HDBaseT-4x4Matrix
HDBaseT-4x4-Matrix(HDMI 2.0)
HDMI 2.0 18Gbps 4x4 HDMI Matrix w/ Audio Extractor
4159 McConnell Drive Burnaby B.C. Canada V5A-3J7
Toll Free 1-855-204-1388
www.factorelectronics.com
Factor Electronics
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HDBaseT-4x4Matrix and is the answer not in the manual?

Questions and answers

Summary of Contents for Factor Electronics HDBaseT-4x4Matrix

  • Page 1 HDBaseT-4x4Matrix HDBaseT-4x4-Matrix(HDMI 2.0) HDMI 2.0 18Gbps 4x4 HDMI Matrix w/ Audio Extractor 4159 McConnell Drive Burnaby B.C. Canada V5A-3J7 Toll Free 1-855-204-1388 www.factorelectronics.com Factor Electronics...
  • Page 2 HDBaseT-4x4Matrix Thank you for purchasing this product. For optimum performance and safety, please read these instructions carefully before connecting, operating or adjusting this product. Please keep this manual for future reference. SURGE PROTECTION DEVICE RECOMMENDED This product contains sensitive electrical components that may be damaged by electrical spikes, surges, electric shock, lightning strikes, etc.
  • Page 3: Table Of Contents

    HDBaseT-4x4Matrix Table of Content Introduction ......................... 5 Features ..........................5 Panel Descriptions ......................6 Front Panel ........................6 Back Panel ........................7 Remote Control Description ....................8 Master Remote Control ....................8 Output and Input select ..................9 EDID Set Up ......................9 Satellite Remote Control ....................
  • Page 4 HDBaseT-4x4Matrix EDID Page ........................29 Audio Page ......................... 30 ....................... 30 Users Page Maintenance ........................31 Warranty Policy ......................... 31 Limitations of Warranty..................... 31 Exclusive Remedies ......................32 RMAPolicy ......................... 32 Standard Replacement ....................32 Once you have obtained an RMA number ..............33 Please note .........................
  • Page 5: Introduction

    HDBaseT-4x4Matrix Introduction The HDBASET-4X4MATRIX HDBaseT 4×4 Matrix for HDMI routes four Hi-Def sources to any four HDTV displays, supporting 1080p Full HD up to 4K@60Hz HDR plus all 3D formats, along with multichannel digital audio formats such as Dolby® True HD and DTS-HD® Master Audio™.
  • Page 6: Panel Descriptions

    Front Panel 1. LCD display---Shows the status of input-output selection, EDID info and so on. 2. IR receiver window----Receives the IR from the remote control of the HDBaseT-4x4Matrix. 3.Power LED indicator---Indicates the power status for the matrix. 4. Power button---Press to power on/off the matrix.
  • Page 7: Back Panel

    HDBaseT-4x4Matrix OUT5 OUT5=Copy OUTPUT5 EDID to INPUTx OUT6 OUT6=Copy OUTPUT6 EDID to INPUTx OUT7 OUT7=Copy OUTPUT7 EDID to INPUTx OUT8 OUT8=Copy OUTPUT8 EDID to INPUTx 8. Up selection button--- Press to change a segment’s value. 9. ESC---Press to quit EDID set mode.
  • Page 8: Remote Control Description

    12. HDMI outputs 1 to4---Output to four displays, AVR etc. 13. IR extension receiver input --- 3.5mm stereo phone-jack, connects to the IR receiver cable to receive the IR from the HDBaseT-4x4Matrix remote. 14. Power port---Use the included 24V/3.5ADC adaptor to power the matrix.
  • Page 9: Output And Input Select

    HDBaseT-4x4Matrix Output and Input select A. OUTPUT-X select INPUT-Y: 1. Press OUTPUT-X (X = outputs1 to 4 )Press INPUT-Y ( Y = inputs 1 to 4 ) 2. Press OUTPUT-X (X= outputs 1 to 4 ) press the left and right arrow buttons to select the input.
  • Page 10: Application Diagram

