To Mount An Airflake-Holder; Locking The Airflake-Holder; Snip-Snap In Locking Position; Put The Snip-Snap Into The Hole - ABSTRACTA AIRFLAKE Manual

How to mount airfl ake on rails
H H
Picture 8 - to mount a airfl ake-holder
Long Long
Picture 11 - snip-snap in two sizes to lock airfl ake
to airfl akeholder
Picture 13 - put the snip-snap into the hole of the airfl ake-
holder.
Abstracta AB
Box 75
SE- 360 30 Lammhult
Phone + 46 472 26 96 00
Fax + 46 472 26 96 01
info@abstracta.se
www.abstracta.se
Picture 9 - fi t it to position
Short Short
H H
H H
Long Long
Picture 12 - snip-snap in locking position
Picture 14 - Lock the snip-snap into the hole by pressing it
together
Picture 10 - locking the airfl ake-holder
H H
