Table of Contents
Overview........................................................1
Features........................................................2
Console Connection.........................................3
Computers Connection......................................8
Initial Power-up...............................................12
Front Panel operation.......................................13
Hot-key commands...........................................13
Audio Function................................................16
■ Appendices
Specifications.................................................17
■ Troubleshooting.......................................19
follow the Installation procedures to prevent any
damage to the Claxan Switch or any connecting
device.
Table of Content
Please read this manual thoroughly and
Advertisement
Table of Contents
Related Manuals for Claxan CL-KVM-5002
Summary of Contents for Claxan CL-KVM-5002
-
Page 1: Table Of Contents
Computers Connection……………….……….……...8 Initial Power-up……………….………………..……..12 ■ Operations Front Panel operation…………...……………..…….13 Hot-key commands…...…………...……………..…..13 Audio Function..……………………………………….16 ■ Appendices Specifications………………..………………………..17 ■ Troubleshooting…………………...……………19 Please read this manual thoroughly and follow the Installation procedures to prevent any damage to the Claxan Switch or any connecting device. -
Page 2: Introduction
There is no interface card and software to install and the Claxan Switch is independent of the computer operating system. Ready to run right out of the box, this Kit comes with everything you need - a switch and complete cable sets, just hook them up and go. -
Page 3: Features
Operating system independent, transparent to all applications. High VGA resolution 1920x1440. DDC2B compatible. Power-free operation - the Claxan Switch draws power from the attached PCs. Supports the audio (SPEAKER+MIC) function (For CL-KVM-5002A, CL-KVM-5004A,... -
Page 4: Installations
“Mouse”. Then connect your VGA monitor cable directly to the HDB15 port as shown in Figure 1 for CL-KVM-5002 and Figure 2 for CL-KVM-5004. For the models with audio function, CL-KVM-5002A and CL-KVM-5004A, connect a pair of Speakers and a MIC as well. - Page 5 The Figure 3 and 4 shows the console connection for CL- KVM-5002A and CL-KVM-5004A respectively. Figure 3: CL-KVM-5002A Console Connection Figure 4: CL-KVM-5004A Console Connection...
- Page 6 CL-KVM-UMH-2 / CL-KVM-UMH-4 / CL-KVM-UMH-2A CL-KVM-UMH-4A Turn your computers off. Connect a USB keyboard to the USB port marked with “Keyboard” and a USB mouse to USB port marked with “Mouse”. Then connect your VGA monitor cable directly to the HDB15 port as shown in Figure 5 for CL-KVM-UMH-2 and Figure 6 for CL-KVM-UMH-4.
- Page 7 The Figure 7 and 8 shows the console connection for CL- KVM-UMH-2A and CL-KVM-UMH-4A respectively. Figure 7: CL-KVM-UMH-2A Console Connection Figure 8: CL-KVM-UMH-4A Console Connection...
- Page 8 The multi-sync monitor must be capable of synchronizing with the computer's video signal. If you are uncertain about the monitor type, please consult the monitor user's manual. The Claxan Switch consumes negligible power and is designed to run reliably without an external power adapter.
-
Page 9: Computers Connection
(one HDB15 and two mini-DIN6s). The PC 1 ~ PC 2 marks on the Claxan Switch are for computer connection. For the models with audio function, CL-KVM-5002A and CL-KVM-5004A, connect to Speaker port and MIC port as well. - Page 10 The PC 1 ~ PC 4 marks on the Claxan Switch are for computer connection as shown in Figure 11 and 12. Figure 11: CL-KVM-5004 COMPUTER Connection Figure 12: CL-KVM-5004A COMPUTER Connection NOTE: If your computer uses an AT style keyboard, you will need an "AT-to-PS/2 keyboard adapter"...
- Page 11 (one HDB15 and one USB/ one HDB15 and two PS/2s). The PC 1 ~ PC 2 marks on the Claxan Switch are for computer connection as shown in Figure 13 and 14. For the models with audio function, CL-KVM-UMH-2A and CL-KVM-UMH-4A, connect to Speaker port and MIC port as well.
- Page 12 The PC 1 ~ PC 4 marks on the Claxan Switch are for computer connection as shown in Figure 15 and 16. Figure 15: CL-KVM-UMH-4 COMPUTER Connection Figure 16: CL-KVM-UMH-4A COMPUTER Connection NOTE: For UMH Series, you may feel free to connect either one USB port (for both keyboard and mouse) or two PS/2 ports (one for keyboard and another one for mouse).
-
Page 13: Initial Power-Up
The Claxan Switch can be powered from the computers. This procedure ensures the Claxan Switch receive computer settings correctly when computer boots. NOTE: You may hot plug any additional powered-down computer to the Claxan Switch at any time after the initial power up. -
Page 14: Operations
Hot-key commands Hot-key command is a short keyboard sequence to select a computer or to activate computer scanning. Claxan Switch interprets keystrokes for hot-keys all the time. A hot-key sequence starts with two left Ctrl keystrokes followed by one keystroke. - Page 15 left Ctrl + left Ctrl + 4 Selects the computer at PC 4 (for CL-KVM-5004,CL-KVM-5004A CL-KVM-UMH-4 and CL-KVM-UMH-4A only). NOTE: Do not use the keypad at the right side of the keyboard for hot key commands. To start Auto Scan, automatically scans all ports one by one at a fixed interval: left Ctrl + left Ctrl + F 1 To abort the Auto Scan mode, press the left Ctrl key...
- Page 16 Ctrl + left Ctrl + F4 There are four options: 10, 15, 20 and 30 characters/sec. NOTE: The keyboard typematic Rate is set to default of 10 characters/sec when Claxan Switch loses all power sources, i.e., all connected computers are turned off.
-
Page 17: Audio Function
The audio signal selection follows computer selection. It is useful if you want to listen to a particular computer's audio signal. You can also broadcast audio signal to a particular computer or all computers connected. CL-KVM-5002A CL-KVM-5004A CL-KVM-UMH-4A Figure 17: The Claxan Switch Audio Function... -
Page 18: Specifications
----------------- Appendices Specifications Specification CL-KVM-5002 CL-KVM-5002A CL-KVM-5004 CL-KVM-5004A Console port number Computer port number Port selection push button Hot plug-and-play Hot-key control 1920 x 1440, DDC2B Computer HDB15 x 2 HDB15 x 4 connector HDB15 x 2 HDB15 x 4... - Page 19 Specification CL-KVM-UMH-2 CL-KVM-UMH-2A CL-KVM-UMH-4 CL-KVM-UMH-4A Console port number Computer port number Port selection push button plug-and-play Hot-key control 1920 x 1440, DDC2B Computer HDB15 x 2 HDB15 x 4 connector HDB15 x 2 HDB15 x 4 Stereo jack x 4 Stereo jack x 8 Console connector...
-
Page 20: Troubleshooting
DC 9V 500mA function power. output rating to the SPARE occasionally. power jack. Computer can The Claxan Switch does not not use serial support serial mouse. mouse. Scan Rate was All connecting Set the Scan Time again and...