    HDBaseT-4x4Matrix Application Diagram Specifications Bandwidth 18 Gbps Video Input Connectors 4xHDMI Type A, 19-pin, female Video Output Connectors 4xHDMI Type A, 19-pin, female, 4x RJ45 Connector Audio Output Connectors 4x RCA(SPDIF), 4x L/R RS232 Serial port DB-9, female TCP/IP Control...
  • Page 11: Package Contents

    HDBaseT-4x4Matrix Package Contents 1x HDbaseT-4x4Matrix 1x 24V/3.5A DC Power Supply 1x Power Cord 1x Master Remote Control 4x Satellite Remote Control 4x IR Transmitter 5x IR Receiver 8x Phoenix connector 1xRack-mount kit RS-232 Pin Assignment Remote Control Console HDBASET-4X4MATRIX(DCE) (DTE)
  • Page 12: Rs232 And Telnet Commands

    HDBaseT-4x4Matrix RS232 and Telnet Commands Command Action Print Help Information HELP Print Help Information STATUS Print System Status And Port Status Power On, System Run On Normal State POFF Power Off, System Run On Power Save State IR ON/OFF Set System IR Control On Or Off (Only for IR Extension)
  • Page 13 HDBaseT-4x4Matrix zz=08: HDMI 1080p@60Hz/3D, Audio 7.1CH PCM/DTS/DOLBY/HD zz=09: HDMI 4K2K, Audio 2CH PCM zz=10: HDMI 4K2K, Audio 5.1CH PCM/DTS/DOLBY zz=11: HDMI 4K2K, Audio 7.1CH PCM/DTS/DOLBY/HD zz=12: DVI 1280x1024@60Hz, Audio None zz=13: DVI 1920x1080@60Hz, Audio None zz=14: DVI 1920x1200@60Hz, Audio None...
  • Page 14: Gui Control

    HDBaseT-4x4Matrix GUI Control PC System: Microsoft Windows Operation System Installation The HDBaseT4x4 Matrix software controller is green software.Simply copy the “4x4 HDMI Matrix Controller vx.x.exe” to your PC which is used to control the Matrix by connecting an RS232 COM or TCP port to complete the installation.
  • Page 15: General" Page

    HDBaseT-4x4Matrix “ ” General page ① Select control mode: RS232 COM mode (Auto COM ports detected) or TCP mode ② List detected COM ports ③ List all Matrix devices after search operation ④ Click to search all Matrix devices that connected in same subnet ⑤...
  • Page 16: Set Tcp Control Configuration

    HDBaseT-4x4Matrix Set TCP control configuration Click the Config button to show the TCP configuration window. ① Set the tag to identify Matrix device ② Set IP mode: Subnet should support DHCP protocol when set Auto IP mode, then Matrix device will obtain IP automatically. Otherwise, set Static IP mode and designate a useable IP for Matrix device ③...
  • Page 17: Port Tag" Page

    HDBaseT-4x4Matrix “Port Tag” page ① Input port tags ② Click to edit Input port tags ③ Output port tags ④ Click to edit Output port tags NOTE: Edit boxes are read only, click the “Edit” button to edit the tags in the pop up window .
  • Page 18: Edit Input Port Tags

    HDBaseT-4x4Matrix Edit Input port tags After action of② , edit form will pop-up as below: Define tags for respective Input port, then devices connect the Input ports can be easily remembered. Click buttons with “×” caption to delete the tag that you want to delete, if a tag is still used by any other Input port, the delete action will be discarded.
  • Page 19: Setting" Page

    HDBaseT-4x4Matrix “Settings” page ① LED displays the Input number for respective Output port ② Click to select the Input port for the respective Output port ③ Click to select previous or next Input ports for the respective Output port ④ Displays the IN/OUT with tag information when a mouse moves cursors over ② buttons ⑤...
  • Page 20: Pop-Up Tag Messages

    HDBaseT-4x4Matrix Pop-up tag messages When the “Display Input, Output tags setting buttons are on” The “General” page is checked and the Input/output port tag has been defined, tag messages will pop up like this: Pop-up Menu When the mouse cursors over the② setting buttons right click the mouse and the menu will pop up like this: www.factorelectronics.com...
  • Page 21: Edit Selected Pre-Setting Item

