Vanderbilt SPCN310 Installation Instruction

SPCN310
GSM Module incl. Antenna
Modem GSM incluyendo antena
Modul GSM vcetne anteny
Modut telefoniczny GSM
STEP: A6V10209207, Edition: 17.09.2008
English
,&. Before starting to install and work with this device,
please read the Safety Instructions.

Installing the SPCN310

The SPCN310 provides the SPC controller with a GSM
interface allowing the user to send and receive text
messages via the mobile network. For a complete
description on the GSM features please consult the SPC
Configuration Manual.
The SPCN310 must have a SIM card installed in the unit
to operate (see below for details on installing the SIM
card).
I I
I
1
See Fia: SPCN310
I
I
1 SPCN310 on the SPC Controller
Before installing the GSM module onto the SPC
controller ensure that a functioning SIM card is installed
on the module.
To install a SIM card onto the GSM module unlock flap
with an upward motion, rotate the flap on the SIM card
holder to the 'up' position and slide the SIM card down
into the slot. Rotate the flap back to its original position,
press and click into place with a downward motion.
Please make a note of the unlock code for your SIM card
as this will be required when enabling the SIM card on
the SPC.
I I
I
See Fia: 2 Insert SIM Card
I
I
SIM Card
1
I
I
2 SIM Card Holder
1
1
oao o□□□
I
0
�
0
D
=
□
o
o 11111B11
aaciaa
aaaaa
o��
□
2
D
CE
To install the SPCN310 (with SIM card):
► Ensure the AC Mains power and battery backup
connections are removed.
► Insert the mounting pillars (included with the modem)
into the hole positions at the top on either the primary
slot (left) or back-up slot (right) on the controller.
► Align the 16-pin female socket over the 16-pin male
connector, ensuring that the holes on the SPCN310
are aligned with the top of the mounting pillars.
► Firmly but gently press down to secure the module.
► Power up the SPC controller.
I See Fia: I 3 I Primarv and Back-Uo Slot
I
I
I
I
1 Primarv Slot
I
I
2 Back-Up Slot

LED Functionality

There are 2 LED's on the top left of the modem module.
The top LED (D1) stays on during the configuration period
of the modem. When the modem has been configured
this LED flashes regularly (once every second approx.) to
indicate that the modem is functioning normally.
The bottom LED (D2) flashes when the modem is
communicating with the SPCN310 mast. This occurs
during registration and whenever data is being
exchanged.
An antenna (supplied with the SPCN310) needs to be
I
attached to the SMA connector located at the end of the
I
connector lead. (If an additional SMA connector is
I
mounted on the top of the module, do not use it to
connect the antenna.) The antenna can be mounted on
the top of the cabinet using one of the knock-out holes
provided. Ensure that the antenna is unobstructed.
I
I I
See Fig_: 4 LEDs on the toe left
3
-----------
' -
:
'
'
'
&.
Please make a note of the unlock code for your SIM card
as this will be required when enabling the SIM card on the
SPC.

Configuring the SPCN310

I
I
For configuration instruction please refer to SPC
I Configuration Manual or SPC Pro Configuration Manual.

Technical Data

Communication
protocol
Interfaces
Status LEDs
Network
connection
Current
consumotion
Operating
temperature
Relative
humiditv
MountinQ
Standards
I
� 0
4
--
:
'
'
'
0
Installation Instruction
When replacing or installing modules
on the SPC system, always ensure
that the mains supply and the battery
WARNING are disconnected. Ensure that all
anti-static precautions are adhered to
when handling connectors, wires,
terminals and PCBs.
Analogue alarm protocols (e.g. SIA,
Contact ID), PPP dial up, SMS
1 x 16-Pin socket to controller
interface,
1 x SMA connector for aerial
2
GSM (dual band 90011800 MHz)
Min. 50 mA at 12 V DC
Max. 60 mA at 12 V DC
s - ·c
40
Max. 90 % (no condensation)
Plui:i on module for SPC controller
Designed to meet
EN50131-1 :2006 (Grade 3),
TS50131-3:2003 (Grade 3)
