Summary of Contents for Claxan CL-KVM-DAAG-114
- Page 2 Package Contents CL-KVM-DAAG-112 (w/ Audio) 2-Port (CL-KVM-DAAG-112) User’s manual Rubber foot pad x 1 set CL-KVM-DAAG-114 (w/ Audio) 4-Port (CL-KVM-DAAG-114) User’s manual Rubber foot pad x 1 set PP5-GG0800-010 Printed in Taiwan...
-
Page 3: Table Of Contents
Table of Content Introduction…………………………….…...1 Overview .............1 Features............2 System Requirements…………………..…3 Console side ..........3 Computer side..........3 Installations………………………………… 4 PC BIOS Notice ...........4 Console Connection ........5 Computers Connection ........6 Operations……………….…………………..7 Front Panel……………………………………7 Rack Mount Kit……………………….……14 Appendices…………………………………15 Specifications………………………………..15 Troubleshooting…………………………...16 Please read this manual thoroughly and follow the Installation procedures to prevent any damage to the Unit or any connecting device. -
Page 4: Introduction
The CL-KVM-DAAG-112/ CL-KVM-DAAG-114 provides the easiest way to manage multiple computers with USB interface and share USB peripherals among computers. No more tangled cables and messy working environment; CL-KVM-DAAG-112/ CL-KVM-DAAG-114 do the computer switching for you. -
Page 5: Features
Front panel push buttons for easy computer selection Rear panel “FUNC” button for easily adjusting the video signal strength (for CL-KVM-DAAG-114 only) No drivers needed for keyboard and mouse operation Support keyboard and mouse plug-n-play Buzzer sound for computer switching confirmation... -
Page 6: System Requirements
Claxan Switch --------------- System Requirements Console side One DVI monitor One USB keyboard One USB mouse Computer side Each USB-enabled computer must be connected to the unit by One DVI cable for monitor, as shown below. One USB A-B cable with Type-A and Type-B plug for USB devices. -
Page 7: Installations
2. In PNP AND PCI SETUP, set PNP OS INSTALLED to YES and set USB IRQ to ENABLED. Note: The CL-KVM-DAAG-112/ CL-KVM-DAAG-114 is applicable for USB keyboard and mouse switching from one computer to the other. If you plan to share other peripherals such as... -
Page 8: Console Connection
Claxan Switch Console Connection Before installation, make sure all devices and computers to be connected to the unit have been turned off. Plug a monitor to the Console's DVI port; plug a USB keyboard and a USB mouse to any two of the Console's USB ports as... -
Page 9: Computers Connection
Claxan Switch Computers Connection Use a male-to-male cable to connect from a computer's DVI port to the unit's DVI port of PC side. Use a USB A-B Cable to connect from the unit's USB port (B connector, square connector) to the USB port on the corresponding computer (A connector, flat connector), as shown below. -
Page 10: Operations
"4" simultaneously. The port LED flashes during Auto Scan. Auto Scan is effective for powered-on computers only. To exit the Auto Scan mode, just tap any one of the pushbuttons. ( CL-KVM-DAAG-114 only ) Note: keyboard and mouse are not operable during Auto Scan. - Page 11 Note: Scan Time is automatically set to the default of 3 seconds when the unit loses power. “FUNC” Button ( CL-KVM-DAAG-114 only ) To adjust the optimal video signal strength corresponding to the length or quality of DVI cable, the user can press “FUNC” button combining with the other pushbuttons.
- Page 12 Claxan Switch equalization of selected port input video strength with one beep (normal) or two beeps (enhance) respectively. Press pushbutton “3” one or two times for adjusting the output current of selected port with one beep (normal) or two beeps (enhance) respectively.
- Page 13 Claxan Switch Hotkey Commands The Hot-key command is a short keyboard sequence to select a computer, to activate computer scan, etc. KVM Switch interprets keystrokes for hot-keys all the time. A hot-key sequence starts with two left Ctrl keystrokes ( in 0.2 seconds ) followed by one or two more keystrokes.
- Page 14 Claxan Switch suspends the scanning till the activity stops; it then resumes with the next computer in sequence. The length of the Auto Scan interval (Scan Rate) is adjustable, see below. Manual Scan enables you to manually switch back and forth between power-on computers.
- Page 15 Ctrl + Press Left Ctrl + Press F8 (CL-KVM-DAAG-114 only) Enforce the USB followed with the selected computer by pressing the following hotkey Press Left Ctrl + Press Left Ctrl + Press U NOTE: Please make sure that USB device linking procedure has accomplished before switching to the next computer.
- Page 16 Claxan Switch Alternative Hotkey Commands In addition to the Left Ctrl + Left Ctrl hotkeys, there are two other hotkey sequences available. Users may Press Scroll Lock twice instead. For example, To select a computer: Press Scroll Lock + Press Scroll Lock + Press Selects the computer at port 1.
-
Page 17: Rack Mount Kit
Claxan Switch ----------------- Rack Mount Kit The figure below shows how to attach optional mounting brackets and cable support (RMK04) to the CL-KVM-DAAG-114 for standard 19-inch rack cabinet. -
Page 18: Appendices
Claxan Switch ----------------- Appendices Specifications CL-KVM-DAAG-112 CL-KVM-DAAG-114 Console Port Computer Port Front panel push button FUNC button Hot plug-and-play Automatic scan interval 3, 8, 15, 30 seconds 3, 8, 15, 30 seconds Cable length (Max) 3M (10ft) for USB 3M (10ft) for USB... -
Page 19: Troubleshooting
Claxan Switch ----------------- Troubleshooting Ensure that all cables are well seated. Label the cable for each computer to avoid confusion when connected to the unit. The unit has built-in power protection that works automatically when needed. When it works, USB communication halts and the... - Page 20 Claxan Switch When the unit unit by unplugging all USB A-B works under cables and the power adapter; self-power, i.e., then start all over again. no power supply Select the computer by added, it pushbutton, restart the computer supports max of and try again.
- Page 21 Claxan Switch resolution Improper video To adjust the optimal is not good. settings of the video signal strength unit corresponding to the length or quality or DVI cable, the user can press “FUNC” button combing with the other pushbuttons.
- Page 22 Claxan Switch Limited Warranty IN NO EVENT SHALL THE DIRECT VENDOR'S LIABILITY FOR DIRECT OR INDIRECT, SPECIAL, INCIDENTIAL OR CONSEQUENTIAL DAMAGES, LOSS OF PROFIT, LOSS OF BUSINESS, OR FINANCIAL LOSS WHICH MAY BE CAUSED BY THE USE OF THE PRODUCT EXCEEDS THE PRICE PAID FOR THE PRODUCT.
