Summary of Contents for Ancar TOPCON ATE-800
- Page 1 INSTRUCTION MANUAL OPHTHALMIC TABLE ATE-800 (MARCH - 2009) QS4-423-01...
- Page 2 Antoni Carles, S.A. Volta dels Garrofers, 41-42 T. (34) 93 754 07 97 Pol. Ind. Els Garrofers F. (34) 93 759 26 04 calidad@ancar-online.com 08340-Vilassar de Mar www.ancar-online.com/ (Barcelona-SPAIN) ISO 9001 ISO13485 DCA-0274-AQ-99 DCA-0274-NA-99 EC Declaration of Conformity (Directive 93/42/EEC) Manufacturer’s Name...
- Page 3 INTRODUCTION Thank you for purchasing the TOPCON elevation table ATE-800. This instruction manual covers an overview of the TOPCON line-powered elevation table, basic operations, troubleshooting, maintenance and cleaning. To ensure the efficient, safe use, carefully read through “Safety Precautions” and use the instrument correctly accordingly operating procedures.
-
Page 4: Safety Precautions
3.- SAFETY PRECAUTIONS Warnings - To ensure that the product is used correctly and to avoid risk of accident to the operator and third parties or damage to property, warnings and information have been placed on the table and are described in the User Manual. -Install, use and store the ophthalmic table under controlled conditions, including the temperature range (+10ºC a +40ºC), humidity (30-80%), and atmospheric pressure (700 to 1060 hPa), dust and condensation free, and away from direct sunlight as well as salty /... -
Page 5: Usage And Maintenance
4.- USAGE AND MAINTENANCE This elevation table is an electric instrument and it must be used in accordance with its Instruction Manual. User Maintenance To maintain the safety and performance of the equipment, never attempt to repair or perform maintenance. An authorized service representative should perform these tasks. Repairs to the elevation group and electronic controls should be only carried out at the manufacturer’s facilities. - Page 6 6.- DIMENSIONS QS4-423-01...
-
Page 7: Installation
7.- INSTALLATION Turn upside-down elevation group (3) and lean it on wood plug. First remove covers (10, 11) from base frame (6). To assemble it into lift column, pass wire through hole (5). Then screw on to fix elevation group into base with the help of screws (8) and washers (3 of them standard ones, flat ones, “9”, and one to assure electrical safety, earth continuity, a glover washer, “7”). - Page 8 Before placing tabletop support frame, remove wood plugs (in previous image, details “1” and “2”). Frame is fixed on top of lift column with screws (3). Please pay attention when passing cabling through hole (5). Disassemble cover (8) to get access to the connection to be made in connector (7) and proceed in order with electrical diagram.
-
Page 9: Auxiliary Outputs
8.- KEYBOARD The table moves up and down by pressing the up & down switch. Detail about up (“1”) & down (“2”) maneuver control placed on tabletop. Both push buttons have light incorporated. 9.- AUXILIARY OUTPUTS There are four available outlets placed under tabletop. They have an on/off switch associated that can be located below frame. -
Page 10: Maintenance
11.- MAINTENANCE Surfaces of the table can be cleaned by a cotton piece dampened with water and neuter soap. Dry up immediately. Do not splash with water or any other liquid. Do not blow spray cleaner directly into the unit. It could travel through a clearance around the switches and cause electrical problems. -
Page 11: Electrical Diagram
13.- ELECTRICAL DIAGRAM QS4-423-01... - Page 12 14.- ADDRESSES Topcon Europe Medical B.V. Essebaan 11; 2908 Ll Capelle a/d Ussel; P.O. Box 145; 2900 AC Capelle a/d Ussel; The Netherlands Phone: (+31) 10 4585077; Fax: (+31) 10 4585045 E-mail: mailto:medical@topcon.eu; www.topcon.eu Topcon Deutschland GmbH Topcon S.A.R.L. Giesserallee 31; D-47877 Willich, Germany HEAD OFFICE;...
