1
ITEM #0338651
WALL LANTERN
MODEL #LWS1204C
Lowes.com/portfolio
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Portfolio LWS1204C 0338651
Summary of Contents for Portfolio LWS1204C 0338651
- Page 1 ITEM #0338651 WALL LANTERN Portfolio ® is a registered trademark of LF, LLC. All Rights Reserved. MODEL #LWS1204C ATTACH YOUR RECEIPT HERE Serial Number Purchase Date Questions, problems, missing parts? Before returning to your retailer, call our customer service department at 1-800-643-0067, 8 a.m. - 6 p.m., EST, Monday - Thursday, 8 a.m. - 5 p.m., EST, Friday.
-
Page 2: Package Contents
PACKAGE CONTENTS PART DESCRIPTION QUANTITY Fixture Loop Assembly Fixture Body Lowes.com/portfolio... -
Page 3: Safety Information
If any part is missing or damaged, do not attempt to assemble the product. Estimated Assembly Time: 20 - 30 minutes Tools Required for Assembly (not included): Flathead screwdriver, Phillips screwdriver, Pliers, Wire cutters, Electrical tape, Safety goggles, Ladder and Caulk. Helpful Tools (not included): Wire strippers Lowes.com/portfolio... - Page 4 1. Thread the fixture loop assembly (A) into the hex coupling on the top of fixture body (B). hand tighten until snug. Hex Coupling 2. Rotate the flat scroll to the top of the fixture. pull Flat Scroll the scroll end into the fixture loop (A). Lowes.com/portfolio...
- Page 5 (FF) onto the mounting screws (CC) as shown. Hardware Used Mounting Screw Hex Nut Crossbar Secure the crossbar (GG) to the outlet box (not included) with outlet box screws (DD). Hardware Used Outlet Box Screw Outlet Box Lowes.com/portfolio...
- Page 6 (B) with the mounting screws (CC) attached to the crossbar (GG). Pass the fixture over the mounting screws (CC) and secure by threading mounting balls (EE) onto end of mounting screws (CC). Tighten until snug. Hardware Used Outlet Box Mounting Ball Lowes.com/portfolio...
- Page 7 Proceed to caulk over top of backplate and down other side. Do not caulk bottom of fixture backplate to ensure proper moisture drainage. Outdoor Fixture Backplate Exterior Wall Surface Lowes.com/portfolio...
-
Page 8: Care And Maintenance
As some states do not allow exclusions or limitations on an implied warranty, the above exclusions and limitations may not apply to you. This warranty gives you specific legal rights. You may have other rights that vary from state to state. Lowes.com/portfolio... -
Page 9: Replacement Parts List
Monday - Thursday, 8 a.m. - 5 p.m., EST, Friday. PART DESCRIPTION PART # Green Ground Screw Wire Connector Mounting Screw Outlet Box Screw 9451KIT Hex Nut Mounting Ball Crossbar Candle Cover M2227CCK Printed in China Portfolio ® is a registered trademark of LF, LLC.All Rights Reserved. 2015-01-12 Lowes.com/portfolio...
