SEC/SH/11/16/EU1
CHARLES 2 DRAWER BEDSIDE
ASSEMBLY INSTRUCTIONS
FOR DOMESTIC USE ONLY
IMPORTANT
PLEASE READ BEFORE YOU CONTINUE FURTHER
THE PRODUCT YOU HAVE PURCHASED WILL GIVE YOU MANY
YEARS OF SERVICE IF YOU FOLLOW THE GUIDELINES FOR ITS
SAFE ASSEMBLY AND PERIODIC MAINTENANCE AND CLEANING.
ASSEMBLE ON A SOFT CLEAN SURFACE.
DO NOT USE ANY TOOLS OTHER THAN THOSE SHOWN.
ANY SPANNERS OR ALLEN KEYS REQUIRED ARE INCLUDED WITH
THE FITTINGS KIT.
DO NOT FOR ANY REASON USE A POWER TOOL TO ASSEMBLE
THIS PRODUCT.ITS USE WILL INVALIDATE ANY CLAIM YOU MAY
HAVE AND COULD MAKE THIS PRODUCT UNSAFE.
DEPENDING ON THE AMOUNT OF USE THIS PRODUCT RECEIVES
IT MAY BE NECESSARY TO TIGHTEN UP THE FIXINGS FROM TIME
TO TIME.THIS IS COMPLETELY NORMAL FOR ANY FLAT PACK
FURNITURE.DO NOT OVERTIGHTEN FIXING.
FOR CLEANING,YOU MAY USE A DAMP CLOTH (NOT WET) DO NOT
USE POLISH,DETERGENT OR CHEMICAL CLEANERS.
THE SURFACE OF THIS ITEM IS NOT HEAT RESISTANT.ALWAYS
USE A PLACE MAT UNDER HOT OR COLD ITEMS TO PREVENT
MARKING.
PAGE 1 OF 9
Advertisement
Related Manuals for Seconique Furniture Charles 100-103-029
Summary of Contents for Seconique Furniture Charles 100-103-029
- Page 1 SEC/SH/11/16/EU1 CHARLES 2 DRAWER BEDSIDE ASSEMBLY INSTRUCTIONS FOR DOMESTIC USE ONLY IMPORTANT PLEASE READ BEFORE YOU CONTINUE FURTHER THE PRODUCT YOU HAVE PURCHASED WILL GIVE YOU MANY YEARS OF SERVICE IF YOU FOLLOW THE GUIDELINES FOR ITS SAFE ASSEMBLY AND PERIODIC MAINTENANCE AND CLEANING. ASSEMBLE ON A SOFT CLEAN SURFACE.
- Page 2 SEC/SH/11/16/EU1 ( SCREWDRIVER NOT PROVIDED ) USE A FLAT HEAD SCREWDRIVER TO TIGHTEN THE CAM NUTS. A QUARTER TURN CLOCKWISE IS ALL THAT IS NEEDED. STEP 1 - PUSH CAM BOLT INTO INSERT STEP 2 - ALIGN THE CAM BOLT WITH THE HOLE AND PUSH TOGETHER UNTIL FLUSH. ( MAKE SURE THE ARROW OF CAM LOCK IS POINTING TOWARD THE HOLE ON EDGE OF PANEL.
- Page 3 SEC/SH/11/16/EU1 PARTS LIST PARTS LIST PLEASE CHECK THAT YOU HAVE ALL THE PARTS LISTED BEFORE YOU START LEFT SIDE PANEL 1 PC ASSEMBLING.IF YOU DO FIND THAT SOMETHING IS MISSING,DO NOT CONTINUE TOP FRAME ( FRONT ) 1 PC ASSEMBLY,PLEASE CONTACT YOUR SUPPLIER IMMEDIATELY. TOP FRAME ( BACK ) 1 PC BASE FRAME HORIZONTAL...
- Page 4 SEC/SH/11/16/EU1 HARDWARE LIST DOWEL 6 X 30MM 30 PCS BOLT M7 X 60MM 10 PCS SCREW M4 X 30MM 4 PCS SCREW M4 X 38MM 8 PCS TACK 16 PCS 2 PCS HANDLE CAM BOLT + CAM NUT 4 SETS EDGE PROTECTOR 2 SETS HANDLE SCREW M4 X 30MM...
- Page 5 SEC/SH/11/16/EU1 STEP 1 STEP 2 YOU WILL NEED :- YOU WILL NEED :- 16 PCS 22 PCS 4 PCS UP SECOND HOLE FRONT BACK FIRST HOLE LAST SECOND HOLE SCREW MUST BE INSERTED IN THE FIRST HOLE ON THE DRAWER RUNNER THE USE OF POWER TOOLS TO ASSEMBLE THIS PRODUCT WILL INVALIDATE CAUTION :...
- Page 6 SEC/SH/11/16/EU1 STEP 3 STEP 4 YOU WILL NEED:- YOU WILL NEED:- 5 PCS 5 PCS 1 PC 1 PC FINISHED EDGE THE USE OF POWER TOOLS TO ASSEMBLE THIS PRODUCT WILL INVALIDATE CAUTION : ANY CLAIM AND MAY DAMAGE THIS PRODUCT MAKING IT UNSAFE. PAGE 6 OF 9...
- Page 7 SEC/SH/11/16/EU1 STEP 5 STEP 6.1 YOU WILL NEED:- YOU WILL NEED:- 4 PCS 8 PCS FRONT SIDE VIEW 2 SETS 4 PCS BEFORE FIXING THE TOP PANEL PLEASE ALIGN THE TOP PANEL WITH THE FRONT FRAME. BOTTOM 1 & 7 PLEASE INSERT THE BACK PANEL INTO THE UNIT STEP 6.2...
- Page 8 SEC/SH/11/16/EU1 STEP 7.1 STEP 7.2 YOU WILL NEED:- 8 PCS 8 PCS & 8 PCS 2 PCS 4 SETS 4 PCS 12 PCS STEP 7.3 4 PCS THIRD HOLE 11 & 12 FRONT LAST THIRD HOLE BACK STEP 7.4 STEP 7.5 2 X DRAWERS THE USE OF POWER TOOLS TO ASSEMBLE THIS PRODUCT WILL INVALIDATE CAUTION :...
- Page 9 SEC/SH/11/16/EU1 STEP 8 STEP 9 THE USE OF POWER TOOLS TO ASSEMBLE THIS PRODUCT WILL INVALIDATE CAUTION : ANY CLAIM AND MAY DAMAGE THIS PRODUCT MAKING IT UNSAFE. PAGE 9 OF 9...