    HDBaseT-4x4Matrix All Outputs: All Outputs from the same Input “1 Output” to “4 Outputs”: Set the current Output (right click the mouse) and the next x-1 ( x range is from 1 to 4, set total x Outputs at the same time )all Output(s) from the same Input Port to Port: Output1 from Input1, Output2 from Input2, Output3 from Input3, etc.
  • Page 22: Edid Control" Page

    HDBaseT-4x4Matrix “EDID control” page ① Set the EDID mode for the selected Input port or All Input ports, click the “Set” button to complete the action. NOTE: When setting User1/User2 EDID mode,downloadthe EDID content to the User1 Memory/User2 Memory first. The User1/User2 default EDID content is 1080p, Stereo Audio 2.0.
  • Page 23: Ir Configuration" Page

    HDBaseT-4x4Matrix ⑧ Click to clear EDID content displayed in grid “IR Configuration” page To enable or disable the IR control functions. When the box is checked the IR control functions are enabled, otherwise the IR control functions are disabled. This setting is not memorized. IR control function is always enabled after power up.
  • Page 24: Fw Upgrade" Page

    HDBaseT-4x4Matrix “FW upgrade” page ① Click to open firmware file (file extension is “.fw”). ② Firmware upgrade progress ③ Click the button to upgrade the firmware. NOTE: If a failure occurs during the upgrading firmware process, the following steps SHOULD...
  • Page 25: Web Gui

    HDBaseT-4x4Matrix Web GUI How to enter the Web GUI Type in the IP address "192.168.0.200" in your web browser to enter the Web GUI. The first login will enter the default Guest account where you can only check limited system info and perform simple source switching.
  • Page 26: Admin Account

    HDBaseT-4x4Matrix Admin account Logout of the guest account and login to the admin account for full access. Account Name: admin Password: 1234 Zone Page Same as Guest account interface www.factorelectronics.com Factor Electronics...
  • Page 27: Status Page

    HDBaseT-4x4Matrix Status Page System info and Web UI info including Model Number, Firmware Version, Power Status, IP status, IP address, Gateway, Subnet Mask, MAC Address and UI Version. You can turn the matrix ON/OFF by clicking the power icon on the bottom.
  • Page 28: Output Page

    HDBaseT-4x4Matrix Output Page You can select Input for each Output, enable/disable each Output and set the priority for HDMI/HDBaseT outputs This page also shows the connect status for HDMI/HDBaseT ports. Input Page You can set the Input Source priority (Force HDMI, Force HDBT, Auto HDMI or Auto HDBT), check the current input source and check the HDMI/HDBT connected status.
  • Page 29: Preset Page

    HDBaseT-4x4Matrix Preset Page There're several preset input/output settings to choose from. EDID Page You can select built-in EDID patterns for each input, and select EDID priority for HDMI/HDBT. www.factorelectronics.com Factor Electronics...
  • Page 30: Audio Page

    HDBaseT-4x4Matrix Audio Page You can select audio sources for each output, set audio delay values, and control the audio volume.in each zone User Page You can create, edit and remove accounts. PS: The Admin account can't be deleted. www.factorelectronics.com Factor Electronics...
  • Page 31: Maintenance

    The warranty does not apply to any part of a product that has been installed, altered, repaired, or misused in any way that, in the opinion of Factor Electronics, would affect the reliability or detracts from the performance of any part of the product, or is damaged as the result of use in a way or with equipment that had not been previously approved by Factor Electronics.
  • Page 32: Exclusive Remedies

    Exclusive Remedies Factor Electronics warranty, as stated is in lieu of all other warranties, expressed, implied, or statutory, including those of merchantability and fitness for a particular purpose. The buyer...
  • Page 33: Once You Have Obtained An Rma Number

    Shipping your RMA to Factor Electronics using regular mailing envelopes is not acceptable, as they do not protect the product from damage during shipping. Factor Electronics will not repair or replace a module that is shipped in such a way that the product is not properly protected.
