OPTION 1: RTA CUBBY ON LEFT SIDE
OPTION 2: RTA CUBBY ON RIGHT SIDE
IMPORTANT! Please keep these instructions for future reference. Please read
these instructions before assembly and use of this product.
•
Adult assembly is required.
•
Allen wrench (included) required for assembly.
•
Product features and decorations may vary from illustrations.
•
Do not use power drills or drivers.
•
Phillips Head Screwdriver (Not Included) required for assembly.
MADE IN VIETNAM
Bulletin NO.: 171019-00
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Dolce Lucca Storage Unit
Summary of Contents for Dolce Lucca Storage Unit
- Page 1 OPTION 1: RTA CUBBY ON LEFT SIDE OPTION 2: RTA CUBBY ON RIGHT SIDE IMPORTANT! Please keep these instructions for future reference. Please read these instructions before assembly and use of this product. • Adult assembly is required. • Allen wrench (included) required for assembly. •...
-
Page 2: Part List
Part List A. 2 Drawer Storage Unit B. Top Panel C. Side Panel D. Bottom Panel E. Back Panel... - Page 3 Part List HARDWARE AND TOOL DIAGRAM Cam Lock X 4 1-3/8" Allen Head Bolt X 4 Phillips Head Screw 5/8” X 14 Cam Rods X 4 Flat Washer X 4 Spring Washer X 4 Allen Wrench X 1...
- Page 4 Furniture Care Instructions Room Climate Control Wood, when first cut contains more than 50 percent water. When it is prepared for furniture construction it is placed in a Kiln and the moisture content is brought down to 8 to 10 percent. Wood is porous and responds to its environment.
- Page 5 STOP IF YOU EXPERIENCE ANY ISSUES WITH THIS PRODUCT BEFORE YOU RETURN THIS TO THE RETAILER PLEASE FOLLOW PROCEDURES ON THE BACK PAGE...
-
Page 6: Assembly Step
OPTION 1: RTA CUBBY ON LEFT SIDE Assembly step 1 Cam Rods X 4 A. 2 Drawer Storage Unit C. Side Panel FIGURE 1A FIGURE 1B Step 1: Insert Cam Rods (K) into the inset nut on the left side panel of Storage Unit (A), and right side of Side Panel (C) as shown in Figure. - Page 7 OPTION 1: RTA CUBBY ON LEFT SIDE Assembly step 2 B. Top Panel Flat Washer x 4 Spring Washer x 4 1-3/8" Allen Head Bolt x 4 Allen Wrench x 1 D. Bottom Panel Cam Lock x 4 NOTE: TURN STORAGE UNIT ONTO ITS BACK FIGURE 2B FIGURE 2A Step 2:...
- Page 8 Assembly step 3 Phillips Head Screw 5/8” X 14 E.Back Panel Step 3: Use a Phillips Head screwdriver to attach Back Panel (E) with 5/8” Phillips Head screws (L) as shown in figure. Move assembled storage unit under the bed carefully as shown above.
- Page 9 OPTION 2: RTA CUBBY ON RIGHT SIDE Assembly step 1 Cam Rods X 4 A. 2 Drawer Storage Unit C. Side Panel FIGURE 1A FIGURE 1B Step 1: Insert Cam Rods (K) into the inset nut on the right side panel of 2 Drawer Storage Unit (A) and left side of Side Panel (C) as shown in Figure.
- Page 10 OPTION 2: RTA CUBBY ON RIGHT SIDE Assembly step 2 B. Top Panel 1-3/8" Allen Head Bolt X 4 Flat Washer x4 Spring Washer x4 Allen Wrench X 1 D. Bottom Panel Cam Lock X 4 FIGURE 2B NOTE: TURN STORAGE UNIT ONTO ITS BACK FIGURE 2A Step 2: - Attach the Bottom Panel (D) to the Storage Unit using...
- Page 11 OPTION 2: RTA CUBBY ON RIGHT SIDE Assembly step 3 Phillips Head Screw 5/8” X 14 E. Back Panel Step 3: Use a Phillips Head screwdriver to attach Back Panel (E) with 5/8” Phillips Head screws (L) as shown in figure. Move the storage to bottom of the bed carefully as figure.
- Page 12 Product Assistance Procedures You have purchased a quality piece of furniture. Our International team has spent many hours designing and engineering this piece and packaging to ensure you will be satisfied with your purchase. But if for any reason you need help with your purchase please contact us at any time.
