND PARTS LIST FT-38A 18 ¼”W x 19”H Copper 79 lbs Pipe adapter FT-38B 10 ¾”W x 5 ¼”H 13 lbs Non Kink Tubing FT-38C Pump 34”W x 8 ½”H 191 lbs NOTE: Component photos are not to scale Compression Stopper...
- Page 2 FT-38 Palamos Fountain (3 pieces) Revised May 24, 2012 ASSEMBLY INSTRUCTIONS 1. Make sure you are assembling your fountain on a level surface. 2. Place the Basin (FT-38C) into position where the fountain will be installed. 3. Feed the pump cord through the hole in the basin leaving enough cord length to work with the pump. 4.
